| Ref | Part Number | Description |
|---|
| 1 |
194176X428 |
Control Bar Price: Call Us |
| 1 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 2 |
194788 |
Rope Guide Price: Call Us |
| 2 |
98-4517 |
AIR CLEANER ASM Price: $272.15 |
| 3 |
851201X004 |
Engine Washer Price: Call Us |
| 3 |
93-6692 |
DISCONTINUED Price: Call Us |
| 4 |
194180X479 |
Upper Handle Price: Call Us |
| 4 |
48-7430 |
PRECLEANER Price: $50.85 |
| 5 |
151590X479 |
Lower Handle Price: Call Us |
| 5 |
98-4578-03 |
BRACKET-FILTER, FUEL Price: $35.38 |
| 6 |
132004 |
Nut, Hex Price: Call Us |
| 6 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 7 |
110-3257 |
HOSE-FUEL This part replaces 63-7630. Price: $17.26 |
| 7 |
191574 |
Handle Bolt 5/16-18 x 1-3/4 Price: Call Us |
| 8 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 8 |
86899X004 |
Up-Stop Bracket Price: Call Us |
| 9 |
189241 |
Hex Washer Head Screw #10-24 x 1/2 Price: Call Us |
| 9 |
32128-33 |
NUT-HF Price: $0.25 |
| 10 |
162778 |
Engine Zone Control Cable Price: Call Us |
| 10 |
98-4525 |
BRACKET-CLEANER, AIR Price: $52.87 |
| 11 |
322-4 |
SCREW-HH Price: $0.35 |
| 11 |
750634 |
Screw Price: Call Us |
| 12 |
66-2750 |
DISCONTINUED Price: Call Us |
| 12 |
664-26 |
Wire Tie Price: Call Us |
| 13 |
104-0086 |
CABLE-BATTERY, POSITIVE Price: $78.07 |
| 13 |
51793 |
Hairpin Cotter Price: Call Us |
| 14 |
189713X428 |
Knob, Handle Price: Call Us |
| 14 |
323-9 |
SCREW-HH Price: $1.29 |
| 15 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 15 |
412277X428 |
Discharge Guard Price: Call Us |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
850263 |
Helical Lock Washer 3/8 Price: Call Us |
| 17 |
138-6335 |
RETAINER-BATTERY This part replaces 66-2490. Price: $10.49 |
| 17 |
73800400 |
Locknut, Hex 1/4-20 Price: Call Us |
| 18 |
851074 |
Hardened Washer Price: Call Us |
| 18 |
94-7343 |
BASE-BATTERY Price: $118.61 |
| 19 |
411832 |
Torsion Spring Price: Call Us |
| 19 |
93-6668 |
DECAL-BATTERY Price: $18.99 |
| 20 |
145106 |
Blade, 20" Price: Call Us |
| 20 |
93-7276 |
DECAL-DANGER Price: $15.13 |
| 21 |
32128-20 |
NUT-HF Price: $0.99 |
| 21 |
88602 |
Hinge Deflector Price: Call Us |
| 22 |
150215 |
Hinge Rod Price: Call Us |
| 22 |
98-4576-03 |
BRACKET-RESERVOIR, WATER Price: $43.21 |
| 23 |
189240 |
Rear Deflector Price: Call Us |
| 23 |
321-5 |
SCREW-HH Price: $0.22 |
| 24 |
407494X005 |
Wheel Adjusting Bracket Price: Call Us |
| 24 |
93-9164 |
INDICATOR-MINI Price: $55.24 |
| 25 |
850977 |
Blade Adapter Price: Call Us |
| 25 |
98-4518-03 |
BRACKET-CLEANER, AIR Price: $75.61 |
| 26 |
170345X479 |
Handle Bracket Assembly, RH Price: Call Us |
| 26 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 27 |
170346X479 |
Handle Bracket Assembly, LH Price: Call Us |
| 27 |
94-1416 |
ADAPTER-INDICATOR Price: $11.87 |
| 28 |
61537 |
Washer, Flat Price: Call Us |
| 28 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 29 |
401629 |
Spacer Price: Call Us |
| 29 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 30 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 31 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 31 |
401621X004 |
Selector Spring Price: Call Us |
| 32 |
108-0638 |
BOTTLE-OVERFLOW This part replaces 104-9318. Price: $33.20 |
| 32 |
87877 |
Selector Knob Price: Call Us |
| 33 |
401179X004 |
Axle Arm Assembly Price: Call Us |
| 33 |
98-4509 |
HOSE-CLEANER, AIR Price: $97.00 |
| 34 |
401630 |
Belleville Washer Price: Call Us |
| 34 |
98-9305 |
WATER / FUEL FILTER ASM Price: $116.51 |
| 35 |
353-783 |
FITTING-STR Price: $29.05 |
| 35 |
401638 |
Shoulder Bolt Price: Call Us |
| 36 |
193931X427 |
Wheel and Tire Assembly Price: Call Us |
| 36 |
322-6 |
SCREW-HH Price: $0.45 |
| 37 |
409148 |
Nut, Hex Price: Call Us |
| 38 |
110-4107 |
HOSE-FUEL This part replaces 95-4275. Price: $7.77 |
| 38 |
150406 |
Hex Head Thread Rolling Screw 3/8-16 x 1-1/8 Price: Call Us |
| 39 |
414790 |
Lawn Mower Housing Price: Call Us |
| 40 |
851084 |
Hex Head Screw 3/8-24 x 1-3/8 Grade 8 Price: Call Us |
| 41 |
149741 |
Thread Cutting Screw 5/16-18 x 3/4 Price: Call Us |
| 42 |
404763 |
Danger Decal Price: Call Us |
| 43 |
73930500 |
Locknut, Hex 3/8-16 Price: Call Us |
| 55 |
700829X479 |
Baffl e, Front Price: Call Us |
| 58 |
128415 |
Pop Rivet Price: Call Us |
| 58 |
193732 |
Operator’s Manual, English Price: Call Us |
| 58 |
193735 |
Operator's Manual, Spanish Price: Call Us |
