| Ref | Part Number | Description |
|---|
| 1 |
114-5052 |
HOUSING ASM This part replaces 75-0020. Price: $2,587.20 |
| 1 |
121327X |
PULLEY TRANSAXLE Price: Call Us |
| 2 |
12000004 |
RING Price: Call Us |
| 2 |
75-0030 |
GASKET-HOUSING Price: $20.85 |
| 3 |
2228M |
SUB= 2228M1 Price: Call Us |
| 3 |
75-0040 |
SECTION-CENTER Price: $2,817.90 |
| 4 |
138788 |
TRANSAX. PRLES. Price: Call Us |
| 4 |
83-4780 |
HOUSING-PUMP, CHARGE Price: $714.23 |
| 5 |
72140506 |
BOLT Price: Call Us |
| 5 |
75-0060 |
PLUG Price: $22.19 |
| 6 |
104-2189 |
PLUG-THREAD, STRAIGHT This part replaces 75-0070. Price: $24.99 |
| 6 |
19111214 |
WASHER Price: Call Us |
| 7 |
71208 |
BUSHING Price: Call Us |
| 7 |
86-7520 |
RH TRUNNION COVER ASM Price: $486.26 |
| 8 |
422707 |
ENGINE B&S 18HP Price: Call Us |
| 8 |
75-0090 |
CAPSCREW-HH Price: $2.16 |
| 9 |
126197X |
WASHER Price: Call Us |
| 9 |
86-7530 |
LH TRUNNION COVER ASM Price: $465.32 |
| 10 |
100229X |
SUB= 100229L Price: Call Us |
| 10 |
75-0110 |
CAPSCREW-HH Price: $2.14 |
| 11 |
109740X |
REAR BAFFLE T Price: Call Us |
| 11 |
75-0120 |
CAPSCREW-HH Price: $7.11 |
| 12 |
17490512 |
SCREW Price: Call Us |
| 12 |
75-0130 |
DISCONTINUED Price: Call Us |
| 13 |
110-6342 |
SPRING This part replaces 75-0140. Price: $9.45 |
| 14 |
108373X |
MUFFLER HYT Price: Call Us |
| 14 |
75-0150 |
GUIDE-SEAL Price: $270.30 |
| 15 |
74780412 |
SUB= 74780414 Price: Call Us |
| 15 |
75-0160 |
PLUG-PIPE Price: $4.39 |
| 16 |
75-0170 |
PLUG-THREAD, STRAIGHT Price: $18.20 |
| 17 |
123796X |
BELT.GRDRV.94.75 Price: Call Us |
| 17 |
75-0180 |
CAPSCREW-HH Price: $19.18 |
| 18 |
75-0190 |
PLUG-SPECIAL Price: $124.62 |
| 18 |
8545J |
SUB= 272250 Price: Call Us |
| 19 |
106279X |
CONTROL KNOB LT Price: Call Us |
| 19 |
67-9090 |
PLUG This part replaces 75-0200. Price: $41.68 |
| 20 |
123781X |
SUB= 141002 Price: Call Us |
| 20 |
75-0210 |
O-RING Price: $7.35 |
| 21 |
105701X |
WASH-SHFT PLT LT Price: Call Us |
| 21 |
75-0220 |
PIN Price: $77.53 |
| 22 |
19171216 |
WASHER Price: Call Us |
| 22 |
75-0230 |
SEAL-LIP Price: $80.68 |
| 23 |
75-0240 |
O-RING Price: $2.36 |
| 23 |
76020416 |
PIN COTTER 1/8 Price: Call Us |
| 24 |
17490612 |
SCREW Price: Call Us |
| 24 |
75-0250 |
DISCONTINUED Price: Call Us |
| 25 |
129921 |
KEEPER.BELT.ENG.L Price: Call Us |
| 25 |
75-0260 |
VALVE-RELIEF Price: $97.16 |
| 26 |
74760616 |
BOLT Price: Call Us |
| 26 |
75-0270 |
SPRING Price: $9.79 |
| 27 |
19131312 |
WASHER Price: Call Us |
| 27 |
75-0280 |
SPRING Price: $7.03 |
| 28 |
73680600 |
SUB= 73690600 Price: Call Us |
| 28 |
75-0290 |
DISCONTINUED Price: Call Us |
| 29 |
8883R |
PEDAL COVER T Price: Call Us |
| 30 |
122424X |
SUB= 149001 Price: Call Us |
| 30 |
75-0310 |
SHIM Price: $131.21 |
| 31 |
1572H |
SUB= 2882J Price: Call Us |
| 31 |
75-0320 |
NIPPLE Price: $89.72 |
| 32 |
19211616 |
WASHER LT Price: Call Us |
| 32 |
75-0330 |
SEAL-LIP Price: $31.04 |
| 33 |
75-0340 |
BEARING-NEEDLE Price: $86.35 |
| 34 |
75-0350 |
PIN Price: $8.75 |
| 35 |
137140 |
SUB= 142600 Price: Call Us |
| 35 |
75-0360 |
GEROTOR Price: $430.63 |
| 36 |
136715 |
SUB= 140312 Price: Call Us |
| 36 |
75-0370 |
O-RING Price: $10.08 |
| 37 |
109070X |
