| Ref | Part Number | Description |
|---|
| 1 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 1 |
532150546 |
STEERING WHEEL KIT This part replaces 532121472. Price: $59.99 |
| 2 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 2 |
532142033 |
Axle, Front (AYP part number) This part replaces 532133988. Price: $59.99 |
| 3 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 3 |
532156483 |
SPINDLE ASM LH This part replaces 532130460. Price: $14.99 |
| 4 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 4 |
532130459 |
Spindle, Assembly, R.H. Price: $29.86 |
| 5 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 6 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 6 |
532121748 |
Washer 25/32 x 1-5/8 x 16 Gauge (AYP part number) Price: $1.99 |
| 7 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 7 |
819272016 |
Washer 27/32 x 1-1/4 x 16 Gauge (AYP part number) Price: $2.99 |
| 8 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 8 |
812000029 |
Ring, Klip (AYP part number) Price: $1.99 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $1.99 |
| 10 |
532130468 |
Link, Drag (AYP part number) Price: $49.99 |
| 11 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 12 |
873680600 |
LOCKNUT This part replaces 873610600. Price: $1.99 |
| 13 |
532110438 |
Spacer, Bearing (AYP part number) Price: $5.99 |
| 14 |
874011056 |
Bolt, Hex 5/8 - 11 unc x 3-1/2 (AYP part number) Price: $4.99 |
| 15 |
583612401 |
LOCKNUT M (1 2) (5 2) This part replaces 873601000. Price: $2.99 |
| 16 |
532132624 |
Pin, Axle 5/8 - 1.55/1.54 (AYP part number) Price: $2.42 |
| 17 |
532156544 |
STEERING SHAFT This part replaces 532128762. Price: $64.99 |
| 18 |
532057079 |
Washer (AYP part number) Price: $2.99 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $6.99 |
| 20 |
819091016 |
WASHER This part replaces 532126684. Price: $2.99 |
| 21 |
810040400 |
Washer, Lock 1/4 (AYP part number) Price: $3.99 |
| 22 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871070410. Price: $2.99 |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $27.99 |
| 24 |
532109816 |
Nyliner, Snap In (AYP part number) Price: $2.99 |
| 25 |
532124036 |
Bracket, Steering (AYP part number) Price: $4.99 |
| 26 |
812000029 |
Ring, Klip (AYP part number) Price: $1.99 |
| 27 |
532136874 |
Gear Sector (AYP part number) This part replaces 532124034. Price: $49.99 |
| 28 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 29 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 30 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 31 |
873680600 |
LOCKNUT This part replaces 873610600. Price: $1.99 |
| 32 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532130467. Price: $59.99 |
| 33 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111216. Price: $2.99 |
| 34 |
810040500 |
Washer, Lock 5/16 (AYP part number) Price: $2.99 |
| 35 |
873610500 |
This part replaces 873810500. Price: Call Us |
| 36 |
532155108 |
KIT/BUSH This part replaces 532124720. Price: $3.99 |
| 37 |
817211008 |
Screw, Hex Wsh. Tap #10-16 x 1/2 (AYP part number) This part replaces 817431008. Price: $2.99 |
| 38 |
532150546 |
STEERING WHEEL KIT This part replaces 532126805. Price: $59.99 |
| 39 |
532100712 |
Washer 17/32 x 2-1/4 x .160 (AYP part number) Price: $2.42 |
| 40 |
873940800 |
Nut, Hex, Toplock Jam 1/2-20 (AYP part number) Price: $3.99 |
| 41 |
532100711 |
Adapter, Steering Wheel (AYP part number) Price: $11.99 |
| 43 |
532121749 |
Washer 25/32 x 1-1/4 x 16 Gauge (AYP part number) Price: $1.99 |
| 44 |
532121748 |
Washer 25/32 x 1-5/8 x 16 Ga. (AYP part number) Price: $1.99 |
| 45 |
81200002 |
Ring, Klip (AYP part number) Price: Call Us |
| 46 |
532121232 |
Cap, Spindle (AYP part number) Price: $1.99 |
