| Ref | Part Number | Description |
|---|
| 1 |
23-8880 |
BRG DRIVER Price: $160.79 |
| 1 |
530016153 |
Screw Price: $1.99 |
| 2 |
3219-18 |
NUT-HEX Price: $3.26 |
| 2 |
530053183 |
Cylinder Shield Price: $5.99 |
| 3 |
23-8840 |
STUD Price: $65.53 |
| 3 |
530071835 |
Kit-Purge Bulb This part replaces 530047213. Price: $5.99 |
| 4 |
22-6090 |
DISCONTINUED Price: Call Us |
| 4 |
530015780 |
Screw Price: $1.99 |
| 5 |
23-8850 |
DISC-GET FROM K-LINE IND TOR238900A Price: Call Us |
| 5 |
530095646 |
Fuel Pick-up Ass'y. Price: $2.99 |
| 6 |
530069247 |
Kit-Line Purge/Carb. (Small Dia) Price: $3.99 |
| 7 |
530069216 |
Kit-Line Purge/Tank (large line) Price: $3.99 |
| 8 |
530049244 |
Grommet-Carb Adjust. Price: $1.99 |
| 9 |
530038479 |
Limiter Cap-High Price: $1.99 |
| 10 |
530038478 |
Limiter Cap-Low Price: $1.99 |
| 12 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 13 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 15 |
530015814 |
Screw Price: $1.99 |
| 16 |
530039198 |
Ignition Module Price: $29.99 |
| 17 |
530047442 |
Ground Strap Price: $1.99 |
| 18 |
530037652 |
Heat Insulator Price: $1.99 |
| 19 |
530049870 |
Muffler Back Plate Price: $3.99 |
| 20 |
530016132 |
Screw Price: $1.99 |
| 21 |
530036103 |
Spark Screen Price: Call Us |
| 22 |
530037813 |
Muffler Diffuser Price: $1.99 |
| 23 |
530019221 |
Muffler Gasket Price: $1.99 |
| 25 |
545113101 |
CRANKSHAFT ASSY This part replaces 530047062. Price: $54.99 |
| 26 |
530037935 |
Cap-Crankcase Price: $8.99 |
| 27 |
530056363 |
Seal & Bearing Assy. Price: $11.99 |
| 28 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 29 |
530015697 |
Retainer - Piston Pin Price: $1.99 |
| 31 |
530069720 |
Cylinder Kit Price: $17.52 |
| 32 |
530019249 |
Gasket - Carb. Adapter Price: $1.99 |
| 33 |
530016187 |
Screw Price: $1.99 |
| 35 |
530016386 |
Screw Price: $5.99 |
| 36 |
530019271 |
GASKET This part replaces 530019239. Price: $1.99 |
| 38 |
530047604 |
Air Filter Housing Price: $1.99 |
| 39 |
530016101 |
Nut - Carb. Screw Price: $1.99 |
| 40 |
530037793 |
Air Filter - Foam Price: $1.99 |
| 41 |
530031163 |
Bar Wrench This part replaces 530031135. Price: $4.99 |