BELT KEEPER LT Price: Call Us |
| 37 |
75-0380 |
PLATE-VALVE Price: $518.86 |
| 38 |
4470J |
SPACER T Price: Call Us |
| 38 |
75-0390 |
DISCONTINUED Price: Call Us |
| 39 |
123674X |
PULLEY.IDLER.FLAT Price: Call Us |
| 39 |
75-0400 |
PLATE-THRUST Price: $41.27 |
| 40 |
74760644 |
BOLT Price: Call Us |
| 40 |
75-0410 |
O-RING Price: $5.70 |
| 41 |
136906 |
PULLEY ENGINE Price: Call Us |
| 41 |
86-7540 |
SHAFT-PUMP Price: $910.85 |
| 42 |
10040700 |
LOCKWASHER Price: Call Us |
| 42 |
75-0430 |
RING-RETAINING Price: $23.82 |
| 43 |
71170768 |
SUB= 150280 Price: Call Us |
| 43 |
75-0440 |
SHAFT-MOTOR Price: $550.98 |
| 44 |
123791X |
KEEPER BELT LH Price: Call Us |
| 44 |
75-0450 |
COLLAR Price: $44.00 |
| 45 |
75-0460 |
BEARING-BALL Price: $175.71 |
| 46 |
123776X |
BRKT TRANS RH Price: Call Us |
| 46 |
75-0470 |
CYLINDER BLOCK KIT Price: $1,746.91 |
| 47 |
120183X |
NYLON BEARING Price: Call Us |
| 47 |
94-3975 |
PIN This part replaces 75-0480. Price: $5.80 |
| 48 |
71040412 |
SUB= 74550412 Price: Call Us |
| 49 |
19091216 |
WASHER PM Price: Call Us |
| 49 |
75-0500 |
BEARING-NEEDLE Price: $83.78 |
| 50 |
75-0510 |
PIN Price: $8.40 |
| 51 |
73680500 |
SUB= 73690500 Price: Call Us |
| 51 |
75-0520 |
BEARING-BALL Price: $88.98 |
| 52 |
74760540 |
BOLT Price: Call Us |
| 52 |
75-6930 |
VALVE-SCREW Price: $97.36 |
| 53 |
123787X |
STRAP TORQUE Price: Call Us |
| 53 |
32120-74 |
RING-SNAP Price: $0.54 |
| 54 |
123780X |
BRKT TRANS LH Price: Call Us |
| 55 |
93-0097 |
VALVE-SCREW Price: $235.37 |
| 56 |
76020412 |
COTTER PIN Price: Call Us |
| 57 |
133261 |
BRAKE PARK ROD Price: Call Us |
| 58 |
123786X |
ROD BRAKE Price: Call Us |
| 59 |
7733J |
SUB= 71673 Price: Call Us |
| 61 |
19131316 |
WASHER Price: Call Us |
| 62 |
123800X |
WASHER Price: Call Us |
| 64 |
19111012 |
WASHER T Price: Call Us |
| 65 |
127783 |
SUB= 139245 Price: Call Us |
| 66 |
123789X |
ARM IDLER Price: Call Us |
| 67 |
123205X |
RETAIN BELT Price: Call Us |
| 68 |
74760624 |
SUB= 74930624 Price: Call Us |
| 69 |
110812X |
WASHER LT Price: Call Us |
| 70 |
12000039 |
KLIP RING Price: Call Us |
| 73 |
73530400 |
NUT 1/4-28 Price: Call Us |
| 74 |
132773 |
SUB= 133439 Price: Call Us |
| 75 |
17720410 |
SCREW LT Price: Call Us |
| 78 |
73510600 |
NUT Price: Call Us |
| 79 |
123190X |
SHIELD HEAT FRT Price: Call Us |
| 81 |
108097X |
SPACER HYT Price: Call Us |
| 82 |
108236X |
BRACKET LT Price: Call Us |
| 83 |
12000053 |
E RING HYT Price: Call Us |
| 85 |
9396E |
SQ KEY STD Price: Call Us |
| 87 |
17490624 |
SCREW LT Price: Call Us |
| 88 |
19212016 |
WASHER D Price: Call Us |
| 89 |
74760612 |
SUB= 74780612 Price: Call Us |
| 91 |
12000008 |
KLIP RING Price: Call Us |
| 94 |
11050600 |
LOCKWASHER Price: Call Us |
| 97 |
73800600 |
NUT Price: Call Us |
| 98 |
137141 |
BRACKET.ASM.MTG Price: Call Us |
| 102 |
2751R |
CLIP T Price: Call Us |
| 104 |
132922 |
SPARK ARREST KIT Price: Call Us |
| 105 |
110422X |
SUB= 146682 Price: Call Us |
| 106 |
4497H |
RETAINER M Price: Call Us |
| 108 |
13280336 |
PIPE NIPPLE LT Price: Call Us |
| 110 |
10040400 |
LOCKWASHER Price: Call Us |
| 112 |
13200300 |
ELBOW Price: Call Us |
| 116 |
17021008 |
SCREW Price: Call Us |
