| Ref | Part Number | Description |
|---|
| 3 |
581805901 |
BELT.42.SZ.117.3 Price: $79.99 |
| 4 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 5 |
532400140 |
BELT KEEPER.MANDREL.38"COATED Price: $39.99 |
| 8 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 9 |
532417645 |
BRACKET.CLUTCH.CABLE Price: $4.99 |
| 10 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC This part replaces 532193108. Price: $29.99 |
| 11 |
532401872 |
SPRING RETURN Price: $4.99 |
| 12 |
599698501 |
SPRINGS This part replaces 581542601. Price: $5.99 |
| 13 |
532123713 |
SPRING TORSION Price: $6.99 |
| 14 |
532195945 |
PULLEY.MANDREL.5.438.P Price: $12.99 |
| 15 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 16 |
596718601 |
Coupling This part replaces 539116689. Price: $2.99 |
| 17 |
574693302 |
ARM.BRAKE.42.BLACK Price: $17.99 |
| 18 |
574694505 |
ARM DECK IDLER ARM.IDLER.BLACK This part replaces 574694502. Price: $19.99 |
| 19 |
532400130 |
BRAKE.ARM.LH.38"TEX.COATED This part replaces 532199470. Price: $14.99 |
| 20 |
581506902 |
Links This part replaces 532195740. Price: $9.99 |
| 21 |
581514302 |
SWIVEL TRUNION CLEAR ZINC This part replaces 581514301. Price: $4.99 |
| 22 |
532416405 |
COUPLING.QUICK CONNECT Price: $8.99 |
| 23 |
585323901 |
BEARING.MANDREL.TOP.EXTENDED Price: $12.99 |
| 24 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 587256501. Price: $49.99 |
| 25 |
581866301 |
LINK Price: $6.99 |
| 26 |
581866201 |
LINK SZ42 ADJ, PINNED END Price: $5.99 |
| 27 |
584300001 |
KIT.SERVICE.42SZ.MANUAL.CLUTCH This part replaces 581542701. Price: $119.99 |
| 28 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 29 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 587253301. Price: $49.99 |
| 30 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 31 |
525851801 |
GUIDE, BELT Price: $11.99 |
| 33 |
577209101 |
KEEPER, BELT Price: $8.99 |
| 34 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 35 |
532165898 |
SPRING.RETAINER.YELLOW.ZINC Price: $3.99 |
| 36 |
596273101 |
Pins This part replaces 539976989. Price: $2.99 |
| 37 |
596582201 |
Bolts This part replaces 539976935. Price: $2.99 |
| 38 |
596564403 |
Screws This part replaces 874780632. Price: $3.99 |
| 39 |
582740701 |
BOLT This part replaces 874780628. Price: $4.99 |
| 40 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 41 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 42 |
532137729 |
SCREW.1/4-20X5/8 This part replaces 539107631. Price: $3.99 |
| 43 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 44 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 45 |
596241101 |
Bolts This part replaces 539113621. Price: $2.99 |
| 46 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 47 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 48 |
532110452 |
NUT PUSH M Price: $2.99 |
| 49 |
596134801 |
Nuts This part replaces 539107590. Price: $1.00 |
| 50 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 51 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 52 |
596584101 |
Nuts This part replaces 539991073. Price: $2.99 |
| 53 |
596040901 |
Hardware This part replaces 539990223. Price: $2.99 |
| 54 |
596230801 |
Nuts This part replaces 539200282. Price: $2.99 |
| 55 |
573975201 |
NUT, 7/16-20 HEX NYLOC ZC Price: $2.99 |
| 56 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 57 |
819171713 |
WASHER STEEL Price: $2.99 |
| 58 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 59 |
539102998 |
WASHER, FRICTION Price: $4.99 |
| 60 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 61 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
