| Ref | Part Number | Description |
|---|
| 1 |
04193051 |
WMT, STEERING HANDLE Price: $101.95 |
| 2 |
04257400 |
GRIP, HANDLEBAR 15" FOAM Price: $14.45 |
| 3 |
05710200 |
RG-RTNG-EXT .500X.042 (E) Price: $0.95 |
| 4 |
03943800 |
DAMPER, STABILUS Price: $37.45 |
| 5 |
03652200 |
STUD- BALL Price: $3.45 |
| 6 |
06500809 |
NUT,NYL-FLG .31-18 GF ZCC This part replaces 06545400. Price: $1.45 |
| 7 |
04197651 |
WMT, STEERING SHAFT Price: $54.45 |
| 8 |
07400122 |
SCR-TAP .25-20X.50 HWH ZCC This part replaces 07400034. Price: $0.45 |
| 9 |
06400005 |
WSHR-WAVE .50X.75X.015 .13FRHT Price: $2.45 |
| 10 |
05511000 |
BSHG-FLG .500X.750X.625X.937 Price: $10.45 |
| 11 |
04192851 |
WMT, LOWER CONTROL ARM Price: $71.95 |
| 12 |
05500932 |
BSHG, ECCENTRIC .328X.750X.970 Price: $1.95 |
| 13 |
06500726 |
NUT,NYL-FLG .38-16 GF ZCC This part replaces 06545500. Price: $1.45 |
| 14 |
04199451 |
WMT, LOWER CONTROL RH Price: $71.95 |
| 15 |
05501017 |
BSHG-FLG, .625X.75X.450X.875 Price: $7.45 |
| 16 |
04193500 |
SPACER, .375X.625X.970 (PM) Price: $0.95 |
| 17 |
04192951 |
WMT, UPPER CONTROL ARM Price: $39.45 |
| 18 |
07500131 |
CAP PLUG, SQ 3/4-14-20 RIBBED Price: $3.45 |
| 19 |
05901804 |
BLT, HEX .31-18X1.75 G5 ZCC This part replaces 05957400. Price: $2.95 |
| 20 |
05901612 |
BLT, HEX .38-16X1.75F G5 ZCC This part replaces 05974000. Price: $2.95 |
| 21 |
03787100 |
ALIGNABALL, 5/16 RH THREAD Price: $16.45 |
| 22 |
05901701 |
BLT-HEX .31-18X1.00 G5 ZCC This part replaces 05946900. Price: $1.45 |
| 23 |
06500910 |
NUT-JAM .375-16 G2 ZCC This part replaces 06535900. Price: $0.95 |
| 24 |
03956251 |
WMT, STEERING STOP Price: $152.95 |
| 25 |
06200309 |
BLT, RHSSN.31-18X.750 G5 ZCC This part replaces 06220800. Price: $2.45 |
| 26 |
06500923 |
NUT-JAM .312-24 ZCC This part replaces 06536700. Price: $0.95 |
| 27 |
04197300 |
WIREFORM, STEERING LINK Price: $25.45 |
| 28 |
05901702 |
BLT,HEX .38-16X.75 G5 ZCC This part replaces 05959400. Price: $1.45 |
| 29 |
04208000 |
SPACER, .328X.500X.625 Price: $3.45 |
| 30 |
05901805 |
BLT- HEX .31-18X2.00 G5 ZCC This part replaces 05957200. Price: $1.45 |
| 31 |
03759351 |
PLATE, DAMPER RH Price: $12.45 |
| 32 |
04147200 |
BSHG-FLG .316X.430X.225X.750 Price: $3.45 |
| 33 |
07001816 |
BLT, SERHFWH .375-16X1.25 ZCC This part replaces 07050000. Price: $3.95 |
| 34 |
06200307 |
BLT, RHSN .25-20X.750 G5 ZCC This part replaces 06219900. Price: $0.95 |
| 35 |
06500813 |
NUT,NYL-FLG .25-20 GF ZCC This part replaces 06500012. Price: $1.45 |
| 36 |
04199551 |
WMT, STEERING HANDLE LH Price: $84.95 |
| 37 |
03766051 |
PLATE, DAMPER (LH) Price: $9.45 |
| 38 |
06500914 |
NUT-LK-CTR-JAM .375-16 GB ZCC This part replaces 06537200. Price: $0.95 |
