| Ref | Part Number | Description |
|---|
| 1 |
115-5304 |
CAP-FUEL This part replaces 93-3101. Price: $26.87 |
| 2 |
105-8266 |
TANK-FUEL This part replaces 92-7189. Price: $466.98 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 3 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 4 |
63-8410 |
WASHER Price: $1.76 |
| 5 |
2412-41 |
CLAMP-R Price: $4.82 |
| 6 |
323-6 |
SCREW-HH Price: $0.66 |
| 7 |
3256-63 |
WASHER-FLAT Price: $0.25 |
| 8 |
83-2200 |
NUT Price: $9.81 |
| 9 |
33113-012 |
SCREW-HH This part replaces 48-7610. Price: $0.71 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 10 |
2412-94 |
CLAMP Price: $2.31 |
| 11 |
107-9296 |
HOSE-FUEL This part replaces 93-0116. Price: $24.69 |
| 11 |
587255001 |
CLUTCH. 5.0 PD. 2.5 OFFSET Price: $229.99 |
| 12 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 12 |
586899601 |
PULLEY.EXTENDED.SHAFT.GROUND Price: $29.99 |
| 13 |
94-2690 |
FILTER-FUEL This part replaces 83-1320. Price: $4.69 |
| 14 |
109-0304 |
HOSE-FUEL This part replaces 83-2040. Price: $1.99 |
| 15 |
532422804 |
TANK FUEL Price: $149.99 |
| 15 |
83-1390 |
VALVE-SHUT-OFF, FUEL Price: $55.01 |
| 16 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 Price: $14.99 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 28 |
587044860 |
HOSE.1/4".LOW.PERM.FUEL.LN.60" This part replaces 587044660. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 Price: $19.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 Price: $17.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606701 |
BOLT.HEX.7/16-20X5.GR5.GREEN Price: $7.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 117 |
532420828 |
VALVE FUEL RESERVE Price: $27.99 |
