| Ref | Part Number | Description |
|---|
| 8 |
165866 |
Rod Shift Fend. Price: Call Us |
| 9 |
179334 |
Clutch Electric Price: Call Us |
| 10 |
76020416 |
Pin Cotter 1/8 x 1 Price: Call Us |
| 10 |
99-8300 |
CRANKCASE ASM Price: $1,821.17 |
| 14 |
10040400 |
Washer Lock Hvy 1/4 Price: Call Us |
| 15 |
74490544 |
Bolt Hex Flghd 5/16-18 Gr. 5 Price: Call Us |
| 16 |
73800500 |
Nut Lock Hex W/Ins. 5/16-18 unc Price: Call Us |
| 17 |
126197X |
Washer 1-1/2 OD x 15/32 ID x.250 Price: Call Us |
| 19 |
73800600 |
Nut Lock Hex W/Wsh 3/8-16 unc Price: Call Us |
| 20 |
173937 |
Bolt Hex 7/16-20 x 4 x Gr. 5-1.5 Price: Call Us |
| 20 |
98-9398 |
CAP-SEALING Price: $6.08 |
| 21 |
106933X |
Knob Price: Call Us |
| 22 |
169498 |
Rod, Brake Price: Call Us |
| 23 |
190736 |
Bracket Anti-Rotation Price: Call Us |
| 24 |
73350600 |
Nut, Hex Jam 3/8-16 unc Price: Call Us |
| 25 |
106888X |
Spring, Brake Rod Price: Call Us |
| 26 |
19131316 |
Washer Price: Call Us |
| 27 |
76020412 |
Pin Cotter 1/8 x 3/4 CAD. Price: Call Us |
| 28 |
175765 |
Rod, Parking Brake Price: Call Us |
| 29 |
71673 |
Knob Brake Parking Price: Call Us |
| 30 |
169592 |
Bracket, Transaxle Price: Call Us |
| 30 |
98-7539 |
CAP-SEALING Price: $6.44 |
| 32 |
74760512 |
Bolt Hex Hd 5/16-18 unc x 3/4 Price: Call Us |
| 34 |
175578 |
Shaft, Foot Pedal Price: Call Us |
| 35 |
120183X |
Bearing, Nylon Price: Call Us |
| 36 |
19211616 |
Washer Price: Call Us |
| 37 |
1572H |
Pin, Roll Price: Call Us |
| 38 |
179114 |
Pulley, Composite Price: Call Us |
| 39 |
72110622 |
Bolt Rdhd 3/8-16 unc x 2-3/4 Gr. 5 Price: Call Us |
| 40 |
98-9687 |
PLUG This part replaces 98-7540. Price: $2.86 |
| 41 |
175556 |
Keeper, Belt Idler Flat Price: Call Us |
| 47 |
127783 |
Pulley, Idler, V-Groove Price: Call Us |
| 48 |
154407 |
Bellcrank Clutch Grnd Drw Stl Price: Call Us |
| 49 |
123205X |
Retainer, Belt Price: Call Us |
| 50 |
72110612 |
Bolt Price: Call Us |
| 50 |
99-8347 |
JOINT-PIPE, DRAIN Price: $52.64 |
| 51 |
73680600 |
Nut Crownlock 3/8-16 unc Price: Call Us |
| 52 |
73680500 |
Nut, Crownlock 5/16-18 unc Price: Call Us |
| 53 |
105710X |
Link, Clutch Price: Call Us |
| 55 |
105709X |
Spring, Return, Clutch Price: Call Us |
| 56 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
| 57 |
140294 |
V-Belt, Ground Drive Price: Call Us |
| 59 |
169691 |
Keeper, Center Span Price: Call Us |
| 60 |
98-9597 |
PLUG Price: $17.66 |
| 61 |
17120614 |
Screw 3/8-16 x .875 Price: Call Us |
| 62 |
123533X |
Cover, Pedal Price: Call Us |
| 63 |
174607 |
Pulley, Engine Price: Call Us |
| 65 |
10040700 |
Washer Price: Call Us |
| 66 |
154778 |
Keeper Belt Engine Price: Call Us |
| 69 |
142432 |
Screw Hex Wsh Hi-Lo 1/4-1/2 unc Price: Call Us |
| 70 |
98-7487 |
PLUG Price: $3.18 |
| 71 |
169183 |
Strap Torque LH Price: Call Us |
