| Ref | Part Number | Description |
|---|
| 1 |
353-426 |
FITTING-90 DEG Price: $29.88 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 2 |
237-80 |
O-RING Price: $6.10 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT Price: $119.99 |
| 3 |
44-7612 |
BOLT-HWH Price: $24.50 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
353-721 |
PLUG Price: $44.12 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
237-79 |
O-RING Price: $5.46 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
38-5540 |
FITTING-HYD Price: $80.14 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
353-537 |
FITTING-ELBOW, 90 DEG Price: $12.91 |
| 8 |
52-5860 |
COLLAR-SPOOL Price: $13.37 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
68-4240 |
BONNET ASSEMBLY Price: $42.76 |
| 10 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
353-976 |
SCREW Price: $1.49 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
353-417 |
COLLAR-STOP Price: $10.31 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
44-7650 |
SPRING Price: $31.84 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
353-959 |
PLATE-RETAINER, SEAL Price: $7.40 |
| 15 |
353-958 |
WASHER Price: $13.57 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
3219-3 |
NUT-HEX Price: $0.34 |
| 17 |
532177883 |
SHAFT ASM STRG Price: $104.99 |
| 18 |
353-799 |
CONVERSION PLUG ASM Price: $87.60 |
| 19 |
237-177 |
O-RING This part replaces 353-800. Price: $2.73 |
| 20 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 21 |
353-798 |
PLATE-COVER, RIGHT Price: $451.34 |
| 22 |
322-13 |
SCREW-HH Price: $2.73 |
| 26 |
353-318 |
WIPER Price: $32.73 |
| 28 |
353-321 |
PIN-COTTER Price: $3.15 |
| 29 |
353-324 |
HANDLE BRACKET Price: $107.74 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
63-8760 |
LINK PIN KIT Price: $62.78 |
| 31 |
3272-1 |
PIN-COTTER Price: $0.25 |
| 32 |
52-5900 |
SCREW Price: $26.40 |
| 32 |
532171888 |
TIE ROD Price: $59.99 |
| 33 |
52-5670 |
DISCONTINUED X-REF Price: Call Us |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
63-8760 |
LINK PIN KIT Price: $62.78 |
| 36 |
353-322 |
PIN-CLEVIS Price: $5.09 |
| 36 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 37 |
44-7660 |
DISCONTINUED Price: Call Us |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
353-306 |
WASHER-BACKUP Price: $9.12 |
| 38 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 39 |
353-305 |
O-RING Price: $10.91 |
| 39 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532199978. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 118 |
532406013 |
BUSHING, AXLE CAST Price: $4.99 |
