| Ref | Part Number | Description |
|---|
| 1 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 1 |
603-0023 |
PEDESTAL A Not Available Price: |
| 2 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 2 |
712-3044 |
NUT, 1/4 WING Not Available Price: |
| 3 |
322-10 |
SCREW-HH Price: $0.70 |
| 3 |
736-0463 |
Washer, Flat, .251 X .62 X .052 Thk Price: $3.91 |
| 4 |
32105-21 |
SCREW-HH Price: $1.09 |
| 4 |
931-3115A |
SIDE PANEL (LH) Not Available This part replaces 731-3115. Price: |
| 5 |
931-3116 |
SIDE-PANEL (RH) Not Available This part replaces 731-3116. Price: |
| 6 |
29-6162 |
SWITCH-MICRO Price: $107.13 |
| 6 |
759-3629 |
KIT-DECAL Not Available Price: |
| 7 |
710-0376 |
Screw, 5/16-18 X 1 Znd Hex Hd Cap This part replaces 710-3002. Price: $3.66 |
| 7 |
75-4130 |
PLATE-SWITCH Price: $13.26 |
| 8 |
76-9430-03 |
SPRING-EXTENTION This part replaces 76-9430. Price: $28.14 |
| 8 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 9 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 9 |
703-0008 |
GRILLE HOUSING RETAINER Not Available Price: |
| 10 |
322-7 |
SCREW-HH Price: $0.89 |
| 10 |
731-3099 |
GRILLE INSERT Not Available Price: |
| 11 |
251-259 |
BEARING-BALL Price: $13.67 |
| 11 |
931-3102 |
GRILLE LENS This part replaces 731-3102. Price: $36.19 |
| 12 |
75-5470 |
SPACER-BEARING Price: $3.06 |
| 13 |
32144-22 |
SCREW Price: $0.75 |
| 13 |
703-1829-0499 |
HOOD HINGE ASSEMBLY (CUB BEIGE) Not Available This part replaces 703-1829. Price: |
| 14 |
710-3214 |
STUD-DOUBLE ENDED Not Available Price: |
| 15 |
75-4080-03 |
PLATE-TRACTION ASM This part replaces 75-4080. Price: $56.27 |
| 15 |
912-0107 |
Hex L-Nut 1/4-20 Thd This part replaces 712-0107. Price: $4.06 |
| 16 |
703-1856 |
PLATE, HINGE Not Available Price: |
| 16 |
85-9900-03 |
PLATE-ANCHOR, SPRING This part replaces 85-9900. Price: $21.09 |
| 17 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 17 |
710-0748 |
SCREW #12-14 x .500 Not Available Price: |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 18 |
931-3089B |
HOOD Not Available This part replaces 731-3089A. Price: |
| 19 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 19 |
979-3536 |
LABEL-CCC SCRIPT Not Available This part replaces 779-3536. Price: |
| 20 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 20 |
710-3217 |
Screw, Truss Hd, #8-32 X .38 Lg Price: $5.94 |
| 21 |
732-3063A |
Clip, Hood Latch Price: Call Us |
| 21 |
92-2581 |
DISCONTINUED Price: Call Us |
| 22 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 22 |
736-0310 |
Washer, Flat, .16 X .38 X .045 Thk Price: $3.50 |
| 23 |
76-8640 |
STUD-TRACTION Price: $23.60 |
| 23 |
912-3072 |
HEX NUT KEPS #8-32 Not Available This part replaces 712-3072. Price: |
| 24 |
3296-9 |
NUT-HEX Price: $0.25 |
| 24 |
911-3296 |
LATCH PIN Not Available This part replaces 711-3296. Price: |
| 25 |
710-0286 |
Screw, Phillips Hd Truss Mach, 1/4-20 X .50 Lg Price: $3.86 |
| 25 |
75-4100-03 |
CONTROL-PUMP This part replaces 75-4100. Price: $198.81 |
| 26 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 26 |
703-1955 |
BRACKET ASSY, LH PANEL MTG Not Available Price: |
| 27 |
703-2162-0499 |
PANEL SCREEN (RH) (CUB BEIGE) Not Available This part replaces 703-2162. Price: |
| 27 |
85-9910 |
EYEBOLT Price: $28.77 |
| 28 |
703-2163 |
PANEL SCREEN (LH) Not Available Price: |
| 29 |
726-0175 |
CLAMP Not Available This part replaces 726-3014. Price: |
| 502110703 |
502110703 |
CRANKCASE Price: $149.61 |
| 503230005 |
503230005 |
WASHER 6.5X11 Price: $2.99 |
