| Ref | Part Number | Description |
|---|
| 1 |
127-4840 |
DECK ASM Price: $2,958.09 |
| 2 |
121-5481-01 |
PLATE-SPINDLE Price: $246.80 |
| 3 |
127-4843 |
RH PLATE ASM Price: $430.58 |
| 3 |
817490408 |
SCREW Price: $5.99 |
| 4 |
127-4844 |
LH PLATE ASM Price: $468.95 |
| 5 |
3230-22 |
SCREW-CARR Price: $1.99 |
| 6 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 7 |
114-0997 |
PIVOT-IDLER Price: $53.85 |
| 8 |
125-9433 |
IDLER ARM ASM Price: $159.42 |
| 9 |
140-7079 |
IDLER ARM ASM This part replaces 117-9176. Price: $49.85 |
| 10 |
116506 |
SPRING-EXTENSION Price: $18.19 |
| 11 |
108-1921 |
SPRING-TORSION Price: $28.33 |
| 12 |
121-5274 |
SPACER-IDLER Price: $35.01 |
| 13 |
139-1037 |
DOUBLE DRIVEN SPINDLE ASM This part replaces 119-4548. Price: $724.15 |
| 14 |
138-1931 |
DOUBLE DRIVEN SPINDLE ASM This part replaces 121-5255. Price: $706.34 |
| 15 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 16 |
106-7166-03 |
BLADE-COMBINATION (19 INCH) Price: $32.86 |
| 17 |
92-5816 |
BOLT-BLADE Price: $4.93 |
| 18 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 19 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 20 |
93-4871 |
GEARBOX PULLEY ASM Price: $374.90 |
| 21 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 22 |
108-1926 |
WASHER Price: $5.30 |
| 23 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 24 |
1-613098 |
PULLEY-IDLER Price: $33.36 |
| 25 |
108-1993 |
SCREW-HSBH Price: $3.66 |
| 26 |
3296-45 |
NUT-HEX Price: $3.79 |
| 27 |
92-2651 |
WASHER Price: $1.83 |
| 28 |
121-5253 |
BELT-V Price: $103.34 |
| 29 |
132-1324 |
BELT-V, 54.75 INCH This part replaces 121-5254. Price: $53.39 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 31 |
01-182-0816 |
BOLT-HH Price: $2.85 |
| 32 |
3218-5 |
NUT-JAM Price: $0.27 |
| 33 |
42257 |
SPACER-TUBULAR Price: $11.54 |
| 34 |
SG271517 |
SCREW-HH Price: $6.79 |
| 35 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 36 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 37 |
140-5848 |
PULLEY-IDLER This part replaces 63-1540-03. Price: $62.48 |
| 38 |
117-3266 |
SCREW-HH Price: $1.63 |
