| Ref | Part Number | Description |
|---|
| 1 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 1 |
871191008 |
SCREW.PNHD.10-24 Price: $7.99 |
| 1 |
MA-19642301AG0 |
PEDAL HST Not Available Price: |
| 2 |
532126956 |
PANEL Price: $31.99 |
| 2 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 2 |
MA-19642303AG0 |
ARM Not Available Price: |
| 3 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 3 |
532104164 |
TIE CABLE CRT Price: $4.99 |
| 3 |
MA-19632304000 |
BOLT SET Not Available Price: |
| 4 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 4 |
532008206 |
GRIP T This part replaces 532124797. Price: $9.99 |
| 4 |
MA-A3030110003 |
NUT Not Available Price: |
| 5 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 5 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 6 |
532081328 |
SHOULDER BOLT ST Price: $4.99 |
| 6 |
82-9850-03 |
AXLE-REAR Price: $1,614.33 |
| 7 |
532109335 |
SHIFT HANDLE CRT Price: $3.99 |
| 7 |
93-0311-03 |
SPINDLE-WHEEL, LH Price: $378.60 |
| 7 |
MA-19642308000 |
PLATE Not Available Price: |
| 8 |
532109313 |
GROMMET.RUBBER.CRT.TILLER Price: $3.99 |
| 8 |
MA-05200130020 |
COTTER PIN Not Available Price: |
| 9 |
117-8969 |
HUB ASM This part replaces 69-2960-03. Price: $336.24 |
| 9 |
532109337 |
SHIFT ROD CRT Price: $32.99 |
| 9 |
MA-19632311000 |
SHAFT PEDAL Not Available Price: |
| 10 |
596728201 |
Bolts This part replaces 872110608. Price: $3.99 |
| 10 |
93-0310-03 |
SPINDLE-WHEEL, RH Price: $584.69 |
| 10 |
MA-05500006032 |
SPRING PIN Not Available Price: |
| 11 |
106-6895-03 |
BALL JOINT ASM This part replaces 69-9810-03. Price: $258.08 |
| 11 |
532109229 |
LOCK.HANDLE.CRT Price: $5.99 |
| 11 |
MA-19632313000 |
ARM LOCK Not Available Price: |
| 12 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 12 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 12 |
MA-19632312000 |
SHAFT Not Available Price: |
| 13 |
23-7270 |
NUT-LUG Price: $10.37 |
| 13 |
596140201 |
Washers This part replaces 819131611. Price: $2.99 |
| 13 |
MA-11931812000 |
COVER,PEDAL Not Available Price: |
| 14 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 14 |
532109228 |
LEVER.LOCK.CRT Price: $11.99 |
| 14 |
MA-10320228000 |
COVER PEDAL Not Available Price: |
| 15 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 15 |
532440884 |
HANDLE.ASM.TILLER.GREY. This part replaces 532125011. Price: $99.99 |
| 16 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 16 |
82-9210 |
SHAFT-PIVOT Price: $187.73 |
| 16 |
MA-19632317000 |
SPRING Not Available Price: |
| 17 |
3220-7 |
NUT-JAM Price: $4.09 |
| 17 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 18 |
873271000 |
NUT This part replaces 873731000. Price: $2.99 |
| 18 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 19 |
532102162 |
CABLE CLUTCH CRT Price: $17.99 |
| 19 |
60-3670 |
PIN Price: $12.56 |
| 20 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 20 |
532009484 |
CONDUIT.CLIP.PLATED Price: $4.99 |
| 20 |
MA-19632361000 |
SHAFT A Not Available Price: |
| 21 |
58-6520 |
DECAL-GREASE Price: $2.57 |
| 21 |
817021008 |
SCREW This part replaces 532086777. Price: $3.99 |
| 21 |
MA-19632366000 |
GUIDE A Not Available Price: |
| 22 |
115-8014 |
CYLINDER-HYDRAULIC This part replaces 77-4800. Price: $1,015.97 |
| 22 |
532102604 |
GRIP BAR CRT(1) Price: $4.99 |
| 22 |
MA-19871263000 |
SPRING PEDAL Not Available Price: |
| 23 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 23 |
532102744 |
CLAMP.BAR.CRT.BLACK Price: $4.99 |
| 23 |
MA-19632365000 |
GUIDE B Not Available Price: |
| 24 |
48-6660 |
WASHER Price: $5.22 |
| 24 |
532105216 |
BAR ASSY CONTROL Price: $14.08 |
| 24 |
MA-19632362000 |
SHAFT B Not Available Price: |
| 25 |
48-6640 |
BEARING Price: $10.04 |
| 25 |
532175769 |
CONTROL.THROTTLE This part replaces 532127012. Price: $29.99 |
| 25 |
MA-A6010101000 |
PLUG Not Available Price: |
| 26 |
596133401 |
Bolts This part replaces 872140404. Price: $1.99 |
| 26 |
MA-19632363000 |
CAP A Not Available Price: |
| 27 |
MA-08301100120 |
O-RING Not Available This part replaces MA-08300100120. Price: |
| 28 |
32136-13 |
NUT-SHH Price: $2.85 |
| 28 |
MA-19632364000 |
CAP Not Available Price: |
| 29 |
MA-08300100260 |
O-RING Not Available Price: |
| 30 |
69-9870 |
WIDE WHEEL AND 6-PLY TIRE ASM Price: $513.71 |
| 31 |
MA-07310001201 |
LINER Not Available Price: |
| 32 |
110-9719-03 |
TIE ROD ASM This part replaces 82-9260-03. Price: $380.21 |
| 32 |
MA-07310001203 |
LINER Not Available Price: |
| 33 |
MA-07310001205 |
LINER Not Available Price: |
| 34 |
MA-A2000105008 |
BOLT Not Available Price: |
| 35 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 35 |
MA-08330000500 |
WASHER,SEAL Not Available Price: |
| 36 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
| 36 |
MA-19632367000 |
COLLAR Not Available Price: |
| 37 |
340-54 |
ELBOW-45 DEG Price: $40.72 |
| 37 |
MA-A3500106000 |
NUT Not Available Price: |
| 38 |
69-2980 |
SEAL Price: $33.94 |
| 38 |
MA-08300100060 |
O-RING Not Available Price: |
| 39 |
254-106 |
CONE-BEARING, TAPERED Price: $19.51 |
| 42 |
MA-A3010108002 |
NUT Not Available Price: |
| 43 |
254-92 |
CONE-BEARING, OUTER Price: $15.84 |
| 43 |
MA-10302436000 |
LINK-BALL (RH) Not Available Price: |
| 44 |
MA-H1550110020 |
BOLT,W/WASHER Not Available Price: |
| 45 |
MA-19631724000 |
PLATE Not Available Price: |
| 46 |
MA-F1550110020 |
BOLT,W/SPRING WASH Not Available Price: |
| 47 |
MA-07420100800 |
RING, SNAP Not Available Price: |
| 48 |
MA-19642332000 |
PLATE Not Available Price: |
| 50 |
MA-19632309000 |
BUSHING Not Available Price: |
| 51 |
MA-08331001000 |
SEAL, WASHER Not Available Price: |
