| Ref | Part Number | Description |
|---|
| 1 |
23-8880 |
BRG DRIVER Price: $160.79 |
| 2 |
3219-18 |
NUT-HEX Price: $3.26 |
| 2 |
530071605 |
KIT HARNESS CLAMP This part replaces 530055392. Price: $2.99 |
| 3 |
23-8840 |
STUD Price: $65.53 |
| 3 |
530058563 |
Clamp-Bracket Price: $2.99 |
| 4 |
22-6090 |
DISCONTINUED Price: Call Us |
| 4 |
530015886 |
Screw Price: $1.99 |
| 5 |
23-8850 |
DISC-GET FROM K-LINE IND TOR238900A Price: Call Us |
| 5 |
530058765 |
Clamp-Handlebar (1") Price: $2.99 |
| 5 |
530058766 |
Clamp-Handlebar (7/8") Price: $2.99 |
| 6 |
530095812 |
Bracket-Shield Price: $1.99 |
| 7 |
530096183 |
Flexshaft-Split boom Price: $2.99 |
| 8 |
530071585 |
Assy-Gearbox Price: $54.99 |
| 9 |
530016312 |
Screw Price: $1.99 |
| 10 |
530071605 |
KIT HARNESS CLAMP This part replaces 530055395. Price: $2.99 |
| 11 |
530016406 |
Screw Price: $1.99 |
| 12 |
530015886 |
Screw Price: $1.99 |
| 13 |
530071907 |
Assy.-Driveshaft Price: $17.99 |
| 14 |
530016014 |
Screw Price: $1.99 |
| 15 |
530016224 |
Screw-Alignment Price: $1.99 |
| 16 |
530095815 |
Dust cup - Blade Price: $6.99 |
| 17 |
530094417 |
Shoulder Strap This part replaces 530094408. Price: $20.65 |
| 18 |
530052285 |
Limiter-Line Price: $1.99 |
| 19 |
530015805 |
Screw Price: $1.99 |
| 20 |
530015820 |
Bolt Price: $1.99 |
| 21 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 24 |
530095772 |
Assy-Hub Price: $5.42 |
| 25 |
530053241 |
Spring Price: $1.99 |
| 26 |
530401957 |
Retainer Price: $1.99 |
| 27 |
952711551 |
Accy--Spool w/Line This part replaces 952711580. Price: $8.95 |
| 28 |
530071383 |
Kit-Blade Shield Price: $9.99 |
| 29 |
952711584 |
Accy.-Weed Blade (8") Price: $12.81 |
| 30 |
530095816 |
Washer-Blade Retaining Price: $6.99 |
| 31 |
530016240 |
Washer-Belleville Price: $1.99 |
| 32 |
530015793 |
Nut-Flange Price: $1.99 |
| 33 |
530031159 |
Wrench-Hex (5/32") Price: $1.99 |
