| Ref | Part Number | Description |
|---|
| 1 |
125-6918 |
SWITCH-OIL Price: $25.77 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532188715. Price: $219.99 |
| 2 |
125-6975 |
BOLT-JOINT, PIPE Price: $12.92 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
125-6952 |
BOLT-JOINT, PIPE Price: $18.97 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
125-7076 |
PIPE ASM Price: $102.27 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
125-6931 |
RETAINER Price: $14.47 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
125-6976 |
RETAINER Price: $8.13 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
125-6988 |
JOINT BOLT ASM Price: $10.74 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
125-7174 |
WASHER-SEAL Price: $5.45 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
125-7194 |
BOLT-JOINT Price: $5.25 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
125-7174 |
WASHER-SEAL Price: $5.45 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $17.99 |
| 11 |
125-7175 |
WASHER-SEAL Price: $6.16 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
125-7193 |
GASKET Price: $1.28 |
| 13 |
125-7212 |
BOLT Price: $2.74 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
125-7231 |
NUT Price: $3.77 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
125-6971 |
ELBOW Price: $33.07 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 16 |
125-7077 |
PIPE Price: $72.90 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
125-6958 |
HOSE Price: $12.98 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
125-7188 |
CLAMP-HOSE Price: $2.39 |
| 19 |
125-7198 |
O-RING Price: $7.26 |
| 20 |
125-7208 |
BOLT Price: $3.77 |
| 21 |
125-7105 |
CHECK VALVE ASM Price: $41.11 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 27 |
125-7098 |
NOZZLE Price: $43.36 |
