EXTERNAL POWER UNIT
Parts (79)
| Ref | Part Number | Description |
|---|---|---|
| A | A-277599 | Starter Assembly Price: Call Us |
| B | 237643 | Cover Price: Call Us |
| C | 277619 | Nut, Stop Price: Call Us |
| D | 277614 | Washer Price: Call Us |
| E | 277607 | Spring, Anti-Drift Price: Call Us |
| F | 277606 | Spacer Price: Call Us |
| G | 4875502 | Drive Price: Call Us |
| H | 4821101 | Thru Bolt Price: Call Us |
| J | 4822703 | Cap-Drive End Price: Call Us |
| K | 277611 | Washer Price: Call Us |
| L | 277605 | Armature Price: Call Us |
| M | 277612 | Cap, Comm. End Price: Call Us |
| N | 237761 | Kit, Hardware Price: Call Us |
| O | 237762 | Kit, Brush Holder Price: Call Us |
| 1 | 530027732 | Retainer Mount Price: $1.99 |
| 2 | 530016057 | Screw Price: $1.99 |
| 3 | 530027732 | Chain Catcher Retainer-Serv. Ref. 1 Price: $1.99 |
| 4 | 530027399 | Carb. Cover Bumper Price: $1.99 |
| 5 | 530027392 | Lower Isolator Price: $3.33 |
| 6 | 530010877 | Type I Price: $3.33 |
| 6 | 530069391 | Type II Price: $24.32 |
| 7 | 530027394 | Cylindrical Mount Price: $8.99 |
| 8 | 530027187 | Isolator Limiter Price: $1.99 |
| 9 | 530015650 | Screw-Pinch Clamp This part replaces 530015871. Price: $1.99 |
| 9 | 530015715 | Type I Price: $1.99 |
| 10 | 530027733 | Chain Catcher-Serv. Ref. 1 Price: $1.99 |
| 12 | 530010845 | Fuel Cap Ass'y. Price: $5.99 |
| 13 | 530027181 | Handguard Price: $3.33 |
| 14 | 530027191 | Bracket Price: $3.99 |
| 15 | 530015598 | Screw Price: $1.99 |
| 17 | 530024772 | Throttle Lock Spring Price: $1.99 |
| 18 | 530015716 | Screw Price: $1.99 |
| 19 | 530015406 | Screw Price: $1.99 |
| 20 | 530069279 | Cylinder Shield Kit (Inc.54.) Price: $3.33 |
| 21 | 530027178 | Carb. Cover Price: $3.33 |
| 22 | 530015650 | Screw-Pinch Clamp This part replaces 530015871. Price: $1.99 |
| 23 | 530027134 | Trigger Latch Spring Price: $1.99 |
| 24 | 530027133 | Throttle Trigger Price: $1.99 |
| 25 | 530027271 | Grommet Price: $1.99 |
| 26 | 530027121 | Bracket Price: $1.99 |
| 27 | 530069217 | Gasket Set Price: $3.33 |
| 28 | 530035201 | Carburetor (HDA-49) Price: $109.99 |
| 29 | 530023664 | Air Filter Plate Price: $1.99 |
| 30 | 530015735 | Carb. Mounting Stud Price: $0.93 |
| 31 | 530010855 | Model 305 & 335 Price: $11.20 |
| 31 | 530010892 | Model 285 Price: Call Us |
| 32 | 530027135 | Throttle Lockout Price: $1.99 |
| 33 | 530027207 | Rear Handle Cover Price: $11.99 |
| 34 | 530027073 | Throttle Wire Price: $2.99 |
| 35 | 530027075 | Choke Knob Price: $1.99 |
| 36 | 530027393 | Type I Price: $5.99 |
| 36 | 530036962 | Type II Price: $3.33 |
| 37 | 530001543 | Nut Price: Call Us |
| 38 | 530015701 | Dowel Pin Price: $1.99 |
| 39 | 530015724 | Screw Price: $1.99 |
| 40 | 530069216 | Line Kit (Bulk 530-008133) Price: $3.99 |
| 41 | 530095646 | Assy-Fuel Pickup This part replaces 530014199. Price: $2.99 |
| 42 | 530039129 | Grommet Price: $1.99 |
| 43 | 530069225 | Switch Kit Price: $6.99 |
| 44 | 530027138 | Lead Wire Ass'y. Price: $2.99 |
| 45 | 530015598 | Screw This part replaces 530015802. Price: $1.99 |
| 46 | 530027202 | Screw Retainer Price: $1.99 |
| 47 | 530025539 | Impulse Fitting Price: $1.99 |
| 48 | 530024475 | Vent Fitting Price: $1.99 |
| 49 | 530026119 | Check Valve Price: $1.99 |
| 50 | 530031159 | Hex Wrench (5/32) This part replaces 530031111. Price: $1.99 |
| 51 | 530027339 | Vent Plug Price: $2.52 |
| 52 | 530025922 | Air Box Plug Price: $1.99 |
| 53 | 530027341 | Clamp Price: $1.99 |
| 54 | 530027888 | Reflector Price: $3.33 |
| 55 | 952069253 | Carb. Cover Winter Kit Price: Call Us |
| 56 | 530069297 | Bracket Kit-Service Ref. 1 Price: $2.99 |
| 57 | 530015710 | Screw Price: $3.33 |
| 58 | 530015875 | Screw Price: $1.99 |
| 59 | 530015562 | Washer Price: $1.99 |
| 60 | 530015123 | Washer-Typell Only Price: $1.99 |
| 61 | 530037009 | AV Strap-Typell Only Price: $1.99 |
| 62 | 530037012 | Strap Retainer Plate-Type II Only Price: $1.99 |
| 63 | 530069384 | Isolator Ass'y. Kit-Type II Only Price: $17.99 |
