| Ref | Part Number | Description |
|---|
| 1 |
532402949 |
BAIL.MZR.STD.ORANGE Price: $12.99 |
| 1 |
94-3145 |
SCREW-PULLEY Price: $9.84 |
| 2 |
74-8080 |
WASHER Price: $4.77 |
| 3 |
532174291 |
HANDLE.LOWER.BLACK This part replaces 532174110. Price: $32.99 |
| 3 |
94-3144 |
PULLEY-CRANKSHAFT Price: $766.47 |
| 4 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532194788. Price: $7.99 |
| 4 |
74-8100 |
GEAR-PINION Price: $58.79 |
| 5 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532132004. Price: $1.99 |
| 5 |
98-3833 |
GEAR - OIL PUMP This part replaces 74-8110. Price: $26.24 |
| 6 |
532191574 |
BOLT, HANDLE 5/16-18X1.75 Price: $5.99 |
| 6 |
74-8120 |
KEY-WOODRUFF Price: $3.36 |
| 7 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 7 |
94-3150 |
SCREW-HH Price: $1.50 |
| 8 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 8 |
74-7560 |
LOCKWASHER This part replaces 94-3151. Price: $0.67 |
| 9 |
532154132 |
BRACKET.ASM.HOUSING.EZ.MUL Price: $5.99 |
| 9 |
74-8140 |
COVER Price: $137.43 |
| 10 |
581825801 |
DOOR.MULCH.21".REAR.PUSH.GRAY This part replaces 532185589. Price: $11.99 |
| 10 |
74-8150 |
GASKET-COVER Price: $4.08 |
| 11 |
532183281 |
CABLE.ENGINE.ZONE.CONTROL Price: $14.99 |
| 11 |
94-3148 |
SEAL Price: $33.41 |
| 12 |
532750634 |
SCREW Price: $2.99 |
| 12 |
74-8170 |
BEARING SET (STD) Price: $208.01 |
| 13 |
532430034 |
BRACKET.UPSTOP.RT Price: $5.99 |
| 13 |
94-3141 |
DISCONTINUED Price: Call Us |
| 14 |
532182398 |
KNOB.HANDLE.PLASTIC.STAR.BLACK Price: $5.99 |
| 14 |
74-8230 |
SHAFT-CRANK Price: $3,552.00 |
| 15 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 15 |
74-8240 |
DISCONTINUED Price: Call Us |
| 16 |
74-8250 |
PIN This part replaces 74-7990. Price: $0.97 |
| 17 |
94-3149 |
GEAR-FLYWHEEL Price: $113.49 |
| 18 |
74-8270 |
DISCONTINUED Price: Call Us |
| 18 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 19 |
532401174 |
ARM.ASM.AXLE.5/9.POS. This part replaces 532406689. Price: $5.99 |
| 19 |
74-8280 |
SCREW-HH Price: $4.63 |
| 20 |
532401175 |
ARM.ASM.AXLE.5/9.POS.BZP This part replaces 532406690. Price: $5.99 |
| 20 |
74-8290 |
DISCONTINUED Price: Call Us |
| 21 |
532416860 |
SKIRT.REAR.21.PUSH This part replaces 532418655. Price: $11.99 |
| 21 |
74-8300 |
CLIP-PIN, PISTON Price: $2.96 |
| 22 |
532401621 |
SPRING.SELECTOR.5POS.BZP This part replaces 532406428. Price: $4.99 |
| 22 |
74-8310 |
PIN-PISTON Price: $24.33 |
| 23 |
581425601 |
DOOR.REAR.21.DOMED.498 This part replaces 532410603. Price: $10.99 |
| 23 |
94-3158 |
PISTON RING SET Price: $233.60 |
| 24 |
98-9965 |
DISCONTINUED Price: Call Us |
| 25 |
580915605 |
BRACKET.ASM.HAND.HW.21.LT.ORNG This part replaces 532413924. Price: $14.99 |
| 25 |
74-8360 |
CONNECTING ROD Price: $1,118.95 |
| 26 |
532446562 |
RP BRACKET.ASM.HAND.HW.21.RT.O This part replaces 532413925. Price: $19.99 |