| 73 |
169182 |
Strap Torque RH Price: Call Us |
| 74 |
137057 |
Spacer, Axle Price: Call Us |
| 75 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 76 |
12000001 |
E-Ring Price: Call Us |
| 77 |
123583X |
Key, Square Price: Call Us |
| 78 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 80 |
98-9379 |
PLUG-EXPANSION This part replaces 98-7489. Price: $0.76 |
| 81 |
165596 |
Shaft Assy. Cross Taper Price: Call Us |
| 82 |
165711 |
Spring Torsion Price: Call Us |
| 83 |
19171216 |
Washer 17/32 x 3/4 x 16 Ga. Price: Call Us |
| 84 |
169594 |
Link Transaxle Price: Call Us |
| 89 |
188309X428 |
Console, Shift Price: Call Us |
| 90 |
98-9668 |
PLUG-EXPANSION Price: $2.17 |
| 95 |
170201 |
Rod Bypass Price: Call Us |
| 96 |
4497H |
Retainer Spring 1" Zinc/Cad Price: Call Us |
| 100 |
98-9375 |
PIN-STRAIGHT Price: $0.41 |
| 110 |
98-9377 |
PIN-STRAIGHT Price: $1.00 |
| 116 |
72140608 |
Bolt RDHD SQNK 3/8-16 unc x 1 Price: Call Us |
| 120 |
105-3795 |
PIN-STRAIGHT Price: $0.99 |
| 120 |
73900600 |
Nut Lock Flg 3/8-16 unc Price: Call Us |
| 130 |
98-9387 |
PIN-PIPE Price: $2.92 |
| 140 |
98-9539 |
PIN-PIPE Price: $1.15 |
| 150 |
175456 |
Spacer Retainer Price: Call Us |
| 150 |
98-9599 |
PLUG Price: $6.08 |
| 151 |
19133210 |
Washer 13/32 x 2 x 10 Ga. Price: Call Us |
| 156 |
166002 |
Washer 5/16 ID x 1.0 x .125 Price: Call Us |
| 158 |
165589 |
Bracket Shift Mount Price: Call Us |
| 159 |
183900 |
Hub Shift Price: Call Us |
| 160 |
98-9630 |
PIN-SPRING, START Price: $1.47 |
| 161 |
72140406 |
Bolt Rdhd Sqnk 1/4-20 x 3/4 Gr. 5 Price: Call Us |
| 162 |
73680400 |
Nut Crownlock 1/4-20 unc Price: Call Us |
| 163 |
74780416 |
Bolt Hex Fin 1/4-20 unc x 1 Gr. 5 Price: Call Us |
| 164 |
19091210 |
Washer 9/32 x 3/4 x 10 Ga. Price: Call Us |
| 165 |
165623 |
Bracket Pivot Lever Price: Call Us |
| 166 |
17490510 |
Screw 5/16-18 x 5/8 Price: Call Us |
| 168 |
165492 |
Bolt Shoulder 5/16-18 x .561 Price: Call Us |
| 169 |
165580 |
Plate Fastener Cross Shf. Price: Call Us |
| 170 |
98-9675 |
PLUG Price: $8.54 |
| 180 |
98-9656 |
BUSHING-GOVERNOR, GEAR Price: $29.04 |
| 190 |
98-7507 |
PLUG Price: $2.64 |
| 197 |
169613 |
Nyliner Snap-in 5/8 ID Price: Call Us |
| 198 |
169593 |
Washer Nyl 7/8 ID x .105" Price: Call Us |
| 199 |
169612 |
Bolt Shoulder 5/16-18 unc Price: Call Us |
| 200 |
72140508 |
Bolt Rdhd Sqnk 5/16-18 unc x 1 Price: Call Us |
| 200 |
98-7428 |
GASKET Price: $0.68 |
| 202 |
72110614 |
Bolt Carr Sh 3/8-16 x 1-3/4 Gr. 5 Price: Call Us |
| 210 |
98-7509 |
O-RING Price: $4.31 |
| 212 |
145212 |
Nut Hex Flange Lock Price: Call Us |
| 220 |
99-3447 |
PLUG Price: $3.11 |
| 225 |
106-7056 |
GASKET Price: $1.48 |
| 230 |
99-8363 |
BOLT-FLANGE Price: $1.66 |
| 240 |
98-7654 |
GASKET Price: $8.84 |
| 254 |
17000616 |
Screw 3/8-16 x 1 Price: Call Us |
