EXTERNAL POWER UNIT
Parts (75)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 137-6126 | LONG REAR ROLLER ASM (3IN DIA)(32IN) This part replaces 112-8961. Price: $536.38 |
| 1 | 530027732 | Retainer Mount Price: $1.99 |
| 2 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 2 | 530015714 | Screw Price: $3.33 |
| 3 | 119-0626 | SHIM-ROLLER Price: $3.23 |
| 3 | 530027732 | Chain Catcher Retainer Price: $1.99 |
| 4 | 530069384 | Isolator Ass'y. Kit Price: $17.99 |
| 5 | 106-3924 | BRACKET-ROLLER, REAR Price: $23.58 |
| 5 | 530027392 | Lower Isolator Price: $3.33 |
| 6 | 3230-26 | SCREW-CARR Price: $3.99 |
| 6 | 530069391 | Rear Handle & Fuel Tank Price: $24.32 |
| 7 | 117-0990 | PLASTIC WIEHLE ROLLER ASM Price: $553.30 |
| 7 | 530036056 | Cylindrical Mount Price: $2.84 |
| 8 | 32128-20 | NUT-HF Price: $0.99 |
| 8 | 530027187 | Isolator Limiter Price: $1.99 |
| 9 | 322-16 | SCREW-HH Price: $3.39 |
| 9 | 530015650 | Screw-Pinch Clamp This part replaces 530015871. Price: $1.99 |
| 10 | 120-0404 | BRACKET-HIGH HOC (LH) Price: $71.73 |
| 10 | 120-0405 | BRACKET-HIGH HOC (RH) Price: $71.73 |
| 10 | 530027733 | Chain Catcher Price: $1.99 |
| 11 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 12 | 48-9220 | WASHER-PLAIN Price: $0.87 |
| 12 | 530010845 | Fuel Cap Ass'y. Price: $5.99 |
| 13 | 3231-4 | SCREW-CARR Price: $3.59 |
| 13 | 530037012 | Strap Retainer Plate Price: $1.99 |
| 14 | 107-4026 | SCREW-HH Price: $5.28 |
| 14 | 530036035 | Bracket Price: $2.99 |
| 15 | 530015598 | Screw Price: $1.99 |
| 15 | 94-6936 | WASHER-HARDENED Price: $0.58 |
| 16 | 530029666 | Throttle Lock Price: $2.99 |
| 17 | 530024772 | Throttle Lock Spring Price: $1.99 |
| 18 | 530015716 | Screw Price: $1.99 |
| 19 | 530037104 | AV Strap Price: $1.99 |
| 20 | 530069392 | Cylinder Shield Kit Price: $4.32 |
| 21 | 530036038 | Carb. Cover Price: $5.99 |
| 22 | 530015650 | Screw-Pinch Clamp This part replaces 530015871. Price: $1.99 |
| 23 | 530027134 | Trigger Latch Spring Price: $1.99 |
| 24 | 530027133 | Throttle Trigger Price: $1.99 |
| 25 | 119-0649 | TRIM/HD COLLAR KIT Price: $24.38 |
| 25 | 530036053 | Grommet Price: $1.99 |
| 26 | 530027121 | Bracket Price: $1.99 |
| 27 | 530069263 | Model 336C Price: $3.33 |
| 27 | 530069382 | Model 365C Price: $3.33 |
| 28 | 530035201 | Carburetor (HDA-49) Price: $109.99 |
| 29 | 530023664 | Air Filter Plate Price: $1.99 |
| 30 | 530015735 | Carb. Mounting Stud Price: $0.93 |
| 31 | 530010892 | Air Filter Ass'y. Price: Call Us |
| 32 | 530027135 | Throttle Lockout Price: $1.99 |
| 33 | 530027207 | Rear Handle Cover Price: $11.99 |
| 34 | 530027073 | Throttle Wire Price: $2.99 |
| 35 | 530027075 | Choke Knob Price: $1.99 |
| 36 | 530036962 | Spring Ass'y. Price: $3.33 |
| 37 | 530001543 | Nut Price: Call Us |
| 38 | 530015701 | Dowel Pin Price: $1.99 |
| 39 | 530015724 | Screw Price: $1.99 |
| 40 | 530069216 | Line Kit (Bulk 530-008133) Price: $3.99 |
| 41 | 530091878 | Fuel Filter Ass'y. Price: $5.99 |
| 42 | 530039129 | Grommet Price: $1.99 |
| 43 | 530069225 | Switch Kit Price: $6.99 |
| 44 | 530027138 | Lead Wire Ass'y. Price: $2.99 |
| 45 | 530015598 | Screw This part replaces 530015802. Price: $1.99 |
| 46 | 530027202 | Screw Retainer Price: $1.99 |
| 47 | 530025539 | Impulse Fitting Price: $1.99 |
| 48 | 530024475 | Vent Fitting Price: $1.99 |
| 49 | 530026119 | Check Valve Price: $1.99 |
| 50 | 530031159 | Hex Wrench (5/32) This part replaces 530031111. Price: $1.99 |
| 51 | 530027339 | Vent Plug Price: $2.52 |
| 52 | 530025922 | Air Box Plug Price: $1.99 |
| 53 | 530027341 | Clamp Price: $1.99 |
| 54 | 530069297 | Isolator Repair Kit Price: $2.99 |
| 55 | 530015123 | Washer Price: $1.99 |
| 56 | 530029347 | Bracket Retainer Price: $1.99 |
| 57 | 530015710 | Screw Price: $3.33 |
| 58 | 530016386 | SCREW This part replaces 530015810. Price: $5.99 |
| 59 | 530015562 | Washer Price: $1.99 |
