| Ref | Part Number | Description |
|---|
| 1 |
3-6991 |
DISCONTINUED Price: Call Us |
| 1 |
530047721 |
Bulb-Purge Price: $3.99 |
| 2 |
3-9022 |
DISCONTINUED Price: Call Us |
| 2 |
530071717 |
Kit-Choke Lever Price: $7.99 |
| 3 |
3-9161 |
DISCONTINUED Price: Call Us |
| 3 |
530015843 |
Screw-tank Price: $1.99 |
| 4 |
3-6987 |
DISCONTINUED Price: Call Us |
| 4 |
530057973 |
Assy - Fuel Cap w/retainer This part replaces 530049386. Price: $7.99 |
| 5 |
222-8 |
CAP-GAS Price: $65.84 |
| 5 |
530095646 |
Assy-Fuel pickup Price: $2.99 |
| 6 |
3-9158 |
DISCONTINUED Price: Call Us |
| 6 |
530069247 |
Kit-Fuel line Price: $3.99 |
| 7 |
3-8917 |
DISCONTINUED Price: $18.99 |
| 7 |
530069216 |
Kit-Fuel/Purge line Price: $3.99 |
| 8 |
17-9160 |
DISCONTINUED Price: Call Us |
| 8 |
530015775 |
Screw Price: $1.99 |
| 9 |
5-3902 |
DISCONTINUED Price: Call Us |
| 9 |
530054935 |
Cover-Air box Price: $1.99 |
| 10 |
3-9037 |
DISCONTINUED Price: Call Us |
| 10 |
530054946 |
Filter-Air Price: $1.99 |
| 11 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 11 |
530015849 |
Screw-Carb. Price: $1.99 |
| 12 |
5-2942 |
SHACKLE Price: $16.99 |
| 12 |
530054934 |
Box-Air Price: $3.99 |
| 13 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 14 |
98-3206 |
DECAL This part replaces 12-9140. Price: $1.99 |
| 15 |
545075305 |
Assy-Fuel Tank Price: $11.99 |
| 16 |
530015771 |
Screw-Crankcase Price: $1.99 |
| 17 |
530015952 |
Screw-Shroud Price: $1.99 |
| 18 |
5-1935 |
DISCONTINUED Price: Call Us |
| 18 |
530058797 |
Shroud Price: $14.99 |
| 19 |
5-3806 |
DISCONTINUED Price: Call Us |
| 20 |
12-8140 |
KEY SWITCH Price: $39.86 |
| 20 |
530027593 |
Valve-Reed Price: $1.99 |
| 21 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 21 |
530054596 |
Stop-Reed Price: $1.99 |
| 22 |
5-0688 |
DISCONTINUED Price: Call Us |
| 22 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 23 |
36-3520 |
DISCONTINUED Price: Call Us |
| 23 |
530015875 |
Screw-Retainer Price: $1.99 |
| 24 |
530055492 |
Isolator-Tank Price: $1.99 |
| 24 |
7-1394 |
DISCONTINUED Price: Call Us |
| 25 |
5-3882 |
DISCONTINUED Price: Call Us |
| 25 |
530054941 |
Ret.-Tank Price: $1.99 |
| 26 |
32122-30 |
SCREW-PTH Price: $0.28 |
| 26 |
530054834 |
Handle-Starter Price: $1.99 |
| 27 |
5-3954 |
DISCONTINUED Price: Call Us |
| 27 |
530071325 |
Kit-Rope Price: $3.99 |
| 28 |
3217-5 |
NUT-HEX Price: $0.25 |
| 28 |
530032103 |
Bearing-Inner Price: Call Us |
| 29 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
530015787 |
Retainer Price: $1.99 |
| 30 |
5-4543 |
DISCONTINUED Price: Call Us |
| 30 |
530019158 |
Seal Price: $2.99 |
| 31 |
323-6 |
SCREW-HH Price: $0.66 |
| 31 |
530032102 |
Bearing-Outer Price: $8.99 |
| 32 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 32 |
530015789 |
Ret.-Crankshaft Price: $2.99 |
| 33 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 33 |
