| Ref | Part Number | Description |
|---|
| 1 |
04650551 |
WLDMT, IDLER ARM Price: $44.45 |
| 2 |
07300101 |
ASM, 4" IDLER (.75 WIDE) Price: $56.45 |
| 3 |
04655251 |
WLDMT, JACKSHAFT SHAFT Price: $173.45 |
| 4 |
07341067 |
WLDMT, JACKSHAFT HOUSING Price: $183.95 |
| 5 |
04635951 |
WLDMT, DECK IDLER Price: $59.45 |
| 6 |
04656000 |
RETAINER, JACKSHAFT SPINDLE Price: $13.45 |
| 7 |
04694500 |
SPCR, BEARING SPINDLE Price: $31.45 |
| 8 |
04714600 |
SPACER, IDLER ARM Price: $5.95 |
| 9 |
04720051 |
PLATE, JACKSHAFT COVER Price: $24.95 |
| 10 |
05400719 |
BRG-BALL .315X.866X.276(608) Price: $3.95 |
| 11 |
05400730 |
BEARING, RG 1.000 X 2.0467 X .591 This part replaces 05434700. Price: $18.95 |
| 12 |
05480000 |
BRG-BALL .50X1.38X.438 SEALED Price: $13.95 |
| 13 |
05501113 |
BSHG-SLV .330X.455X.550 Price: Call Us |
| 14 |
05901711 |
BLT-HEX .38-16X1.00 G5 ZCC This part replaces 05948700. Price: $1.45 |
| 15 |
06200339 |
BTL,RHSSN .500-13 X 3.25 G5 ZCC This part replaces 06200216. Price: $3.45 |
| 16 |
06200324 |
BLT, RHSN .31-18X1.75 G5 ZCC This part replaces 06220200. Price: $2.95 |
| 17 |
06200313 |
BLT, RHSN .38-16X1.00 G5 ZCC This part replaces 06223600. Price: $2.45 |
| 18 |
06200417 |
BLT, RHSN .38-16X1.75 G5 ZCC This part replaces 06223800. Price: $3.95 |
| 19 |
06200416 |
BLT, RHSN .38-16X1.50 G5 ZCC This part replaces 06224200. Price: $3.95 |
| 20 |
06401013 |
WSHR-FLT .406X.812X.065 ZCC This part replaces 06436200. Price: $0.95 |
| 21 |
06401015 |
WSHR,FLT .531X1.062X.095 ZCC This part replaces 06441900. Price: $0.95 |
| 22 |
06500840 |
NUT,LK-CTR-FLG .31-18 GF ZCC This part replaces 06528700. Price: $0.95 |
| 23 |
06500902 |
NUT-LK-CTR-FLG .500-13 GG ZCC This part replaces 06530008. Price: $0.95 |
| 24 |
06500901 |
NUT-LK-CTR-FLG .375-16 GF ZCC This part replaces 06534800. Price: $0.95 |
| 25 |
04676151 |
WLDMT, PIVOTING IDLER Price: $86.95 |
| 26 |
06500735 |
NUT- SPNLK-FLG .38-16 G5 ZCC This part replaces 06534900. Price: $1.45 |
| 27 |
06500726 |
NUT,NYL-FLG .38-16 GF ZCC This part replaces 06545500. Price: $1.45 |
| 28 |
07001701 |
BOLT,EYE .38-16X4.50,.75"EYE Price: $12.45 |
| 29 |
08300505 |
SPRING, EXTENSION Price: $23.95 |
| 30 |
09357700 |
SPACER .510 X .867 X 1.1485 Price: $4.45 |
| 31 |
05700217 |
RING, RETAINING 7/8" INT Price: $1.95 |
