| Ref | Part Number | Description |
|---|
| 1 |
132-5640-03 |
FRAME-CONSOLE Price: $290.14 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 2 |
132-7615-03 |
PLATE-MONITOR Price: $7.98 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
132-7610-0P |
RETAINER - MONITOR This part replaces 132-7610-03. Price: $35.34 |
| 4 |
125-5320 |
INFOCENTER Price: $1,675.09 |
| 5 |
132-7668 |
SCREW-PPH Price: $0.34 |
| 6 |
132-7617 |
HOOD-CONSOLE Price: $80.38 |
| 7 |
132-7611 |
COVER-LH Price: $93.68 |
| 8 |
132-7612 |
COVER-RH Price: $93.68 |
| 8 |
532176689 |
BOX.BATTERY.FENDER Price: $9.99 |
| 9 |
132-5645-03 |
PANEL-ARM Price: $67.17 |
| 10 |
131-9637 |
ARMREST-QUICK FIND Price: $68.09 |
| 11 |
112-3306 |
NUT Price: $0.82 |
| 12 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 13 |
132-7704-03 |
RETAINER-HARNESS, CONSOLE Price: $14.55 |
| 16 |
114-3321 |
CONTROLLER-TEC Price: $1,515.96 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
119-4012 |
SCREW-HWHTF Price: $0.61 |
| 18 |
32144-85 |
SCREW-HWH Price: $1.59 |
| 19 |
3250-12 |
SCREW-PPH Price: $0.25 |
| 20 |
132-7695 |
DECAL-CONSOLE Price: $12.17 |
| 21 |
100-8490 |
SWITCH-ROCKER, ON-NONE-ON Price: $33.76 |
| 21 |
532175688 |
HARNESS.W/LIGHT SOCKET Price: $29.99 |
| 22 |
104-9007 |
SWITCH-ROCKER Price: $75.33 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
100-1535 |
SWITCH Price: $84.91 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $8.99 |
| 24 |
95-8999 |
SWITCH Price: $42.14 |
| 25 |
122-0111 |
THROTTLE-ELECTRONIC Price: $238.70 |
| 25 |
532146147 |
CABLE BATTERY Price: $22.99 |
| 26 |
125-7996 |
SWITCH-PB, MOMENTARY Price: $123.36 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 28 |
532004207 |
CABLE T This part replaces 532124773. Price: $4.99 |
| 29 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $12.99 |
| 30 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 31 |
131-8388 |
SOCKET-USB Price: $57.32 |
| 32 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 33 |
110-9380 |
SCREW-HWH Price: $1.89 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 34 |
132-7786 |
DECAL-QUICKFIND Price: $13.48 |
| 40 |
532179720 |
HARNESS.IGNITION Price: $99.99 |
| 41 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532178861. Price: $19.99 |
| 48 |
532140844 |
ADAPTER.AMMETER Price: $4.99 |
| 52 |
532141940 |
WIRE PROTECTION LOOP Price: $4.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532180449. Price: $4.99 |
