| Ref | Part Number | Description |
|---|
| 1 |
532059192 |
VALVE CAP Price: $4.99 |
| 1 |
94-3132 |
SCREW-HHF Price: $1.17 |
| 2 |
532065139 |
VALVE STEM LT Price: $5.99 |
| 2 |
741-3005 |
BUSHING Not Available Price: |
| 2 |
94-3130 |
SCREW-HH Price: $0.57 |
| 3 |
532106732 |
RIM.ASM.6X4.5.FRONT.SILVER This part replaces 532138336. Price: $79.99 |
| 3 |
937-3000 |
Grease Fitting This part replaces 7373000. Price: $4.04 |
| 3 |
94-3125 |
DISCONTINUED Price: Call Us |
| 4 |
710-3019 |
BOLT-PIVOT 3/4-10 x 5.0 GR5 W Not Available Price: |
| 4 |
94-3129 |
PLUG Price: $1.40 |
| 5 |
532122073 |
TIRE.15X6-6.TURF.SAVER.FRONT This part replaces 532106222. Price: $59.99 |
| 5 |
703-1445-0637 |
KNUCKLE ASSEMBLY (LH)(POWDER BLACK) Not Available This part replaces 703-1445. Price: |
| 5 |
94-3126 |
DISCONTINUED Price: Call Us |
| 6 |
703-0275 |
KNUCKLE ASSEMBLY (RH) Not Available Price: |
| 6 |
94-3133 |
NUT-W/WASHER Price: $1.04 |
| 7 |
711-3053 |
TIE ROD Not Available Price: |
| 7 |
94-3127 |
DISCONTINUED Price: Call Us |
| 8 |
532104757 |
CAP.HUB.FRONT.LT.BLACK This part replaces 532175039. Price: $3.99 |
| 8 |
923-3015 |
BALL JOINT Not Available This part replaces 723-3015. Price: |
| 8 |
94-3134 |
NUT Price: $4.71 |
| 9 |
532420531 |
TIRE.18X9.5-8 TURF SAVER Price: $79.99 |
| 9 |
923-3016 |
BALL JOINT This part replaces 723-3016. Price: $21.06 |
| 9 |
94-3128 |
CASE-TIMING, RIGHT Price: $90.91 |
| 10 |
710-3111 |
SCREW 3/8-16 ? 1-1/2 Not Available Price: |
| 11 |
532106108 |
RIM.ASM.8X7.REAR.SILVER This part replaces 532138337. Price: $99.99 |
| 12 |
711-3048 |
PIN-STEER PIVOT Not Available Price: |
| 13 |
714-0111 |
Pin, Cotter, 3/32 Dia x 1.0 Lg Price: $4.20 |
| 14 |
716-3002 |
Ring, Retaining Price: Call Us |
| 15 |
736-0921 |
Washer, Lock, 1/2 Dia Price: $3.90 |
| 16 |
712-3012A |
HEX NUT This part replaces 712-3012. Price: $11.49 |
| 17 |
736-3027 |
FLAT WASHER Not Available Price: |
| 18 |
710-3043 |
BOLT, 1/2 x 3/4 TYPE 5 Not Available Price: |
| 19 |
712-3011 |
HEX NUT Not Available Price: |
| 20 |
914-3001 |
Cotter Pin, .125 x 1.5 This part replaces 714-3001. Price: $3.23 |
| 21 |
710-1039 |
Screw, Hex Cap 3/8-24 x 1.0 GR8 This part replaces 710-0152. Price: $4.02 |
| 22 |
736-3039 |
Washer, Flat, .406 x 1.5 x .112 Thk Price: $4.42 |
| 23 |
719-3065 |
STEERING ARM Not Available Price: |
| 24 |
710-3083 |
Screw, Hex Cap, 5/16-18 x 1.38 Lg GR5 Price: $3.94 |
| 25 |
712-3009 |
Nut, Hex Center Lock, 5/16-18 GR5 Price: $5.99 |
