| Ref | Part Number | Description |
|---|
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532140840. Price: $219.99 |
| 1 |
60-6230 |
SCREW-HH Price: $4.80 |
| 1 |
703-1796 |
FENDER Not Available Price: |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
60-6200 |
ADAPTER Price: $537.89 |
| 2 |
703-1797 |
RUNNING BOARD - LH Not Available Price: |
| 3 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 3 |
70-1240 |
PLUG ASM Price: $51.46 |
| 3 |
703-1798 |
RUNNING BOARD - RH Not Available Price: |
| 4 |
710-0528 |
Screw, Hex Cap, 5/16-18 X 1.25 Lg GR5 Price: $3.90 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
712-3009 |
Nut, Hex Center Lock, 5/16-18 GR5 Price: $5.99 |
| 5 |
99-8708 |
O-RING This part replaces 60-6180. Price: $21.71 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
63-4390 |
BEARING-NEEDLE Price: $51.67 |
| 6 |
710-0759 |
SCREW 5/16-18 x .625 GR5 Not Available Price: |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
60-6350 |
DISCONTINUED Price: Call Us |
| 7 |
912-0107 |
Hex L-Nut 1/4-20 Thd This part replaces 712-0107. Price: $4.06 |
| 8 |
33-4970 |
DISCONTINUED Price: Call Us |
| 8 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 8 |
817000616 |
SCREW 3/8-16X1 This part replaces 817490616. Price: $5.99 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
60-6040 |
DISCONTINUED Price: Call Us |
| 9 |
736-0173 |
Washer, Flat, .281 X .73 X .063 Thk Price: $3.76 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532155925. Price: $17.99 |
| 10 |
60-6130 |
GASKET Price: $19.03 |
| 10 |
710-3013 |
Screw, Hex, Cap, 1/4-20 X .50 Lg GR5 Price: $4.02 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT This part replaces 532120068. Price: $6.99 |
| 11 |
735-3030 |
FOOT PAD (RH) Not Available This part replaces 703-1960. Price: |
| 11 |
95-6050 |
PIN-DOWEL Price: $2.59 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 12 |
60-6030 |
KIT Price: $1,481.34 |
| 12 |
735-3031 |
FOOT PAD (LH) Not Available Price: |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
60-6310 |
KEY Price: $8.97 |
| 13 |
703-1887 |
SUPPORT ASSEMBLY, SEAT Not Available Price: |
| 14 |
60-6020 |
CAMPLATE Price: $784.96 |
| 14 |
736-0275 |
FLAT WASHER This part replaces 7360275. Price: $5.99 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 15 |
60-6120 |
COVER-SEAL Price: $17.87 |
| 16 |
104-4861 |
SEAL-SHAFT This part replaces 42-2720. Price: $28.44 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 17 |
60-6250 |
WASHER Price: $9.70 |
| 18 |
532124238 |
CAP SPRING Price: $4.99 |
| 18 |
60-6110 |
BEARING Price: $47.19 |
| 19 |
60-6000 |
HOUSING Price: $924.77 |
| 20 |
60-5990 |
RACE Price: $51.48 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532153236. Price: $2.99 |
| 21 |
60-6190 |
O-RING Price: $3.76 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 22 |
60-6210 |
COVER Price: $12.31 |
| 23 |
60-6010 |
COVER-TRUNNION Price: $11.26 |
| 24 |
60-6330 |
SCREW Price: $6.91 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
76-7010 |
RING-RETAINING This part replaces 60-6260. Price: $3.66 |
| 26 |
105-3331 |
SEAL-SHAFT This part replaces 60-6300. Price: $35.63 |
| 27 |
60-6240 |
WASHER Price: $15.20 |
| 28 |
60-6270 |
RING Price: $2.40 |
| 29 |
76-6950 |
RACE-THRUST This part replaces 60-6160. Price: $25.65 |
| 30 |
76-6960 |
BEARING-THRUST This part replaces 60-6170. Price: $23.23 |
| 31 |
60-6140 |
SHAFT Price: $420.62 |
| 32 |
68-6460 |
RELIEF VALVE KIT Price: $545.19 |
| 33 |
60-5980 |
O-RING Price: $1.95 |
| 35 |
60-6320 |
KEY Price: $5.45 |
| 36 |
60-6220 |
SCREW-HH Price: $5.33 |
| 37 |
60-6060 |
CARTRIDGE Price: $31.94 |
| 38 |
60-6080 |
RING Price: $1.46 |
| 39 |
60-6090 |
SPRING Price: $8.73 |
| 40 |
60-6070 |
POPPET Price: $15.52 |
| 42 |
33-4990 |
POPPET Price: $11.08 |
| 43 |
39-2140 |
SPRING Price: $24.34 |
| 44 |
39-2130 |
RETAINER-SPRING Price: $23.51 |
| 45 |
237-114 |
DISCONTINUED Price: Call Us |
| 46 |
60-5950 |
WASHER Price: $11.55 |
| 47 |
60-6150 |
BEARING Price: $37.91 |
| 48 |
60-6050 |
BEARING Price: $50.76 |
