| Ref | Part Number | Description |
|---|
| 1 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 1 |
539130394 |
FUEL CAP, GENERIC This part replaces 539104962. Price: $27.99 |
| 2 |
37-9090 |
V BELT-3L, TRACTION Price: $13.99 |
| 2 |
539104409 |
LEFT TANK W/CUP HOLDER Price: $249.99 |
| 2 |
539104410 |
FUEL TANK RT Price: $279.99 |
| 3 |
539102502 |
STUD, 5/16C Price: $8.99 |
| 3 |
63-8140 |
PULLEY-IDLER Price: $47.94 |
| 4 |
32128-44 |
NUT Price: $2.69 |
| 4 |
539102650 |
HOSE BARB 90 DEGREE Price: $4.99 |
| 5 |
539912222 |
HOSE CLAMP Price: $2.99 |
| 5 |
83-7690-03 |
IDLER PULLEY STRAP This part replaces 83-7690. Price: $20.84 |
| 6 |
3230-22 |
SCREW-CARR Price: $1.99 |
| 6 |
539105382 |
FUEL LINE 30" This part replaces 539105281. Price: $11.99 |
| 7 |
3231-26 |
SCREW-CARR Price: $0.86 |
| 7 |
539104897 |
TANK SPACER Price: $7.99 |
| 8 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 8 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 9 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 9 |
539102845 |
SPRING Price: $2.99 |
| 10 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 10 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 11 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 11 |
83-9070 |
DISCONTINUED Price: Call Us |
| 12 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 12 |
596435501 |
Bolts This part replaces 539102335. Price: $3.99 |
| 13 |
539102679 |
FUEL VALVE Price: $49.99 |
| 13 |
83-8550 |
DISCONTINUED Price: Call Us |
| 14 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 14 |
539105280 |
HOSE 35" Price: $11.99 |
| 15 |
2412-93 |
CLAMP-R Price: $1.02 |
| 15 |
539104980 |
FUEL LINE 16" Price: $6.99 |
| 16 |
82-3110 |
SENDER-TEMP Price: $36.76 |
| 17 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 18 |
110-4105 |
HOSE-FUEL This part replaces 63-7620. Price: $11.71 |
| 19 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 20 |
3290-432 |
SCREW-HH Price: $0.81 |
| 21 |
81-1690 |
CLAMP-CABLE Price: $2.24 |
| 23 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 25 |
75-4703 |
HOSE Price: $16.06 |
| 26 |
3234-24 |
SCREW-HHF Price: $3.19 |
| 27 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 28 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 29 |
33115-025 |
SCREW-HH This part replaces 48-7780. Price: $0.61 |
| 30 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 31 |
94-5980 |
CABLE-BATTERY, NEG This part replaces 83-9210. Price: $92.64 |
| 32 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 33 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 34 |
83-7700 |
DISCONTINUED Price: Call Us |
| 35 |
2412-39 |
CLAMP-R Price: $1.70 |
| 36 |
185046210 |
Alternator Price: Call Us |
| 37 |
322-7 |
SCREW-HH Price: $0.89 |
| 38 |
83-9020 |
V-BELT Price: $13.23 |
| 39 |
145306380 |
Fan Price: Call Us |
| 40 |
321-14 |
SCREW-HH Price: $0.55 |
| 41 |
33093-00 |
WASHER-FLAT This part replaces 48-8010. Price: $0.70 |
| 42 |
92-3181 |
SPACER - FAN Price: $46.36 |
| 43 |
83-7630-03 |
DISCONTINUED This part replaces 83-7630. Price: Call Us |
| 44 |
83-7610 |
HUB - FAN Price: $107.05 |
| 45 |
32120-10 |
RING-SNAP Price: $1.29 |
| 47 |
83-9880 |
DISCONTINUED Price: Call Us |
| 48 |
92-3198-03 |
DISCONTINUED This part replaces 92-3198. Price: Call Us |
| 49 |
36-7290 |
BEARING Price: $40.48 |
| 50 |
62-9510 |
WASHER-LEVER, BRAKE Price: $4.56 |
| 51 |
83-8220 |
DISCONTINUED Price: Call Us |
| 52 |
92-9776 |
MUFFLER - SIDE DISC. This part replaces 83-8500. Price: $459.48 |
| 53 |
3234-28 |
SCREW-HHF Price: $1.59 |
| 54 |
83-7540 |
OBTAIN FROM PERKINS Price: Call Us |
| 55 |
83-7590-03 |
DISCONTINUED This part replaces 83-7590. Price: Call Us |
| 56 |
83-8470-03 |
REAR ENGINE BRKT ASM This part replaces 83-8470. Price: $65.66 |
| 57 |
65-8270 |
WASHER Price: $1.22 |
| 58 |
83-9910 |
PERK#314990013 Price: Call Us |
| 59 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 60 |
57-6390 |
NUT-JAM Price: $0.89 |
| 61 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 62 |
92-3154 |
TAB-THROTTLE Price: $7.93 |
| 63 |
32148-14 |
NUT-CLINCH Price: $1.29 |
| 64 |
92-3153 |
DISCONTINUED Price: Call Us |
| 65 |
92-7910 |
WIRE HARNESS ASSY Price: $774.80 |
| 66 |
83-9220 |
DISCONTINUED Price: Call Us |
