| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT This part replaces 351-59. Price: $273.15 |
| 1 |
530057785 |
Assy-Throttle Cable Price: $6.99 |
| 2 |
351-64 |
DISCONTINUED Price: Call Us |
| 2 |
530058747 |
Throttle Hsg. (Left) Price: $5.99 |
| 3 |
351-60 |
Backrest Price: Call Us |
| 3 |
530057562 |
Locator- left Price: $2.99 |
| 4 |
351-65 |
DISCONTINUED Price: Call Us |
| 4 |
530057563 |
Locator- right Price: $2.99 |
| 5 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 6 |
3217-6 |
NUT-HEX Price: $1.19 |
| 6 |
530016422 |
Bolt-Handle Price: $1.99 |
| 7 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 7 |
530058752 |
Handle-Assist Price: $6.99 |
| 8 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 8 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 9 |
2412-4 |
CLAMP-R Price: $4.22 |
| 9 |
530016406 |
Screw Price: $1.99 |
| 10 |
23-1760 |
DISCONTINUE Price: Call Us |
| 10 |
545007502 |
Shaft- Flex This part replaces 530095939. Price: $11.99 |
| 11 |
530058748 |
Throttle Hsg. (Right) Price: $5.99 |
| 11 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 12 |
32144-102 |
SCREW-HWH This part replaces 11-0590. Price: $3.19 |
| 12 |
530015814 |
Screw Price: $1.99 |
| 13 |
26-0410 |
DISCONTINUED Price: Call Us |
| 13 |
530058000 |
Trigger Price: $2.99 |
| 14 |
23-1770 |
DISCONTINUED Price: Call Us |
| 14 |
530016405 |
Nut-Push Price: $1.99 |
| 15 |
23-1700 |
DISCONTINUED Price: Call Us |
| 15 |
530016407 |
Spring-Actuator Price: $1.99 |
| 16 |
32103-2 |
NUT-WING Price: $0.68 |
| 16 |
530057551 |
Actuator Price: $2.99 |
| 17 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 17 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 18 |
530052287 |
Line Limiter Price: $1.99 |
| 18 |
82-8970 |
DECAL-COOLANT, ENGINE This part replaces 26-7530. Price: $16.00 |
| 19 |
18-2660 |
DISCONTINUED Price: Call Us |
| 19 |
530015814 |
Screw-Line Limiter Price: $1.99 |
| 20 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 20 |
530054459 |
Assy-Wire Guard Price: $3.99 |
| 21 |
23-2150 |
DISCONTINUED Price: Call Us |
| 21 |
530016179 |
Screw Price: $1.99 |
| 22 |
66-6140 |
DECAL This part replaces 18-2180. Price: $25.48 |
| 23 |
27-3220 |
DECAL Price: $41.43 |
| 23 |
530015820 |
Bolt-Shield Price: $1.99 |
| 24 |
26-9890 |
UPPER HOSE Price: $51.37 |
| 25 |
322-3 |
SCREW-HH Price: $0.79 |
| 25 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 26 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 27 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 27 |
530403949 |
Guide-Line Price: $2.99 |
| 28 |
26-9900 |
LOWER HOSE Price: $59.90 |
| 28 |
530054223 |
Assy-Cap Price: $5.99 |
| 29 |
26-0310 |
DISCONTINUED Price: Call Us |
| 30 |
249-21 |
CLAMP-SLOTTED Price: $18.93 |
| 31 |
32140-43 |
DISCONTINUED Price: Call Us |
| 32 |
304-46 |
DRAINCOCK Price: $7.55 |
| 33 |
32128-19 |
NUT-HF Price: $0.99 |
| 34 |
353-548 |
ELBOW Price: $16.04 |
| 35 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 36 |
52-4890 |
ROD-CONNECTING This part replaces 351-61. Price: $33.91 |
| 37 |
51-0790 |
ADJUSTER-SEAT, LH This part replaces 351-63. Price: $127.92 |
| 38 |
351-62 |
DISCONTINUED Price: Call Us |
