Housing
Parts (38)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 125-3486 | GROOMER SHAFT ASM Price: $383.56 |
| 1 | 545145494 | Screw m5x25 Price: $1.99 |
| 2 | 140-5616 | SPACER-SS This part replaces 70-1350. Price: $2.60 |
| 2 | 545145498 | Screw m5x65 Price: $1.99 |
| 3 | 140-5582 | BLADE-GR GROOMER, HELIX (0.015") This part replaces 127-6124. Price: $3.07 |
| 3 | 545145491 | Screw-Tapping m5x20 Price: $1.99 |
| 4 | 545145492 | Vibro-Isolating rubber Price: $19.99 |
| 5 | 545145500 | Cover-Fan Price: $11.99 |
| 6 | 545145501 | Cover Price: $5.99 |
| 7 | 545145493 | Case-Fan Price: $74.99 |
| 8 | 545145495 | Fan Price: $59.99 |
| 9 | 545145496 | Case-Fan Price: $99.99 |
| 10 | 545145492 | Vibro-Isolating rubber Price: $19.99 |
| 11 | 545145497 | Screw m6x30 Price: $1.99 |
| 12 | 545145499 | Nut-Nylon Price: $1.99 |
| 13 | 211302056 | Cap-Spark plug Price: Call Us |
| 14 | 211692051 | Terminal Price: Call Us |
| 15 | 920702113 | Plug-Spark (BPMR7A(NGK) Solid) Price: $12.99 |
| 16 | 210502310 | Flywheel Price: $74.99 |
| 17 | 545145464 | Key-Woodruff Price: $2.99 |
| 18 | 922101325 | Nut-m10 Price: $3.99 |
| 19 | 921532079 | Bolt m4x20 Price: $1.99 |
| 20 | 920712164 | Grommet Price: $2.99 |
| 21 | 260112379 | Wire-Lead Price: $3.99 |
| 22 | 920592233 | Tube 6x7.4x300 Price: $1.99 |
| 23 | 211712246 | Assy-Ignition coil Price: $74.99 |
| 24 | 490882540 | Starter-Recoil Price: $79.99 |
| 25 | 460752153 | Grip-Starter Recoil Price: $5.99 |
| 26 | 591062174 | Rope-3.5x1000 Price: $4.99 |
| 27 | 320992400 | Case-Starter Recoil Price: $29.99 |
| 28 | 921452142 | Spring Price: $2.99 |
| 29 | 921452143 | Spring-Recoil "A" Price: $17.99 |
| 30 | 591012117 | Reel-Starter Recoil Price: $17.99 |
| 31 | 131652101 | Pawl-Starter Recoil Price: $2.99 |
| 32 | 140202113 | Retainer Price: $7.99 |
| 33 | 921722083 | Screw Price: $2.99 |
| 34 | 920092386 | Screw m4x16 Price: $1.99 |
| 35 | 922102094 | Nut Price: $1.99 |
