| Ref | Part Number | Description |
|---|
| 1 |
110-4136 |
DIFFERENTIAL CASE ASM Price: $796.59 |
| 2 |
93-3618 |
GEAR AND PINION ASM This part replaces 92-1676. Price: $1,107.66 |
| 3 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 4 |
86-9610 |
UPPER HOUSING SUB ASM Price: $1,155.01 |
| 5 |
21-7830 |
COVER-GEAR Price: $26.87 |
| 6 |
72-3572 |
SHIM-BEARING, FRONT (.098) This part replaces 72-3570. Price: $23.68 |
| 6 |
72-3573 |
SHIM-BEARING, FRONT (.100) Price: $24.63 |
| 6 |
72-3574 |
SHIM-BEARING, FRONT (.102) Price: $23.68 |
| 6 |
72-3575 |
SHIM-BEARING, FRONT (.104) Price: $22.53 |
| 6 |
72-3576 |
SHIM-BEARING, FRONT (.106) Price: $23.68 |
| 6 |
72-3577 |
SHIM-BEARING, FRONT (.108) Price: $22.53 |
| 6 |
72-3578 |
SHIM-BEARING, FRONT (.110) Price: $22.53 |
| 6 |
72-3580 |
SHIM-BEARING, FRONT (.112) Price: $22.53 |
| 6 |
72-3581 |
SHIM-BEARING, FRONT (.114) Price: $22.53 |
| 6 |
72-3582 |
SHIM-BEARING, FRONT (.116) Price: $22.53 |
| 6 |
72-3583 |
SHIM-BEARING, FRONT (.118) Price: $56.93 |
| 6 |
72-3584 |
SHIM-BEARING, FRONT (.120) Price: $24.63 |
| 6 |
72-3585 |
SHIM-BEARING, FRONT (.125) Price: $22.53 |
| 6 |
72-3586 |
SHIM-BEARING, FRONT (.127) Price: $22.53 |
| 6 |
72-3587 |
SHIM-BEARING, FRONT (.129) Price: $23.68 |
| 6 |
72-3588 |
SHIM-BEARING, FRONT (.131) Price: $22.53 |
| 6 |
72-3590 |
SHIM-BEARING, FRONT (.133) Price: $22.53 |
| 6 |
72-3591 |
SHIM-BEARING, FRONT (.135) Price: $21.44 |
| 6 |
72-3592 |
SHIM-BEARING, FRONT (.137) Price: $22.53 |
| 6 |
72-3593 |
SHIM-BEARING, FRONT (.139) Price: $23.68 |
| 6 |
72-3594 |
SHIM-BEARING, FRONT (.141) Price: $23.68 |
| 6 |
72-3595 |
SHIM-BEARING, FRONT (.143) Price: $22.53 |
| 6 |
72-3596 |
SHIM-BEARING, FRONT (.145) Price: $22.53 |
| 6 |
72-3597 |
SHIM-BEARING, FRONT (.147) Price: $22.53 |
| 6 |
72-3598 |
SHIM-BEARING, FRONT (.149) Price: $24.63 |
| 6 |
72-3600 |
SHIM-BEARING, FRONT (.151) Price: $23.68 |
| 7 |
71-4330 |
SEAL Price: $36.26 |
| 8 |
68-7010 |
FLANGE Price: $306.32 |
| 9 |
71-4340 |
WASHER Price: $15.47 |
| 10 |
71-4350 |
NUT Price: $3.46 |
| 11 |
254-91 |
CONE-BEARING Price: $18.65 |
| 12 |
254-90 |
BEARING-CUP Price: $11.29 |
| 13 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 14 |
3210-7 |
SCREW-HH Price: $0.61 |
| 15 |
43-6710 |
SHIM-PINION (.003) Price: $2.17 |
| 15 |
43-6711 |
SHIM-PINION (.005) Price: $3.80 |
| 15 |
43-6712 |
SHIM-PINION (.010) Price: $3.19 |
| 15 |
43-6713 |
SHIM-PINION (.030) Price: $6.99 |
| 16 |
43-6750 |
BEARING-TAPER, CUP Price: $69.64 |
| 17 |
43-6760 |
BEARING-ROLLER, CONE TAPER Price: $113.20 |
| 18 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 19 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 20 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 20 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 20 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 20 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 21 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 22 |
28-0670 |
SEAL-GREASE Price: $19.74 |
| 23 |
84-8580 |
LH BRAKE ASM Price: $555.65 |
| 24 |
84-8570 |
RH BRAKE ASM Price: $527.93 |
| 25 |
21-8180 |
BEARING ASM Price: $65.11 |
| 26 |
99-6969 |
SEAL-OIL, WHEEL END Price: $14.71 |
| 27 |
24-8840 |
RING-RETAINING, WHEEL BEARING Price: $37.15 |
| 28 |
43-6840 |
HOUSING-LOWER Price: $1,467.48 |
| 29 |
72-9420 |
VENT Price: $6.85 |
| 30 |
3219-2 |
NUT-HEX Price: $0.37 |
| 31 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 32 |
94-6935 |
LOCKNUT Price: $1.09 |
| 33 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 34 |
94-6934 |
SCREW-HH Price: $6.99 |
| 35 |
28-0680-03 |
DRUM-BRAKE This part replaces 28-0680. Price: $358.84 |
| 36 |
28-0650 |
SHAFT-AXLE, FLANGED Price: $1,130.23 |
| 37 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 38 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 39 |
86-7230 |
GEAR-INPUT, TRANSMISSION Price: $610.12 |
| 40 |
32144-112 |
SCREW-HWH Price: $0.99 |
| 41 |
21-8360 |
CLIP-RETAINING Price: $1.29 |
