| Ref | Part Number | Description |
|---|
| 1 |
408007 |
IMPELLER BELT Price: Call Us |
| 1 |
98-7342 |
INSIDE ARM ASM Price: $693.49 |
| 2 |
3290-384 |
PIN-LYNCH Price: $18.43 |
| 2 |
419744 |
TRACTION BELT Price: Call Us |
| 3 |
325-20 |
SCREW-HH Price: $6.29 |
| 3 |
423723X479 |
IDLER ARM BRACKET Price: Call Us |
| 4 |
180523 |
IDLER PULLEY Price: Call Us |
| 4 |
69-8790-01 |
PLATE-REINFORCING Price: $21.41 |
| 5 |
426589 |
NUT 5/16-18 Price: Call Us |
| 5 |
98-4435 |
RUBBER MOUNT ASM This part replaces 69-9700. Price: $102.40 |
| 6 |
74780524 |
SCREW 5/16-18 X 1 .50 Price: Call Us |
| 7 |
32128-23 |
NUT-HF Price: $1.51 |
| 7 |
423990X479 |
IDLER BRACKET Price: Call Us |
| 8 |
32128-45 |
NUT-HHF Price: $7.67 |
| 8 |
428867 |
SCREW 5/16-18 X .625 Price: Call Us |
| 9 |
30-8770 |
WASHER Price: $3.43 |
| 9 |
424297 |
SHOULDER BOLT 5/16-18 X .500 Price: Call Us |
| 10 |
69-7170-01 |
CLEVIS Price: $307.49 |
| 10 |
751153 |
NUT 5/16-18 NYLOCK Price: Call Us |
| 11 |
187786 |
TRACTION IDLER ARM Price: Call Us |
| 11 |
3233-29 |
SCREW-CARR Price: $8.69 |
| 12 |
180522 |
TRACTION PULLEY Price: Call Us |
| 12 |
3233-28 |
SCREW-CARR Price: $5.56 |
| 13 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 13 |
74780520 |
SCREW 5/16-18 X 1 .00 Price: Call Us |
| 14 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 14 |
59289 |
WASHER Price: Call Us |
| 15 |
71-2610 |
SHAFT-PIVOT, DECK Price: $251.69 |
| 15 |
73800500 |
NUT 5/16-18 Price: Call Us |
| 16 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 16 |
851084 |
SCREW 3/8-24 X 1.375 Price: Call Us |
| 17 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 17 |
400026 |
WASHER Price: Call Us |
| 18 |
426491 |
PULLEY ENG IMPELLER Price: Call Us |
| 18 |
98-1461-01 |
BAR-LIFT, LH Price: $504.26 |
| 19 |
426490 |
PULLEY ENG TRACTION Price: Call Us |
| 19 |
98-7343 |
OUTSIDE ARM ASM Price: $792.23 |
| 20 |
13-5009 |
LH DECK ASM Price: $3,588.60 |
| 20 |
74610516 |
SCREW 5/16-18 X 1 .00 Price: Call Us |
| 21 |
10040500 |
LOCKWASHER 5/16 Price: Call Us |
| 21 |
69-6730-01 |
SKID ASM Price: $264.77 |
| 22 |
155452 |
BELT GUIDE Price: Call Us |
| 22 |
3233-9 |
SCREW-CARR Price: $1.97 |
| 23 |
11050500 |
LOCKWASHER 5/16 Price: Call Us |
| 23 |
323-15 |
SCREW-HH Price: $1.53 |
| 24 |
5-0838 |
WASHER Price: $1.09 |
| 25 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 26 |
327-17 |
SCREW-HH Price: $8.50 |
| 27 |
106-6753 |
DECAL-DANGER, CE This part replaces 93-7815. Price: $8.07 |
| 27 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 28 |
93-4241 |
SPACER-BEARING, INNER Price: $26.72 |
| 29 |
120-5378 |
BEARING-BALL This part replaces 93-4237. Price: $13.84 |
| 31 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 32 |
98-7300-01 |
FORK-CASTOR ASM Price: $382.91 |
| 33 |
69-6860 |
WASHER-THRUST Price: $3.15 |
| 34 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 35 |
69-1510 |
SPACER Price: $4.48 |
| 36 |
95-0819 |
DECAL-BELT ROUTING, LEFT Price: $16.94 |
| 37 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 37 |
93-7824 |
DECAL-DANGER Price: $17.85 |
| 38 |
95-0818 |
DECAL-TORQUE Price: $22.79 |
| 39 |
106-8120 |
DECAL-DANGER, CE This part replaces 93-7273. Price: $9.83 |
| 39 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 40 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 42 |
93-4243 |
TIRE Price: $54.25 |
| 43 |
93-5980 |
HUB Price: $67.14 |
| 44 |
95-2741 |
RIM-WHEEL, HALF Price: $25.01 |
| 45 |
93-4244 |
TUBE-INNER (W/VALVE) Price: $14.42 |
| 46 |
93-4242 |
PLATE Price: $11.21 |
| 47 |
32128-16 |
NUT-HHF Price: $0.54 |
| 48 |
133-8095 |
DECAL-CE This part replaces 93-7252. Price: $3.73 |
| 49 |
32144-11 |
SCREW-THD ROLL, HWH This part replaces 32104-31. Price: $6.99 |
| 50 |
94-9822-01 |
BAR-GUARD, WING INNER This part replaces 94-9822. Price: $76.20 |
