| Ref | Part Number | Description |
|---|
| 1 |
60-5860 |
PLUG Price: $27.34 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 2 |
60-5720 |
O-RING Price: $1.86 |
| 4 |
60-5760 |
PIN Price: $2.58 |
| 6 |
60-5710 |
PLUG Price: $13.84 |
| 7 |
60-5780 |
GEAR Price: $268.84 |
| 8 |
60-5730 |
DISC Price: $1.52 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 9 |
60-5820 |
SPRING Price: $12.04 |
| 10 |
60-5770 |
DISCONTINUED Price: Call Us |
| 11 |
42-3140 |
CAPSCREW Price: $9.42 |
| 11 |
532414336 |
KIT.SVC.CLUTCH.ELECTRIC. This part replaces 532179334. Price: $329.99 |
| 12 |
49-2640 |
SEAL-SHAFT Price: $14.83 |
| 12 |
532402980 |
PULLEY.ENGINE.ENX Price: $49.99 |
| 13 |
60-5890 |
WASHER Price: $4.68 |
| 15 |
49-2660 |
FRONT PLT ASM RH Price: $449.50 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 16 |
56-6710 |
O-RING This part replaces 42-3120. Price: $3.82 |
| 17 |
49-2680 |
MOLDED O-RING Price: $4.51 |
| 18 |
49-2700 |
DISCONTINUED Price: Call Us |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 19 |
49-2690 |
DISCONTINUED Price: Call Us |
| 20 |
49-2670 |
WEAR PLATE Price: $66.47 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 21 |
60-5740 |
DISCONTINUED Price: Call Us |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
60-5790 |
SPRING Price: $7.93 |
| 24 |
60-5880 |
DISCONTINUED Price: Call Us |
| 25 |
60-5830 |
DISCONTINUED Price: Call Us |
| 26 |
60-5840 |
DISCONTINUED Price: Call Us |
| 27 |
60-5850 |
DISCONTINUED Price: Call Us |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 28 |
60-5870 |
PLUG Price: $28.47 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
60-5810 |
DISCONTINUED Price: Call Us |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 31 |
60-5800 |
SEAT Price: $65.96 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532150280. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 84 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
