| Ref | Part Number | Description |
|---|
| 1 |
127-3101 |
OIL LUBE PUMP ASM Price: $229.50 |
| 1 |
532124415 |
STEERING WHEEL Price: $58.99 |
| 2 |
532178557 |
AXLE.FRONT.CAST.MACHINE.W/ZERK This part replaces 532137094. Price: $179.99 |
| 3 |
532154920 |
SPINDLE ASS'Y LH Price: $14.99 |
| 4 |
532154921 |
SPINDLE ASM RH Price: $15.99 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
532154432 |
LINK.DRAG.DROPPED.LT Price: $76.99 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 13 |
127-3004 |
GASKET Price: $2.73 |
| 13 |
532154779 |
BEARING AXLE Price: $8.99 |
| 14 |
125-7232 |
BOLT Price: $3.28 |
| 15 |
125-7171 |
PLUG-DRAIN Price: $23.08 |
| 15 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 16 |
125-6987 |
DIPSTICK Price: $68.96 |
| 17 |
125-6954 |
GUIDE-DIPSTICK Price: $9.80 |
| 17 |
531166901 |
SERVICE KIT SHAFT ASM ST This part replaces 532156546. Price: $42.99 |
| 18 |
125-7022 |
GASKET Price: $7.07 |
| 18 |
532057079 |
THRUST WASHER Price: $1.99 |
| 19 |
125-7023 |
PIPE ASM Price: $44.23 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $8.99 |
| 20 |
125-7217 |
BOLT Price: $4.58 |
| 20 |
596582301 |
Washers This part replaces 532126684. Price: $2.99 |
| 21 |
127-3014 |
COOLER ASM Price: $1,323.82 |
| 21 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 22 |
127-2985 |
O-RING Price: $6.88 |
| 22 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871100410. Price: $3.99 |
| 23 |
127-3015 |
BRACKET-COOLER Price: $73.15 |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $29.99 |
| 24 |
125-7041 |
NUT-COOLER, OIL Price: $51.50 |
| 25 |
127-3009 |
BRACKET ASM Price: $82.05 |
| 25 |
532154406 |
BRACKET STEERING Price: $6.99 |
| 26 |
127-3009 |
BRACKET ASM This part replaces 125-6930. Price: $82.05 |
| 27 |
127-3010 |
STUD Price: Call Us |
| 27 |
532136874 |
GEAR.SECTOR Price: $69.99 |
| 28 |
125-7024 |
GASKET Price: $3.16 |
| 29 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 30 |
125-6990 |
JOINT Price: $64.80 |
| 31 |
127-3102 |
PIPE-COOLING, WATER Price: $45.56 |
| 32 |
125-7162 |
CLIP Price: $6.55 |
| 32 |
532186799 |
ROD.TIE.NON-ADJUSTABLE This part replaces 532137347. Price: $59.99 |
| 35 |
127-3103 |
HOSE-COOLING, WATER Price: $48.62 |
| 36 |
125-7162 |
CLIP Price: $6.55 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
127-3007 |
TUBE Price: $19.01 |
| 38 |
532124416 |
INSERT,STR WHEEL Price: $7.89 |
| 39 |
125-7001 |
ELBOW Price: $40.49 |
| 39 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133808. Price: $4.99 |
| 40 |
127-3176 |
O-RING Price: $2.87 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
125-7595 |
BOLT Price: $2.39 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532100711. Price: $7.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532155092. Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 51 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 54 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 62 |
584371701 |
KIT.STEER.ASM.P/L This part replaces 532156594. Price: $119.99 |
| 63 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 65 |
531152101 |
SERVICE KIT SPACER AXLE SPACER This part replaces 532154780. Price: $17.99 |
| 66 |
532154404 |
BEARING ARM Price: $3.99 |
| 67 |
874781044 |
Bolt, Hex 5/8 -11 x 2 - 3/4 Gr. 5 Price: $3.99 |
| 68 |
532154429 |
AXLE, BRACE Price: $11.99 |
