| Ref | Part Number | Description |
|---|
| 3 |
161963 |
Gasket, Gearcase Price: Call Us |
| 4 |
5020J |
Bearing, Needle Price: Call Us |
| 5 |
1370H |
Washer, Thrust 5/8 x 1.10 x 1/32 Price: Call Us |
| 6 |
137335 |
Pinion, Input Price: Call Us |
| 7 |
145101 |
Shaft, Input Price: Call Us |
| 7 |
27105900 |
SCREW,HEX WASHER 1/4-20X1.125 Price: $1.95 |
| 8 |
4895H |
Bearing, Needle Price: Call Us |
| 9 |
154467 |
Washer, Seal Price: Call Us |
| 10 |
7392M |
Ball, Steel Price: Call Us |
| 11 |
100371K |
Spring, Shift, Fork Price: Call Us |
| 11 |
21500049 |
PLUG EXT HEX VENT 9/16 18 Price: $5.45 |
| 12 |
106160X |
O-Ring Price: Call Us |
| 13 |
142145 |
Asm. Bracket Shift Price: Call Us |
| 13 |
21543771 |
SEALANT TUBE 10.1OZ. Price: $132.95 |
| 14 |
8353J |
Fork, Shift Price: Call Us |
| 15 |
12000039 |
Ring, Klip Price: Call Us |
| 16 |
154466 |
Shaft, Shift Price: Call Us |
| 18 |
4358J |
Washer Price: Call Us |
| 19 |
12000040 |
Ring, Klip Price: Call Us |
| 21 |
102115X |
Gear, Reverse Idler Price: Call Us |
| 22 |
6803J |
Bearing, Needle Price: Call Us |
| 23 |
102111X |
Shaft, Reverse Idler Price: Call Us |
| 23 |
21545100 |
OIL FILTER, TRANSMISSION This part replaces 21544900. Price: $36.95 |
| 24 |
10040700 |
Washer, Lock 7/16 Price: Call Us |
| 25 |
73610700 |
Nut, Hex 7/16-20 Price: Call Us |
| 27 |
143009 |
Bearing, Shaft, Ground Drive L.H. Price: Call Us |
| 28 |
106390X |
Spacer 0.765 x 1.125 x 1.23 Price: Call Us |
| 29 |
102134X |
Chain #35-50 Pitch Price: Call Us |
| 30 |
150737 |
Ground Shaft Assembly Price: Call Us |
| 30 |
21543845 |
SEAL, LIP .375X.75X.25 Price: $8.45 |
| 31 |
08622500 |
RING. RETAINING Price: $7.45 |
| 31 |
143008 |
Bearing, Shaft, Ground Drive R.H. Price: Call Us |
| 32 |
106388X |
Spacer 0.70 x 1.00 x 1.150 Price: Call Us |
| 33 |
102121X |
Sprocket and Gear Assembly Price: Call Us |
| 33 |
21543846 |
RING, RET .750 Price: $1.55 |
| 34 |
102112X |
Shaft, Reduction (2nd) Price: Call Us |
| 34 |
21543847 |
ARM, BYPASS Price: $5.95 |
| 35 |
102101X |
Screw, Whiz, Lock 5/16-18 x 3-1/2 Price: Call Us |
| 35 |
21543848 |
RING, RTNG . Price: $4.45 |
| 37 |
4422J |
Bearing, Needle Price: Call Us |
| 38 |
154356 |
Sprocket, Tine Price: Call Us |
| 39 |
105345X |
Gear, Cluster, Red 1st & 2nd Price: Call Us |
| 40 |
105346X |
Gear, Reverse Price: Call Us |
| 40 |
21543783 |
TRUNNION, SWASHPLATE Price: $56.95 |
| 41 |
21543809 |
SEAL, LIP 18X32X7 Price: $8.45 |
| 41 |
8358J |
Shaft, Reduction (1st) Price: Call Us |
| 42 |
4220R |
Washer, Thrust Price: Call Us |
| 43 |
106146X |
Spacer 1.01 x 1.75 x 0.760 Price: Call Us |
| 44 |
155236 |
Seal Asm, Oil Price: Call Us |
| 45 |
08611200 |
WASHER Price: $3.45 |
| 49 |
132688 |
Shaft, Tine Price: Call Us |
| 50 |
106147X |
Chain, Roller #50-50 Pitch Price: Call Us |
| 51 |
17720408 |
Screw 1/4-20 x 1/2 Price: Call Us |
| 52 |
73220500 |
Nut, Hex 5/16-18 Price: Call Us |
| 53 |
165140 |
Kit, Bearing Price: Call Us |
| 55 |
21543773 |
WASHER 1.23X1.56X.04 Price: $5.45 |
| 57 |
21543741 |
RING, RET 1.56 INT Price: $6.45 |
| 58 |
179520 |
Bolt Shoulder Price: Call Us |
| 60 |
183226 |
Fitting Grease Price: Call Us |
| 60 |
21548902 |
HG THRUST BEARING (51462) Price: $25.45 |
| 64 |
21548904 |
HG 16CC CYLINDER BLOCK (71579) Price: $60.95 |
| 65 |
08609100 |
BEARING. THRUST 30 X 52 X 13 Price: $14.95 |
| 69 |
21543921 |
ASSY, BLOCK 7 PISTON Price: $112.45 |
| 70 |
21543708 |
WASHER .63X1.0X.05 Price: $3.45 |
| 71 |
21543704 |
RING, RET 62 EXT Price: $1.45 |
| 74 |
21543788 |
WASHER .71 X 1.16 X .04 Price: $2.95 |
| 80 |
21543724 |
WASHER .5X1.0X.032 Price: $2.95 |
| 90 |
08616500 |
RING, RETAINING Price: $8.45 |
| 93 |
21500082 |
KIT, BEARING Price: $17.95 |
| 95 |
08614000 |
BEARING, BALL 25.4 X 52 X 15 Price: $19.95 |
| 96 |
08614300 |
SEAL, LIP Price: $13.95 |
| 111 |
21544058 |
KIT, FITTING 1/2 BEADED 9/16 Price: $29.45 |
| 140 |
21543870 |
SPACER Price: $9.95 |
| 141 |
21543867 |
ARM, NEUTRAL LEFT Price: $17.45 |
| 142 |
21543843 |
SHCS 5/16-24X1 PATCH Price: $3.95 |
| 170 |
08617400 |
PUCK BRAKE Price: $2.35 |
| 172 |
08618900 |
PLATE, PUCK Price: $1.30 |
| 176 |
08619000 |
BOLT HEX HD 1/4-20; X2 W/PATCH Price: $1.25 |
| 177 |
08618700 |
PIN BRAKE ACTUATING Price: $2.05 |
| 178 |
08615900 |
SPRING, CAMP. BRAKE ANTI-DRAG Price: $1.20 |
| 181 |
08611300 |
NUT Price: $1.90 |
| 182 |
08615300 |
PIN, COTTER 3/32 X 3/4 Price: $1.35 |
| 184 |
08611200 |
WASHER Price: $3.45 |
| 185 |
08300812 |
SPRING, TENSION (RTN) Price: $5.45 |
| 200 |
21543999 |
KIT, SEAL Price: $61.45 |
| 201 |
21544062 |
KIT, CENTER SECTION RH, CHRG Price: $232.85 |
| 203 |
21544060 |
KIT, CHARGE Price: $76.45 |
| 207 |
21500027 |
KIT- FAN/PULLEY Price: $32.45 |
