| Ref | Part Number | Description |
|---|
| 1 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 1 |
532185685 |
VARI-SPEED DRIVE CONTROL ASSEM Price: $32.99 |
| 2 |
3296-357 |
Nut-HFH Price: Call Us |
| 2 |
532169911 |
BEARING, BALL Price: $11.99 |
| 3 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 3 |
532175103 |
GEAR, PINION Price: $10.99 |
| 4 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 4 |
532185681 |
SCREW Price: $3.99 |
| 5 |
28-9060 |
PLATE-IDLER Price: $137.75 |
| 5 |
532169778 |
V-BELT Price: $17.99 |
| 6 |
5-1077 |
KEY-SQUARE Price: $6.18 |
| 6 |
532194185 |
DRIVE CONTROL BAIL This part replaces 532186010. Price: $9.99 |
| 7 |
532191730 |
NUT.HEX.FLANGE.1/4 This part replaces 532751152. Price: $3.99 |
| 7 |
99-1297 |
IDLER ARM ASM This part replaces 27-8580. Price: $133.94 |
| 8 |
532150182 |
CAP.HUB.ARC.SPOKE.8".LP This part replaces 532180626. Price: $3.99 |
| 8 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 9 |
3296-5 |
NUT-HEX Price: $3.09 |
| 9 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 10 |
532193366 |
KIT.PINION.ASM.LH This part replaces 532188292. Price: $43.99 |
| 10 |
65-5940 |
PULLEY-IDLER Price: $35.61 |
| 11 |
532180775 |
WHEEL.8X2.PR.LP.RADII.BLACK.BU This part replaces 532180767. Price: $29.99 |
| 11 |
7-0081 |
WASHER-FLAT Price: $0.89 |
| 12 |
65-5950 |
BUSHING-PULLEY Price: $4.44 |
| 12 |
812000058 |
E-RING 7/16 RE Price: $2.99 |
| 13 |
3211-8 |
SCREW-HH Price: $3.50 |
| 13 |
532193367 |
KIT.PINION.ASM.RH This part replaces 532188293. Price: $38.99 |
| 14 |
27-1160 |
V-BELT Price: $51.80 |
| 14 |
581840401 |
COVER.DUST.WHEEL.INNER.WALK This part replaces 532180504. Price: $5.99 |
| 15 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 15 |
532175102 |
RETAINER, DRIVE, RH Price: $5.99 |
| 16 |
32146-20 |
NUT-HEX Price: $3.23 |
| 16 |
532067725 |
WASHER FLUT Price: $5.99 |
| 17 |
532175098 |
PAWL.DRIVE.21.EZ-WALK Price: $4.99 |
| 17 |
7-4150 |
WASHER Price: $1.19 |
| 18 |
27-0970-03 |
PULLEY ASM This part replaces 27-0970. Price: $51.99 |
| 18 |
532185574 |
SELECTOR KNOB Price: $5.99 |
| 19 |
253-139 |
SEAL-OIL Price: $12.45 |
| 19 |
532188291 |
SPRING, TORSION Price: $3.99 |
| 20 |
46-8530 |
BEARING ASM Price: $93.99 |
| 20 |
532175104 |
DISC.DRIVE.21.EZ-WALK Price: $5.99 |
| 21 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 21 |
532184172 |
SEAL.PINION This part replaces 532175101. Price: $5.99 |
| 22 |
27-7680-03 |
RING-DECK SUPPORT This part replaces 27-7680. Price: $70.99 |
| 23 |
532175105 |
RETAINER.DRIVE.21.EZ-WALK.LT Price: $5.99 |
| 23 |
68-8340 |
DECAL-TORQUE Price: $19.99 |
| 24 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 25 |
61-4160 |
HOUSING-SPINDLE Price: $131.00 |
| 26 |
32128-21 |
NUT-HF Price: $0.39 |
| 26 |
532175262 |
SCREW, HEX HD TAPPING #10-24 1 Price: $3.99 |
| 27 |
27-0920 |
SHAFT Price: $158.07 |
| 28 |
27-0990-03 |
BLADE-18 INCH This part replaces 27-0990. Price: $18.94 |
| 28 |
532432664 |
COVER.DRIVE.ASM.185579.CE.WALK This part replaces 532185579. Price: $19.99 |
| 29 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 30 |
3253-27 |
WASHER-LOCK Price: $2.24 |
| 31 |
44-2200 |
SCREW-BLADE Price: $4.04 |
| 31 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532132010. Price: $3.99 |
| 32 |
27-0950 |
SPACER Price: $29.99 |
| 32 |
532443262 |
RP PULLEY.DRIVE.EZ/VAR.SCREWON This part replaces 532169742. Price: $9.99 |
| 33 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 34 |
92-8791 |
DISCONTINUED This part replaces 72-9260. Price: Call Us |
| 35 |
40-6400 |
SHAFT-ROLLER Price: $38.99 |
| 36 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 36 |
532187212 |
TRANSMISSION.21RD.FGDE This part replaces 532185566. Price: $84.99 |
| 37 |
29-4820 |
ROLLER Price: $14.88 |
| 38 |
57-0690 |
PIN-SPECIAL Price: $3.66 |
| 38 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 40 |
532406558 |
SPRING This part replaces 532182226. Price: $6.99 |
| 54 |
532410677 |
GBAG.250E2.BLK.GEN.SERVICE This part replaces 532185581. Price: $89.99 |
| 55 |
532175739 |
DRIVESHAFT COVER Price: $2.94 |
| 57 |
532183993 |
FRAME.GBAG.21.HT/BAG Price: $44.99 |
| 61 |
817060410 |
SCREW 14-20 X 5/8 Price: $3.99 |
| 62 |
532187212 |
TRANSMISSION.21RD.FGDE This part replaces 532174917. Price: $84.99 |
| 63 |
532057072 |
SEAL Price: $4.99 |
| 64 |
532077881 |
BEARING Price: $24.99 |
| 65 |
532057079 |
THRUST WASHER Price: $1.99 |
| 66 |
532174918 |
DRIVE SHAFT, 21" FWGD Price: $23.99 |
| 67 |
532160817 |
WASHER, THRUST Price: $3.99 |
| 68 |
532187212 |
TRANSMISSION.21RD.FGDE This part replaces 532174916. Price: $84.99 |
| 69 |
532160818 |
BEARING, NEEDLE, THRUST Price: $4.99 |
| 70 |
532850848 |
HI PRO KEY Price: $4.99 |
| 71 |
532171755 |
GEAR, HELICAL (2 2MC) Price: $19.99 |
| 72 |
812000003 |
E-RING Price: $4.99 |
| 73 |
532183863 |
SHAFT GEAR WORM Price: $24.99 |
| 74 |
532186214 |
Return Arm Price: Call Us |
| 75 |
532186215 |
BRKT.TRANSMISSION.BZP Price: $3.99 |
