| Ref | Part Number | Description |
|---|
| 1 |
104-3554 |
SHAFT-SPINDLE Price: $67.98 |
| 1 |
30739 |
SHAFT & LEV Price: Call Us |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $139.99 |
| 2 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 2 |
30357 |
SCREW Price: $2.62 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
119-4546 |
SPINDLE HOUSING ASM Price: $244.67 |
| 3 |
31617 |
SHUTTER Price: Call Us |
| 4 |
106-7159 |
O-RING Price: $0.99 |
| 4A |
30984 |
SHAFT & LEV Price: Call Us |
| 5 |
104-3545 |
PULLEY-DRIVING Price: $250.04 |
| 6 |
104-8322 |
WASHER-HARDENED Price: $23.22 |
| 6 |
650399 |
SCREW This part replaces 630605. Price: $1.20 |
| 7 |
27112 |
IDLE SCREW Price: $1.26 |
| 7 |
3296-60 |
NUT-LOCK, NI Price: $5.08 |
| 8 |
27114 |
SPRING Price: $2.62 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $11.99 |
| 8A |
27114 |
SPRING Price: $2.62 |
| 10 |
30927 |
SHUTTER Price: Call Us |
| 11 |
30356 |
GASKET Price: $2.22 |
| 12 |
27108 |
GASKET Price: Call Us |
| 13 |
29154 |
INLET NEEDLE Price: Call Us |
| 14 |
30354 |
FLOAT Price: Call Us |
| 15 |
27106 |
FLOAT SHAFT Price: $2.04 |
| 16 |
27136A |
DRAIN ASSY This part replaces 27136. Price: $5.96 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 17 |
32131 |
FLOAT BOWL This part replaces 30350. Price: $11.15 |
| 18 |
27136A |
DRAIN ASSY This part replaces 27137. Price: $5.96 |
| 19 |
27136A |
DRAIN ASSY This part replaces 27138. Price: $5.96 |
| 20 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 21 |
28945 |
POWER SCREW Price: $18.86 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $29.99 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 22 |
630786 |
SPRING Price: $1.25 |
| 23 |
31618 |
NOZZLE Price: Call Us |
| 25 |
27554 |
GASKET Price: $1.05 |
| 25 |
532412894 |
CABLE.STARTER.6GA.BL/RED.14. Price: $11.99 |
| 26 |
27544 |
O RING Price: $1.26 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
650506 |
SCREW This part replaces 630606. Price: $0.87 |
| 27 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 28 |
30815 |
BAFFLE Price: Call Us |
| 28 |
532198885 |
CABLE.BLACK.18"REAR.BA Price: $19.99 |
| 29 |
30817 |
SCREW Price: Call Us |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $24.99 |
| 30 |
31352 |
RET SPRING Price: Call Us |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $6.99 |
| 34 |
532110712 |
SWITCH LT Price: $4.99 |
| 40 |
532401098 |
HARNESS IGN. DASH Price: $74.99 |
| 41 |
539990071 |
HCS 1/4-20. This part replaces 817720408. Price: $1.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042801 |
SOLENOID.STARTER.BRASS.PLUNGER This part replaces 532192507. Price: $7.99 |
| 55 |
532171877 |
BOLT, 5/16-18 X 1 3/4 This part replaces 817060512. Price: $3.99 |
| 71 |
532400449 |
HARNESS.IGN.CHASS.TEX.REAR.BAT Price: $24.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $11.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $2.99 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
532192540 |
SCREW.PLASTITE Price: $2.99 |
