| Ref | Part Number | Description |
|---|
| 1 |
163465 |
Battery 12 Volt 25 Amp Price: Call Us |
| 2 |
74760412 |
Bolt Hex Hd 1/4-20 unc x 3/4 Price: Call Us |
| 2 |
92-5655 |
TUBE-CANOPY Price: $15.47 |
| 3 |
58-3930 |
BUSHING-OILITE Price: $15.24 |
| 4 |
58-5330 |
SPACER-HINGE, CANOPY Price: $21.23 |
| 5 |
58-5350 |
SPACER-HINGE, CANOPY Price: $19.88 |
| 6 |
58-1970-01 |
PLATE-HINGE, LEFT Price: $199.89 |
| 7 |
58-1980-01 |
PLATE-HINGE, RIGHT Price: $199.89 |
| 8 |
176689 |
Box Battery Price: Call Us |
| 8 |
86-6130 |
BALL-STUD Price: $7.46 |
| 9 |
92-6086 |
REAR SCREEN ASM Price: $2,609.76 |
| 10 |
92-5253 |
STRIP-SEALING Price: $59.20 |
| 11 |
58-3910 |
PIN-HINGE, CANOPY Price: $70.69 |
| 12 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 13 |
77-3620 |
KNOB-RETAINER Price: $15.13 |
| 15 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 16 |
176138 |
Switch Interlock Push -In Price: Call Us |
| 16 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
88-6760 |
SPRING-GAS Price: $143.68 |
| 18 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 19 |
105-3330-03 |
BAFFLE-BODY, LOWER Price: $92.45 |
| 20 |
3250-25 |
SCREW-PPH Price: $0.23 |
| 21 |
183759 |
Harness Asm Light W/4152J Price: Call Us |
| 21 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 22 |
4152J |
Bulb Light #1156 Price: Call Us |
| 22 |
58-5380 |
LATCH-DRAW Price: $43.60 |
| 23 |
58-7070-03 |
SPACER-LATCH, RH Price: $17.58 |
| 24 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 24 |
4799J |
Cable Battery 6 Ga. 11"red Price: Call Us |
| 25 |
146147 |
Cable Battery 6 Ga. w/16 wire,red Price: Call Us |
| 25 |
322-3 |
SCREW-HH Price: $0.79 |
| 26 |
175158 |
Fuse 20 AMP Price: Call Us |
| 26 |
3250-31 |
SCREW-PPH Price: $0.25 |
| 27 |
68-6040 |
BRACKET Price: $13.03 |
| 27 |
73510400 |
Nut Keps Hex 1/4-20 unc Price: Call Us |
| 28 |
3256-51 |
WASHER-FLAT Price: $0.19 |
| 28 |
4207J |
Cable Ground 6 Ga. 12" black Price: Call Us |
| 29 |
121305X |
Switch Plunger Nc Gray Price: Call Us |
| 29 |
3296-27 |
NUT-LOCK, NI Price: $0.27 |
| 30 |
175566 |
Switch Ign Price: Call Us |
| 31 |
106-7074 |
CANOPY-FRONT Price: $1,980.37 |
| 32 |
33024-00 |
NUT-LOCK, NI This part replaces 48-9510. Price: $0.75 |
| 33 |
140401 |
Key Ign Price: Call Us |
| 33 |
92-5652-03 |
BRACKET Price: $10.46 |
| 34 |
33114-025 |
SCREW-HH Price: $0.70 |
| 35 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 36 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 37 |
105-3325 |
CENTER CANOPY ASM Price: $1,680.34 |
| 38 |
237-141 |
GROMMET-RUBBER Price: $2.39 |
| 39 |
92-5678 |
FOAM-HOOD, TOP Price: $239.26 |
| 40 |
179720 |
Harness Ign Price: Call Us |
| 40 |
92-5679 |
FOAM-HOOD, FRONT Price: $166.50 |
| 41 |
71110408 |
Bolt Blk Fin Hex 1/4-20 x 1/2 Price: Call Us |
| 41 |
92-5680 |
FOAM-HOOD, RH Price: $187.22 |
| 42 |
131563 |
Cover Terminal Red Price: Call Us |
| 42 |
92-5681 |
FOAM-HOOD, LH Price: $187.22 |
| 43 |
178861 |
Solenoid Price: Call Us |
| 43 |
92-5672-03 |
SUPPORT-FOAM, CANOPY Price: $198.05 |
| 44 |
92-5673-03 |
SUPPORT-FOAM, FRONT Price: $46.11 |
| 45 |
121433X |
Ammeter Price: Call Us |
| 45 |
92-6060 |
STRIP-SEALING Price: $59.20 |
| 46 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 47 |
322-4 |
SCREW-HH Price: $0.35 |
| 48 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 49 |
321-2 |
SCREW-HH Price: $2.79 |
| 50 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 52 |
141940 |
Protection Wire Loop Price: Call Us |
| 54 |
104-5230-03 |
BRACKET-FUEL Price: $59.33 |
| 55 |
94-8226-03 |
BRACKET-CLEANER, AIR Price: $55.22 |
| 56 |
32122-42 |
SCREW Price: $1.69 |
| 57 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 58 |
321-3 |
SCREW-HH Price: $0.28 |
| 59 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 62 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 63 |
98-5398 |
LATCH Price: $32.53 |
| 64 |
99-8970 |
KEY-LATCH, HOOD Price: $15.13 |
| 65 |
98-9321 |
RING-KEY Price: $1.80 |
| 66 |
100-6574 |
DECAL-WARNING Price: $15.80 |
| 67 |
133-8095 |
DECAL-CE This part replaces 93-7252. Price: $3.73 |
| 68 |
2412-109 |
CLIP-J Price: $3.82 |
