| Ref | Part Number | Description |
|---|
| 1 |
451224 |
Brake Lever Price: Call Us |
| 2 |
04063-20 |
Key, 1/4 x 1/4 x 1" Price: Call Us |
| 3 |
482061 |
Bushing, Self Align Price: Call Us |
| 4 |
04001-145 |
Bolt, Hex Head 1/2-13 x 3-1/2" Price: Call Us |
| 5 |
04001-153 |
Bolt, Hex Head 1/2-13 x 2-1/4" Price: Call Us |
| 6 |
04021-19 |
Nut, 112-13 Center Lock Price: Call Us |
| 7 |
482639 |
Wheel Motor, Ross This part replaces 481529. Price: Call Us |
| 8 |
04063-25 |
Key, Woodruff 5/16 x 1" Price: Call Us |
| 9 |
46929 |
Wheel Hub Assembly Price: Call Us |
| 10 |
481601 |
Brake Band Assembly Price: Call Us |
| 11 |
48513 |
Brake Drum Price: Call Us |
| 12 |
48680 |
Nut, Hex Castle 1.0-20 UNEF Price: Call Us |
| 13 |
04061-06 |
Cotter Pin, 9/64 x 1-1/2" Price: Call Us |
| 14 |
04028-01 |
Lug Nut Price: Call Us |
| 15 |
481831 |
Wheel Assembly (40"), 23 x 8.50-12 Price: Call Us |
| 16 |
422487 |
Wheel Spacer Price: Call Us |
| 17 |
451074 |
Shaft Weldment, RH Price: Call Us |
| 18 |
451073 |
Shaft Weldment, LH Price: Call Us |
| 19 |
04064-03 |
Clevis Pin, 3/8 x 2" Price: Call Us |
| 20 |
04069-01 |
Pin, Rue Cotter 3/8 Dia Price: Call Us |
| 21 |
461471 |
Brake Linkage LH This part replaces 451071. Price: Call Us |
| 22 |
48114-04 |
Grease Fitting, 1/4-28 Self Tap Price: Call Us |
| 23 |
04020-14 |
Nut, 3/8-24 UNF Price: Call Us |
| 24 |
04050-01 |
Retaining Ring, .625 Ext Price: Call Us |
| 25 |
04021-10 |
Nut, Elastic Stop 5/16-18 Price: Call Us |
| 26 |
04041-07 |
Flatwasher, 3/8- .391 x .938 x .105 Price: Call Us |
| 27 |
04001-09 |
Bolt, Hex Head 5/16-18 x 1" Price: Call Us |
| 28 |
04001-157 |
Bolt, Hex Head 3/8-24 x 5-3/4" Price: Call Us |
| 29 |
04061-02 |
Cotter Pin, 3/32 x 3/4" Price: Call Us |
| 30 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 31 |
451225 |
Brake Shaft Price: Call Us |
| 32 |
04021-05 |
Hex Lock Nut, 3/8-16 Price: Call Us |
| 33 |
48544 |
Rod End, 3/8-24 LH Thread Price: Call Us |
| 34 |
04064-02 |
Clevis Pin, 3/8 x 1.06 Price: Call Us |
| 35 |
48343-04 |
Clevis, 3/8-24 Price: Call Us |
| 36 |
482102 |
Grip, Brake Lever Price: Call Us |
| 37 |
04019-04 |
Nut, Serr Flange 3/8-16 Price: Call Us |
| 38 |
461283 |
Brake Lever Price: Call Us |
| 39 |
04001-22 |
Bolt, Hex Head 3/8-16 x 2-3/4" Price: Call Us |
| 40 |
04020-17 |
Nut, 3/8-24 UNF-2B LH Thread Price: Call Us |
| 41 |
43568 |
Brake Rod Price: Call Us |
| 42 |
04020-14 |
Nut, 3/8-24 UNF Price: Call Us |
| 43 |
423279 |
Plate Weldment, Motor Backing This part replaces 451290. Price: Call Us |
| 44 |
04001-08 |
Bolt, Hex Head 5/16-18 x 3/4" Price: Call Us |
| 45 |
04042-05 |
Flatwasher, 1.0-1.062 x 1.75 x .10 Price: Call Us |
| 461472 |
Brake |
Linkage RH This part replaces 451072. Price: Call Us 461472 |
| 481832 |
Rim |
W/Valve Stem (40") Price: Call Us 481832 |
| 481850 |
Wheel |
Assembly (48" & 52") 24 x 12-12 Price: Call Us 481850 |
