| Ref | Part Number | Description |
|---|
| 1 |
3290-360 |
SCREW-HH Price: $4.34 |
| 2 |
2710-20 |
LINK-OFFSET Price: $10.06 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 3 |
321-24 |
SCREW-HH This part replaces 321-23. Price: $2.31 |
| 4 |
85-9580 |
HOSE-HYD Price: $73.59 |
| 5 |
237-21 |
O-RING Price: $0.70 |
| 6 |
85-9720 |
FITTING-STR, ORIFICE Price: $119.77 |
| 7 |
237-78 |
O-RING Price: $3.85 |
| 8 |
88-8480 |
BRACKET-PIVOT Price: $17.24 |
| 9 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 9 |
596501502 |
Keepers This part replaces 584908001. Price: $9.99 |
| 10 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 11 |
85-9570 |
HOSE-HYD Price: $66.91 |
| 12 |
532405472 |
RP_PULLEY ENGINE Price: $34.99 |
| 12 |
85-9600 |
DISCONTINUED Price: Call Us |
| 13 |
237-22 |
O-RING Price: $2.43 |
| 14 |
340-86 |
FITTING-TEE Price: $35.23 |
| 15 |
237-42 |
O-RING Price: $2.78 |
| 15 |
529999102 |
TANK ASSY W/CAP 3 GAL CARB This part replaces 532414151. Price: $329.99 |
| 16 |
85-0380 |
TUBE-MOTOR TO VALVE Price: $60.31 |
| 17 |
43-1950 |
HYD CONTROL VALVE ASM Price: $695.34 |
| 18 |
2412-138 |
R-CLAMP Price: $1.36 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 Price: $37.99 |
| 19 |
3296-8 |
NUT-HEX Price: $1.29 |
| 20 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN.BK Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
92-2349 |
TUBE-VALVE TO COOLER Price: $61.15 |
| 22 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 23 |
85-8900 |
DISCONTINUED Price: Call Us |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 113 |
597791601 |
VALVES This part replaces 532414127. Price: $9.99 |
| 138 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
