| Ref | Part Number | Description |
|---|
| 1 |
24-2090 |
STEERING WHEEL CAP Price: $30.55 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 2 |
530016153 |
Screw Price: $1.99 |
| 3 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 3 |
530059006 |
Reflector-Tape Price: $1.99 |
| 4 |
256-202 |
DISCONTINUED Price: Call Us |
| 4 |
530039198 |
Module - Ignition Price: $29.99 |
| 5 |
32141-111 |
NUT-ADJUSTING Price: $6.09 |
| 5 |
530016432 |
Screw Price: $1.99 |
| 6 |
29-1360 |
DISCONTINUED Price: Call Us |
| 6 |
530047442 |
Strap-Ground Price: $1.99 |
| 7 |
28-3940 |
STRG SHAFT COLLAR Price: $52.89 |
| 7 |
530057943 |
Assy-Wire Harness Price: $5.99 |
| 8 |
37-1100 |
DISCONTINUED Price: Call Us |
| 8 |
530058687 |
Cover-Air Filter Price: $4.99 |
| 9 |
302-16 |
ZERK FITTING Price: $7.10 |
| 9 |
530057925 |
Filter-Air Price: $0.99 |
| 10 |
29-0750 |
DISCONTINUED Price: Call Us |
| 10 |
530016425 |
Screw Price: $1.99 |
| 11 |
32121-31 |
PIN-SPRING Price: $0.26 |
| 11 |
530057892 |
Housing-Air Filter Price: $4.99 |
| 12 |
29-0770 |
DISCONTINUED Price: Call Us |
| 12 |
545070601 |
Carburetor Zama W-26 This part replaces 530035590. Price: $27.99 |
| 13 |
29-0670 |
STEERING SHAFT Price: $312.47 |
| 13 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 14 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 14 |
530047721 |
Bulb-Purge "snap-in" Price: $3.99 |
| 15 |
323-34 |
SCREW-HH Price: $0.54 |
| 16 |
32151-48 |
E-RING Price: $1.41 |
| 16 |
530071894 |
Gasket-cyl. o-ring (kit) Price: $6.99 |
| 17 |
3220-5 |
NUT-JAM Price: $0.65 |
| 17 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 18 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 19 |
27-2210 |
DISCONTINUED Price: Call Us |
| 19 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 20 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 21 |
321-4 |
SCREW-HH Price: $0.99 |
| 21 |
530057942 |
Backplate-Muffler Price: $5.99 |
| 22 |
29-0980 |
DISCONTINUED Price: Call Us |
| 22 |
530071894 |
Gasket-Muffler (kit) Price: $6.99 |
| 23 |
5-1706 |
SPRING-EXTENSION Price: $12.91 |
| 23 |
545006056 |
Kit-Spark Arrestor Price: $6.99 |
| 24 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 24 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 25 |
237-103 |
DISCONTINUED Price: Call Us |
| 25 |
545015301 |
Insert-Left (black) Cyl. This part replaces 530057885. Price: $2.99 |
| 26 |
3220-4 |
NUT-JAM Price: $2.49 |
| 26 |
545112901 |
Assy-Crankshaft/Rod This part replaces 530012537. Price: $49.99 |
| 27 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 27 |
530016417 |
Bolt Price: $1.99 |
| 28 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 28 |
530057941 |
Cap-Crankcase Price: $5.99 |
| 29 |
322-3 |
SCREW-HH Price: $0.79 |
| 29 |
530056363 |
Assy-Bearing/Seal Price: $11.99 |
| 30 |
353-618 |
DISCONTINUED Price: Call Us |
| 31 |
3253-16 |
DISCONTINUED Price: Call Us |
| 31 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 32 |
353-619 |
DISCONTINUED Price: Call Us |
| 32 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 33 |
38-3320 |
DISCONTINUED Price: Call Us |
| 33 |
545015401 |
Insert-Right (gray) Cyl. This part replaces 530057886. Price: $2.99 |
| 34 |
32121-35 |
PIN-ROLL Price: $0.79 |
| 34 |
530071894 |
Seal-Adaptor (kit) Price: $6.99 |
| 35 |
29-0960 |
DISCONTINUED Price: Call Us |
| 35 |
530016426 |
Screw Price: $1.99 |
| 36 |
29-0970 |
BRAKE ROD Price: $15.02 |
| 36 |
530071894 |
Gasket-Carb. (kit) Price: $6.99 |
| 37 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 37 |
530057926 |
Tube-Intake Price: $1.99 |
| 38 |
29-0950 |
DISCONTINUED Price: Call Us |
| 38 |
530057909 |
Wire-Throttle Price: $1.99 |
| 39 |
3220-7 |
NUT-JAM Price: $4.09 |
| 39 |
530016101 |
Nut-Carb. Price: $1.99 |
| 40 |
68-7530 |
BUSHING This part replaces 19-9750. Price: $19.19 |
| 41 |
32128-29 |
NUT-LOCK, FLANGE Price: $1.63 |
| 41 |
530031163 |
Wrench-Bar Price: $4.99 |
| 42 |
99-5686 |
RH SOCKET ASM This part replaces 21-0140. Price: $99.81 |
| 43 |
32136-4 |
NUT-HEX,SLOTTED Price: $1.56 |
| 44 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 45 |
10-7880 |
DISCONTINUED Price: Call Us |
| 46 |
10-7890 |
DISCONTINUED Price: Call Us |
| 47 |
10-8140 |
SPRING-LATCH, BRAKE Price: $18.38 |
| 48 |
329642 |
Nut Price: Call Us |
| 49 |
10-7850 |
LATCH-BRAKE, PARKING Price: $111.12 |
| 50 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 51 |
29-0890 |
DISCONTINUED Price: Call Us |
| 52 |
256-148 |
FLANGE BUSHING Price: $14.60 |
| 53 |
37-0500 |
FOLLOWER STEER SHAFT Price: $41.37 |
| 54 |
29-0720 |
DISCONTINUED Price: Call Us |
| 55 |
321-2 |
SCREW-HH Price: $2.79 |
| 56 |
29-0730 |
DISCONTINUED Price: Call Us |
| 57 |
29-0700 |
LOWER SLEEVE Price: $27.17 |
| 58 |
38-3330 |
EXT SPRING *O Price: $12.55 |
| 59 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 60 |
29-0910 |
DISCONTINUED Price: Call Us |
| 61 |
27-2830 |
PARKING BRAKE DECAL Price: $8.92 |
| 62 |
29-0710 |
UPPER SLEEVE Price: $20.85 |
| 63 |
29-0790 |
DISCONTINUED Price: Call Us |
| 64 |
3217-6 |
NUT-HEX Price: $1.19 |
| 65 |
322-6 |
SCREW-HH Price: $0.45 |
| 66 |
253-84 |
SEAL-OIL Price: $10.00 |
| 67 |
42-6490 |
DISCONTINUED This part replaces 38-9520. Price: Call Us |
| 68 |
29-1000 |
DISCONTINUED Price: Call Us |
| 69 |
39-4170 |
DISCONTINUED Price: Call Us |
| 70 |
29-0930 |
DISCONTINUED Price: Call Us |
| 71 |
29-2390 |
DISCONTINUED Price: Call Us |
| 72 |
32121-10 |
PIN-ROLL Price: $6.99 |