| 27 |
74-8380 |
DISCONTINUED Price: Call Us |
| 28 |
74-8400 |
BOLT-ROD, CONNECTING Price: $23.09 |
| 29 |
532407494 |
BRACKET.ADJ.5POS.ADS This part replaces 532410594. Price: $3.99 |
| 29 |
74-8420 |
PISTON SET Price: $3,551.52 |
| 29 |
94-3157 |
PISTON SET Price: $3,570.53 |
| 30 |
532401629 |
SPACER.HEIGHT.ADJUSTER Price: $3.99 |
| 31 |
589482402 |
DEFLECTOR.CLIPPING.21.PUSH.BLK This part replaces 532185595. Price: $8.99 |
| 32 |
532401624 |
SPRING.SEL.EXT.21.DOMED.12/14 This part replaces 532410595. Price: $3.99 |
| 33 |
532087877 |
KNOB Price: $3.99 |
| 33 |
94-3152 |
SCREW-HH Price: $2.62 |
| 34 |
532401176 |
ARM.ASM.AXLE..LR.5/9.POS.BZP This part replaces 532410600. Price: $5.99 |
| 35 |
585802801 |
NUT.HEX.FL 5/16-18 TOP LCK BLK This part replaces 532426589. Price: $4.99 |
| 36 |
596203801 |
Hardware This part replaces 532401638. Price: $3.99 |
| 37 |
532401273 |
WHEEL.8X1.75.H3SPK.RAD3.GY.BB1 This part replaces 532410831. Price: $29.99 |
| 39 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT Price: $3.99 |
| 40 |
532411949 |
FRAME.BAG.21.REAR.DOMED.PUSH Price: $32.99 |
| 41 |
532088652 |
HINGE SCREW Price: $3.99 |
| 42 |
532405421 |
SPRING.LH.22.REAR.DOOR.EZ.EMPT Price: $3.99 |
| 43 |
532405423 |
SPRING.RH.22.REAR.DOOR.EZ. Price: $3.99 |
| 44 |
532184193 |
BOLT Price: $4.99 |
| 45 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 46 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532404763. Price: $3.99 |
| 47 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 48 |
532401177 |
ARM.ASM.AXLE..RR.5/9.POS.BZP This part replaces 532410601. Price: $5.99 |
| 49 |
585911001 |
WHEEL.12X1.75.CF H3SPK.RAD3.BB This part replaces 532410815. Price: $22.99 |
| 50 |
581002101 |
GBAG.24710010.BLK.GEN This part replaces 532194715. Price: $59.99 |
| 51 |
532147286 |
ROD.HINGE.COMBI-C Price: $6.99 |
| 53 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 54 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 55 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 57 |
532418373 |
ADAPTER.BLADE.W/KEY.25MM.CE This part replaces 532420097. Price: $9.99 |
| 58 |
532152124 |
TORSION SPRING Price: $5.99 |
| 61 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532409148. Price: $3.99 |
| 62 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 65 |
532088348 |
WASHER.FLAT.1/2 Price: $3.99 |
| 66 |
532197480 |
O-RING..070X.487.NEOPRENE Price: $3.99 |
| 67 |
532197991 |
CLIP.CABLE.BLK Price: $3.99 |
| 68 |
585161003 |
GRIP.HANDLE.FOAM.438MM This part replaces 532164265. Price: $4.99 |
| 73 |
532401630 |
WASHER.CURVED.CYLINDRICAL Price: $3.99 |
| 74 |
532125078 |
WASHER.ENGINE.BZP Price: $4.99 |
| 76 |
532410589 |
BAFFLE.REAR.PLASTIC.21.RD.ECON Price: $11.99 |
| 77 |
817411312 |
SCREW.HX.13X.750 Price: $4.99 |
