| Ref | Part Number | Description |
|---|
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532188715. Price: $219.99 |
| 1 |
925-1707D |
BATTERY Not Available This part replaces IH-PRLU. Price: |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
IH-56286-C92 |
CABLE Not Available This part replaces IH-56286-C91. Price: |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 3 |
IH-545720-R1 |
Cable, Magneto Switch to Generator A Terminal Price: Call Us |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 4 |
IH-545721-R3 |
CABLE Not Available Price: |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
IH-364910-R1 |
Cover, Battery Terminal Price: Call Us |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
IH-55162-C1 |
CABLE Not Available Price: |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 8 |
IH-545723-R1 |
CABLE-HEAD LAMP Not Available Price: |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
IH-545724-R1 |
CABLE Not Available Price: |
| 10 |
None |
Cable, Switch to Charge Indicator |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 11 |
925-3012 |
FUSE-10 AMP Not Available This part replaces 725-3012. Price: |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $8.99 |
| 12 |
IH-545726-R1 |
Cable, Taillight Price: Call Us |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
726-0272 |
Clamp This part replaces 726-3025. Price: $6.24 |
| 14 |
726-3008 |
Clip, Cable This part replaces 726-3015. Price: $4.26 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
None |
Clip, Safety Starting Switch Cable |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 16 |
IH-365584-R1 |
Clip, Cable Price: Call Us |
| 17 |
None |
Grommet, Seat Support Edge |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
IH-549293-R1 |
Grommet, Frame Edge Price: Call Us |
| 19 |
IH-545130-R91 |
Regulator, Voltage Price: Call Us |
| 20 |
None |
Gasket, Voltage Regulator |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 22 |
KH-231149 |
SHIM Not Available Price: |
| 23 |
KH-231278-S |
PULLEY-GENERATOR Not Available This part replaces KH-231278. Price: |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 24 |
925-3001 |
Solenoid This part replaces 725-3001. Price: $54.39 |
| 26 |
IH-60736-C3 |
IGNITION SWITCH This part replaces IH-60736-C1. Price: $79.09 |
| 27 |
IH-131313-C2 |
IGNITION KEY This part replaces IH-382458-R2. Price: $10.72 |
| 28 |
IH-375431-R1 |
Washer, Battery Ignition Switch Price: $10.40 |
| 29 |
IH-365502-R1 |
Nut, Battery Ignition Switch Price: $9.99 |
| 30 |
IH-402238-R1 |
SOCKET, IGNITION SWITCH Price: Call Us |
| 31 |
IH-402239-R1 |
CHANNEL Not Available Price: |
| 32 |
IH-394771-R93 |
SWITCH This part replaces IH-394771-R92. Price: $80.50 |
| 34 |
925-0222 |
Head Light This part replaces 725-0222. Price: $51.68 |
| 35 |
IH-389746-R2 |
RING Not Available This part replaces IH-389746-R1. Price: |
| 36 |
IH-545616-R1 |
LENS, TAIL LIGHT Not Available Price: |
| 37 |
925-3141 |
Ammeter This part replaces 725-3023. Price: $55.06 |
| 39 |
726-3008 |
Clip, Cable This part replaces 726-3015. Price: $4.26 |
| 40 |
IH-106382-C91 |
HOUR METER Not Available Price: |