530028807 |
Assy-Crankshaft Price: $19.99 |
| 34 |
321-6 |
SCREW-HH Price: $0.25 |
| 35 |
321-4 |
SCREW-HH Price: $0.99 |
| 36 |
5-2938 |
SWAGED CABLE ASM 2&3 Price: $104.40 |
| 36 |
530055524 |
Assy-Flywheel Price: $22.99 |
| 37 |
283-15 |
PIN-CLEVIS Price: $4.07 |
| 37 |
530016030 |
Washer Price: $1.99 |
| 38 |
5-2656 |
CABLE KEEPER Price: $27.15 |
| 38 |
530055620 |
Spacer Price: $4.99 |
| 39 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 39 |
530015775 |
Screw-Baffle Price: $1.99 |
| 40 |
3-9031 |
DISCONTINUE Price: Call Us |
| 40 |
545115201 |
Plate-Baffle This part replaces 530054939. Price: $2.99 |
| 41 |
5-1706 |
SPRING-EXTENSION Price: $12.91 |
| 41 |
530016391 |
Screw-Rope Price: $1.99 |
| 43 |
5-2655 |
CABLE KEEPER Price: $28.04 |
| 43 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 44 |
530019182 |
Grommet Price: $1.99 |
| 44 |
HY2562 |
DISCONTINUED This part replaces 256-2. Price: Call Us |
| 45 |
5-2653 |
PULLEY ASM Price: $38.12 |
| 45 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 46 |
5-2724 |
DISCONTINUED Price: Call Us |
| 46 |
530055248 |
Assy.-Fan Housing Price: $17.99 |
| 47 |
3217-5 |
NUT-HEX Price: $0.25 |
| 47 |
530094189 |
Washer-Clutch Price: $2.99 |
| 48 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 48 |
530055122 |
Assy-Clutch Price: $8.99 |
| 49 |
5-3906 |
DISCONTINUED Price: Call Us |
| 49 |
530028799 |
Drum-Clutch Price: $4.48 |
| 50 |
321-9 |
SCREW-HH Price: $0.27 |
| 50 |
530010960 |
Assy-Conn. Rod Price: $14.99 |
| 51 |
3211-15 |
SCREW-HH Price: $7.99 |
| 51 |
530015162 |
Ret.-Piston pin Price: $1.99 |
| 52 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 52 |
530012595 |
Ring-Piston Price: $4.99 |
| 53 |
3217-5 |
NUT-HEX Price: $0.25 |
| 54 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 55 |
321-9 |
SCREW-HH Price: $0.27 |
| 55 |
530058846 |
Assy-Leadwire Price: $4.99 |
| 56 |
3290-192 |
DISCONTINUED Price: Call Us |
| 56 |
530069310 |
Kit-Muffler Price: $9.99 |
| 57 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 57 |
530058957 |
Shield Price: $3.99 |
| 58 |
322-10 |
SCREW-HH Price: $0.70 |
| 58 |
530036409 |
Spring-Muffler Price: $1.99 |
| 59 |
304-75 |
CONNECTOR-HOSE Price: $8.29 |
| 59 |
530071581 |
Kit-Cylinder Price: $59.99 |
| 60 |
110-1872 |
HOSE-FUEL This part replaces 5-4542. Price: $31.99 |
| 61 |
224-173 |
DISCONTINUED Price: Call Us |
| 61 |
530001624 |
Bolt-Cyl. 1/4-20' Price: $1.99 |
| 62 |
289-4 |
DISCONTINUED Price: Call Us |
| 62 |
530039218 |
Module-Ignition Price: $32.99 |
| 63 |
32122-20 |
DISCONTINUED Price: Call Us |
| 63 |
530016357 |
Screw-Module Price: $1.99 |
| 64 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 65 |
323-10 |
SCREW-HH Price: $0.89 |
| 66 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 67 |
322-3 |
SCREW-HH Price: $0.79 |
