| Ref | Part Number | Description |
|---|
| 010 |
131-6557 |
ALTERNATOR ASM This part replaces 98-9474. Price: $443.05 |
| 10 |
73680600 |
SUB= 73690600 Price: Call Us |
| 020 |
98-9453 |
PULLEY-DYNAMO Price: $138.04 |
| 21 |
19131316 |
WASHER Price: Call Us |
| 030 |
98-7708 |
NUT Price: $7.76 |
| 040 |
98-7709 |
COLLAR Price: $8.79 |
| 050 |
107-0136 |
ROTOR ASM This part replaces 98-7710. Price: $268.62 |
| 51 |
17490608 |
SCREW LT Price: Call Us |
| 52 |
72140508 |
BOLT Price: Call Us |
| 53 |
19111610 |
WASHER Price: Call Us |
| 54 |
73680500 |
SUB= 73690500 Price: Call Us |
| 55 |
7901J |
SHOULDER BOLT T Price: Call Us |
| 56 |
73900400 |
NUT T Price: Call Us |
| 57 |
72140606 |
BOLT Price: Call Us |
| 58 |
73930600 |
LOCKNUT Price: Call Us |
| 59 |
74760616 |
BOLT Price: Call Us |
| 060 |
98-7711 |
COVER-BEARING Price: $7.32 |
| 60 |
74350512 |
BOLT LT Price: Call Us |
| 61 |
19091216 |
WASHER PM Price: Call Us |
| 62 |
10090400 |
SUB= 10040400 Price: Call Us |
| 63 |
73220400 |
SUB= 50675 Price: Call Us |
| 64 |
74760612 |
SUB= 74780612 Price: Call Us |
| 68 |
74760512 |
BOLT Price: Call Us |
| 070 |
98-7712 |
BEARING-BALL Price: $31.09 |
| 080 |
98-7713 |
WASHER-THRUST Price: $4.49 |
| 090 |
98-7714 |
FRAME-END, DRIVE Price: $311.88 |
| 100 |
98-7715 |
PLATE-RETAINER Price: $9.38 |
| 110 |
98-7716 |
SCREW-HEAD, ROUND Price: $0.91 |
| 120 |
98-7717 |
BOLT-THROUGH Price: $9.75 |
| 130 |
98-7718 |
BEARING-BALL Price: $34.82 |
| 140 |
98-7719 |
FRAME-END Price: $88.65 |
| 150 |
98-7720 |
COVER-END Price: $39.58 |
| 160 |
98-7721 |
RECTIFIER ASM Price: $486.45 |
| 170 |
98-7722 |
BUSHING-INSULATION Price: $28.44 |
| 180 |
98-7723 |
HOLDER-BRUSH Price: $52.72 |
| 190 |
98-7724 |
BRUSH Price: $12.41 |
| 200 |
98-7725 |
SPRING-BRUSH Price: $4.32 |
| 210 |
98-7726 |
SCREW-HEAD, ROUND Price: $0.42 |
| 220 |
98-7727 |
SCREW-HEAD, ROUND Price: $0.94 |
| 230 |
98-7728 |
SCREW-HEAD, ROUND Price: $0.70 |
| 240 |
98-7729 |
BOLT Price: $2.35 |
| 250 |
98-7730 |
NUT Price: $1.31 |
| 260 |
98-7731 |
BOLT Price: $3.94 |
| 270 |
98-7732 |
NUT Price: $1.45 |
