| Ref | Part Number | Description |
|---|
| 1 |
121-5268-0P |
CHAMBER-CENTER, LH This part replaces 121-5268-01. Price: $575.16 |
| 2 |
121-5267-0P |
CHAMBER-CENTER, RH OUTER This part replaces 121-5267-01. Price: $341.60 |
| 2 |
532422027 |
SHAFT.ASM.CROSS.LIFT Price: $49.99 |
| 3 |
121-5266-0P |
CHAMBER-CENTER This part replaces 121-5266-01. Price: $238.69 |
| 3 |
532195231 |
LEVER.LIFT.HANDLE.LT Price: $29.99 |
| 4 |
3230-22 |
SCREW-CARR Price: $1.99 |
| 5 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 6 |
104-0108 |
U-BOLT Price: $7.10 |
| 7 |
32128-49 |
NUT-HHF Price: $1.04 |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK This part replaces 580962301. Price: $2.99 |
| 8 |
68-6840 |
SHAFT-ROLLER Price: $64.07 |
| 9 |
68-6710 |
ROLLER Price: $59.98 |
| 10 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $2.99 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 12 |
121-5473-01 |
SHIELD-RH Price: $31.16 |
| 13 |
121-5474-01 |
SHIELD-LH Price: $31.16 |
| 14 |
112-1625 |
PULL LINK ASM Price: $212.18 |
| 15 |
120-5570 |
PIN-RETAINER Price: $24.69 |
| 16 |
110-9828 |
SPRING-TORSION Price: $98.42 |
| 17 |
110-9845 |
SPACER-PLAIN Price: $34.73 |
| 18 |
3296-45 |
NUT-HEX Price: $3.79 |
| 19 |
325-33 |
SCREW-HH Price: $11.49 |
| 20 |
325-22 |
SCREW-HH Price: $4.26 |
| 21 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 24 |
125-9436 |
DECAL-REGULATORY Price: Call Us |
| 25 |
110-5070 |
BUMPER Price: $10.00 |
| 26 |
103-4080 |
LATCH-RUBBER Price: $29.99 |
| 27 |
3274-39 |
SCREW-HSBH Price: $4.34 |
| 28 |
127-4957 |
COVER ASM Price: $56.10 |
| 29 |
127-4959 |
LH COVER ASM Price: $82.83 |
| 30 |
75-5780 |
HINGE-STEEL Price: $18.08 |
| 31 |
240-9 |
GROMMET Price: $3.25 |
| 32 |
103-4081 |
LATCH-KEEPER Price: $13.99 |
| 33 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 34 |
3274-31 |
SCREW-HSBH Price: $0.89 |
| 35 |
104-7201 |
NUT-HF Price: $0.69 |
| 36 |
127-4958 |
RH COVER ASM Price: $82.83 |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $1.99 |
| 88 |
532410710 |
SPRING.LIFT.ASSIST Price: $4.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $3.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $1.99 |
| 91 |
532195181 |
LINK.ASM.LIFT.REAR Price: $34.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 98 |
532195270 |
LINK.ASM.SUSP.FRONT.MW Price: $14.99 |
| 100 |
873680600 |
LOCKNUT This part replaces 873930600. Price: $1.99 |
