| Ref | Part Number | Description |
|---|
| 1 |
75-9990 |
HYD MOTOR ASM Price: $831.33 |
| 2 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 3 |
110-8786 |
HYD MOTOR ASM (CW) This part replaces 95-8693. Price: $1,062.27 |
| 4 |
322-9 |
SCREW-HH Price: $3.09 |
| 5 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 6 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
56-7971 |
CLAMP-TUBE Price: $17.90 |
| 8 |
95-8783 |
TUBE ASM Price: $172.34 |
| 9 |
354-77 |
FITTING-QUICK Price: $55.94 |
| 10 |
354-79 |
CAP-DUST Price: $7.81 |
| 11 |
95-8784 |
TUBE ASM Price: $181.92 |
| 12 |
3274-99 |
SCREW-HSH Price: $3.04 |
| 13 |
147-3595 |
BRACKET-BRAKE This part replaces 84-2000. Price: $8.08 |
| 14 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 15 |
93-6838-03 |
HUB-WHEEL This part replaces 93-6838. Price: $72.59 |
| 16 |
10-6850 |
DRUM-BRAKE Price: $54.08 |
| 17 |
85-6540 |
STUD-DRIVE Price: $7.41 |
| 18 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 19 |
115-1572 |
TIRE This part replaces 95-8656. Price: $129.30 |
| 20 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 21 |
321-5 |
SCREW-HH Price: $0.22 |
| 22 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 24 |
95-8818-03 |
SHIELD-WHEEL This part replaces 95-8818. Price: $104.17 |
| 25 |
92-1715 |
SPACER Price: $7.99 |
| 26 |
93-6850 |
LEVER-BRAKE Price: $59.75 |
| 27 |
282-2 |
YOKE Price: $30.04 |
| 28 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 29 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 30 |
95-5824 |
ROD-ADJUSTMENT Price: $68.90 |
| 31 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 32 |
3220-2 |
NUT-JAM Price: $0.50 |
| 33 |
95-8685-03 |
SHAFT-PIVOT, BRAKE This part replaces 95-8685. Price: $91.11 |
| 34 |
95-8683 |
BRACKET-PIVOT, BRAKE Price: $13.75 |
| 35 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 36 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 37 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 38 |
237-80 |
O-RING Price: $6.10 |
| 39 |
237-65 |
O-RING Price: $2.50 |
| 40 |
99-3474 |
RIM-WHEEL Price: $179.64 |
| 41 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 42 |
95-8832 |
HOSE ASM Price: $322.54 |
| 43 |
105-1214 |
HOSE-HYD This part replaces 95-8834. Price: $327.26 |
| 44 |
70-9870 |
PLATE-BACKING Price: $183.14 |
| 45 |
104-7708 |
BRAKE CAM & E-RING ASM This part replaces 70-9860. Price: $42.42 |
| 46 |
104-7708 |
BRAKE CAM & E-RING ASM This part replaces 70-9850. Price: $42.42 |
| 47 |
70-9880 |
SPRING-RETURN Price: $11.81 |
| 48 |
70-9840 |
SHOE-BRAKE Price: $60.36 |
