| Ref | Part Number | Description |
|---|
| 1 |
539105330 |
FUEL TANK DIESEL RT Price: $139.99 |
| 1 |
93-7557 |
DISCONTINUED Price: Call Us |
| 2 |
32152-10 |
LOCKNUT Price: $0.81 |
| 2 |
539105329 |
FUEL TANK DIESEL LT Price: $179.99 |
| 2 |
741-3005 |
BUSHING Not Available Price: |
| 3 |
596584001 |
Screws This part replaces 539991034. Price: $2.99 |
| 3 |
937-3000 |
Grease Fitting This part replaces 7373000. Price: $4.04 |
| 4 |
539977351 |
GAS LINE 3 1/2" Price: $2.99 |
| 4 |
70-2780 |
PISTON Price: $133.22 |
| 4 |
710-3019 |
BOLT-PIVOT 3/4-10 x 5.0 GR5 W Not Available Price: |
| 5 |
539914359 |
FUEL FILTER Price: $4.99 |
| 5 |
703-1445-0637 |
KNUCKLE ASSEMBLY (LH)(POWDER BLACK) Not Available This part replaces 703-1445. Price: |
| 6 |
539105532 |
HEX CAP SCREW 1/4 Price: $2.99 |
| 6 |
703-0275 |
KNUCKLE ASSEMBLY (RH) Not Available Price: |
| 7 |
539105382 |
FUEL LINE 30" This part replaces 539105531. Price: $11.99 |
| 7 |
711-3053 |
TIE ROD Not Available Price: |
| 8 |
587044818 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 539105526. Price: $8.99 |
| 8 |
923-3015 |
BALL JOINT Not Available This part replaces 723-3015. Price: |
| 9 |
539105245 |
RUBBER GROMMET Price: $3.99 |
| 9 |
923-3016 |
BALL JOINT This part replaces 723-3016. Price: $21.06 |
| 9 |
98-7353 |
DISCONTINUED Price: Call Us |
| 10 |
539105244 |
ELBOW Price: $4.99 |
| 10 |
710-3111 |
SCREW 3/8-16 ? 1-1/2 Not Available Price: |
| 11 |
539107765 |
HOSE, FUEL .25 ID X 26" This part replaces 539105527. Price: $6.99 |
| 11 |
93-7991 |
COLLAR Price: $73.29 |
| 12 |
539105331 |
FUEL VALVE Price: $84.99 |
| 12 |
711-3048 |
PIN-STEER PIVOT Not Available Price: |
| 12 |
75-2120 |
SHAFT W/CLEVIS Price: $252.67 |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 13 |
539105398 |
EFI HOSE - 18" Price: $28.81 |
| 13 |
714-0111 |
Pin, Cotter, 3/32 Dia X 1.0 Lg Price: $4.20 |
| 14 |
539912222 |
HOSE CLAMP Price: $2.99 |
| 14 |
716-3002 |
Ring, Retaining Price: Call Us |
| 15 |
539105411 |
VENT HOSE Price: $2.99 |
| 15 |
736-0921 |
Washer, Lock, 1/2 Dia Price: $3.90 |
| 16 |
539105399 |
EFI HOSE - 8" Price: $16.99 |
| 16 |
712-3012A |
HEX NUT This part replaces 712-3012. Price: $11.49 |
| 17 |
539105400 |
EFI HOSE - 4" Price: $26.99 |
| 17 |
736-3027 |
FLAT WASHER Not Available Price: |
| 18 |
539105529 |
CLAMP Price: $4.99 |
| 18 |
710-3043 |
BOLT, 1/2 x 3/4 TYPE 5 Not Available Price: |
| 19 |
539105530 |
FUEL LINE 34" Price: $6.99 |
| 19 |
712-3011 |
HEX NUT Not Available Price: |
| 20 |
539105334 |
FUEL VALVE DECAL Price: $6.99 |
| 20 |
914-3001 |
Cotter Pin, .125 x 1.5 This part replaces 714-3001. Price: $3.23 |
| 21 |
539130394 |
FUEL CAP, GENERIC This part replaces 539106188. Price: $27.99 |
| 21 |
710-1039 |
Screw, Hex Cap 3/8-24 x 1.0 GR8 This part replaces 710-0152. Price: $4.02 |
| 22 |
736-3039 |
Washer, Flat, .406 X 1.5 X .112 Thk Price: $4.42 |
| 23 |
719-3065 |
STEERING ARM Not Available Price: |
| 24 |
710-3083 |
Screw, Hex Cap, 5/16-18 X 1.38 Lg GR5 Price: $3.94 |
| 25 |
712-3009 |
Nut, Hex Center Lock, 5/16-18 GR5 Price: $5.99 |
