| Ref | Part Number | Description |
|---|
| 1 |
20-9430-01 |
WEIGHT Price: $912.11 |
| 1 |
532424543 |
WHEEL.STEERING.HARD.RIM.BLAC Price: $27.99 |
| 2 |
532418168 |
AXLE HALF ASM-WELDED Price: $34.99 |
| 2 |
62-5550 |
DECAL Price: $9.32 |
| 3 |
323-10 |
SCREW-HH Price: $0.89 |
| 4 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 5 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 6 |
20-9550 |
SPRING-COMPRESSION Price: $7.70 |
| 6 |
532121748 |
WASHER Price: $1.99 |
| 7 |
323-12 |
SCREW-HH Price: $1.14 |
| 7 |
819272016 |
WASHER Price: $2.99 |
| 8 |
108-2911-01 |
HOUSING-SPIKER, RH Price: $599.49 |
| 8 |
812000029 |
RING CLIP Price: $1.99 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $1.99 |
| 10 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $44.99 |
| 11 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 11 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 12 |
251-253 |
BEARING Price: $22.84 |
| 13 |
251-255 |
FLANGE Price: $15.34 |
| 13 |
532136518 |
TUBE, PIVOT AXLE (2 2) Price: $6.99 |
| 14 |
32151-44 |
RING-RETAINING Price: $2.99 |
| 15 |
20-9490 |
WASHER Price: $8.14 |
| 15 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 16 |
20-7400 |
SPACER-END Price: $11.87 |
| 17 |
20-7380-01 |
BLADE-SPIKE, PROFILED Price: $36.82 |
| 17 |
532190753 |
SHAFT STEERING SPLINE This part replaces 532411386. Price: $32.99 |
| 18 |
20-9480 |
SPACER Price: $12.27 |
| 19 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 20 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 21 |
92-7196 |
SHAFT Price: $440.72 |
| 22 |
20-9460 |
KEY-SQUARE Price: $75.81 |
| 23 |
20-9540 |
KEY-SQUARE Price: $4.74 |
| 24 |
20-9500 |
WASHER Price: $3.53 |
| 26 |
112-7690-01 |
HUB ASM Price: $197.32 |
| 26 |
532126847 |
BUSHING.DRAGLINK (2 2) Price: $2.99 |
| 27 |
87-5100 |
WASHER-SNUBBING Price: $3.46 |
| 28 |
324-5 |
SCREW-HH Price: $0.54 |
| 28 |
819131414 |
WASHER This part replaces 819131416. Price: $3.99 |
| 29 |
112-7679-01 |
RH FORK ASM Price: $614.00 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 30 |
112-7680-01 |
LH FORK ASM Price: $614.00 |
| 30 |
876020412 |
COTTER PIN Price: $3.99 |
| 31 |
108-2910-01 |
HOUSING-SPIKER, LH Price: $599.49 |
| 32 |
532192757 |
ROD.TIE.WIRE.FORM Price: $12.99 |
| 34 |
810040500 |
LOCKWASHER Price: $2.99 |
| 36 |
532155106 |
KIT.BUSHING This part replaces 532155099. Price: $5.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532424691 |
INSERT, WHEEL STEERING Price: $4.99 |
| 39 |
819113812 |
WASHER.11/32 Price: $3.99 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $1.99 |
| 41 |
532437747 |
STEERING.WHEEL.ADAPTER This part replaces 532186737. Price: $19.99 |
| 43 |
532121749 |
WASHER Price: $1.99 |
| 44 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $9.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $1.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE Price: $2.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $2.99 |
| 68 |
532169827 |
BRACE.AXLE.15"TIRES Price: $14.99 |
| 71 |
532175146 |
STEERING ASM Price: $64.99 |
| 82 |
532199978 |
BRACKET.SUSP.CHASSIS.FRONT.15 Price: $11.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $3.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $8.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $2.99 |
