ENGINE SUMP, OIL PUMP, DIPSTICK/TUBE ASSEMBLY 16
Parts (26)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 3296-60 | NUT-LOCK, NI Price: $5.08 |
| 2 | 104-3546 | PULLEY-DRIVEN, LOW Price: $163.56 |
| 4 | 119-4775 | SPINDLE HOUSING ASM Price: $244.67 |
| 5 | 138-6416 | SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 6 | 104-3554 | SHAFT-SPINDLE Price: $67.98 |
| 7 | 104-8322 | WASHER-HARDENED Price: $23.22 |
| 12 | 582165501 | NEEDS DESCRIPTION Price: $27.99 |
| 15 | 576298701 | Plugs Price: $3.99 |
| 221 | 585091501 | NEEDS DESCRIPTION Price: $7.99 |
| 239 | 598673422 | Switches Price: $22.99 |
| 512 | 582166801 | NEEDS DESCRIPTION Price: $17.99 |
| 523 | 582166001 | NEEDS DESCRIPTION Price: $14.99 |
| 524 | 576302401 | Seals Price: $3.99 |
| 525 | 576302701 | Tubes Price: $19.99 |
| 552 | 576333501 | Bushings Price: $4.99 |
| 552A | 576297901 | Bushings Price: $5.99 |
| 615 | 576318101 | Retainers Price: $2.99 |
| 616 | 576302901 | Crankcases Price: $17.99 |
| 691 | 576320601 | Seals Price: $4.99 |
| 742 | 576297401 | Retainers Price: $2.99 |
| 847 | 598672399 | Dipsticks Price: $37.99 |
| 850 | 576295501 | Seals Price: $11.99 |
| 965 | 585084801 | NEEDS DESCRIPTION Price: $7.99 |
| 1013 | 576299101 | Nipple Price: $4.99 |
| 1017 | 576331001 | Screens Price: $7.99 |
| 1024 | 585130501 | NEEDS DESCRIPTION Price: $27.99 |
