| Ref | Part Number | Description |
|---|
| A |
117-6988 |
CHARGE PUMP KIT This part replaces 38-2670. Price: $1,753.04 |
| 1 |
186093X428 |
Wheel, Steering Price: Call Us |
| 1 |
92-5716 |
SECTION-CENTER Price: $2,472.04 |
| 2 |
184706 |
Axle Asm., Front Price: Call Us |
| 2 |
46-7310 |
SPRING Price: $18.78 |
| 4 |
403087 |
Spindle Asm., LH Price: Call Us |
| 4 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 5 |
403088 |
Spindle Asm., RH Price: Call Us |
| 6 |
25-2450 |
PLATE-SWASH, VARIABLE Price: $896.81 |
| 6 |
6266H |
Bearing, Race Thrust Harden Price: Call Us |
| 7 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 7 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 8 |
12000029 |
Ring, Klip #T5304-75 Price: Call Us |
| 9 |
121232X |
Cap, Spindle Price: Call Us |
| 10 |
251-8 |
BEARING-BALL Price: $30.06 |
| 11 |
94-2975 |
SEAL-SHAFT Price: $24.63 |
| 12 |
28-3640 |
SHAFT-PUMP Price: $1,171.13 |
| 13 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 13 |
38-2680 |
PIN Price: $23.93 |
| 14 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 14 |
28-3520 |
O-RING Price: $8.44 |
| 15 |
73540600 |
Nut, Crown Lock 3/8-24 unf Price: Call Us |
| 16 |
408219 |
Shaft Steering Price: Call Us |
| 19 |
194729 |
Plate Steering Price: Call Us |
| 19 |
25-2460 |
PLUG-HH Price: $37.38 |
| 20 |
199743X428 |
Boot, Steering Price: Call Us |
| 21 |
186737 |
Adapter, Wheel Steering Price: Call Us |
| 21 |
25-2460 |
PLUG-HH Price: $37.38 |
| 22 |
194845 |
Bushing, Strg. Blk Price: Call Us |
| 22 |
28-3400 |
O-RING Price: $6.67 |
| 23 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 26 |
186095X428 |
Insert, Wheel Steering Price: Call Us |
| 28 |
17000612 |
Screw 3/8-16 x 3/4 Price: Call Us |
| 28 |
83-3880 |
PIN-SPRING Price: $2.29 |
| 30 |
28-3670 |
SHAFT-TRUNNION Price: $149.64 |
| 35 |
194732 |
Gear, Sector Plate Price: Call Us |
| 42 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 43 |
110-3051 |
PLATE-VALVE Price: $684.62 |
| 45 |
19113812 |
Washer 11/32 x 2-3/8 x 12 Ga. Price: Call Us |
| 47 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 49 |
83-7260 |
CONE-RELIEF, CHARGE This part replaces 67-8070. Price: $50.57 |
| 50 |
28-3480 |
BEARING Price: $74.83 |
| 50 |
73900600 |
Nut Lock 3/8-16 UNC Price: Call Us |
| 51 |
73940800 |
Nut Hex Jam Toplock 1/2-20 unf Price: Call Us |
| 53 |
188967 |
Washer Hardened .793 x 1.637 x .060 Price: Call Us |
| 54 |
74760636 |
Bolt Hex 3/8-16 UNC x 2-1/4 Price: Call Us |
| 55 |
197636 |
Spacer Brace Axle Price: Call Us |
| 57 |
407465 |
Bracket Upstop Price: Call Us |
| 58 |
194747 |
Bolt Shoulder Sector Pivot CFM Price: Call Us |
| 59 |
194748 |
Washer Thrust Sector Steering Price: Call Us |
| 60 |
73971000 |
Nut Flange Lock 5/8-11 Price: Call Us |
| 61 |
194740 |
Draglink LH Price: Call Us |
| 62 |
194741 |
Draglink, RH Price: Call Us |
| 63 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 64 |
199849 |
Retainer Clip Spring Steering Price: Call Us |
| 65 |
194734 |
Brace Axle Front Price: Call Us |
| 66 |
71020748 |
Bolt Hex Fghd 7/16-14 x 3 Serr Price: Call Us |
| 67 |
194737 |
Bushing PM Front Axle Price: Call Us |
| 68 |
73900700 |
Nut Lock Flange 7/16-14 Gr. 5 Price: Call Us |
| 69 |
199162 |
Washer 1.5 x .505 x .118 Price: Call Us |
| 69 |
93-4133 |
SEAL-LIP Price: $37.43 |
| 70 |
25-3210 |
SEAL-LIP This part replaces 103461. Price: $23.14 |
| 71 |
252-82 |
BEARING-NEEDLE Price: $51.31 |
| 73 |
28-3400 |
O-RING Price: $6.67 |
| 300 |
110-3052 |
HOUSING ASM Price: $1,923.12 |
| 302 |
353-599 |
PIN-DOWEL Price: $2.65 |
| 308 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 309 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 315 |
25-3300 |
BEARING-NEEDLE Price: $107.05 |
| 324 |
28-3340 |
GASKET Price: $16.81 |
| 326 |
107-4370 |
PLUG-EXPANSION Price: $6.00 |
| 327 |
67-9090 |
PLUG Price: $41.68 |
| 328 |
136-3219 |
PLUG ASM This part replaces 28-3440. Price: $21.54 |
| 336 |
323-10 |
SCREW-HH Price: $0.89 |
| 337 |
75-0110 |
CAPSCREW-HH Price: $2.14 |
| 338 |
28-3530 |
CAPSCREW Price: $4.00 |
| 339 |
49-7830 |
CHECK VALVE KIT Price: $311.16 |
| 339A |
28-3570 |
O-RING Price: $6.06 |
| 339B |
28-3580 |
RING-BACK UP Price: $20.88 |
| 339C |
28-3590 |
O-RING Price: $4.60 |
| 340 |
75-0160 |
PLUG-PIPE Price: $4.39 |
| 342 |
136-3219 |
PLUG ASM This part replaces 28-3440. Price: $21.54 |
| 357 |
92-1773 |
SCREW-HHF Price: $3.05 |
| 358 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 373 |
94-2976 |
RING-RETAINING Price: $6.24 |
| 401 |
49-8200 |
SHAFT-MOTOR Price: $1,051.65 |
| 403 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 406 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 408 |
28-3300 |
BEARING-ROLLER Price: $137.87 |
| 409 |
25-3300 |
BEARING-NEEDLE Price: $107.05 |
| 416 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 419 |
28-3380 |
PLATE-VALVE, MOTOR Price: $468.61 |
