| Ref | Part Number | Description |
|---|
| 1 |
119-5043 |
MANIFOLD ASM Price: $2,479.58 |
| 2 |
119-5044-03 |
BRACKET-CONTROLLER MOUNT Price: $45.05 |
| 3 |
114-3321 |
CONTROLLER-TEC Price: $1,515.96 |
| 3 |
532431022 |
GASKET.GEARCASE.CRT/DRT.TILLER Price: $17.99 |
| 4 |
120-8589-03 |
BRACKET-TUBE Price: $60.38 |
| 4 |
532005020 |
NEEDLE BRNG LT Price: $9.99 |
| 5 |
120-0608-03 |
HINGE Price: $130.93 |
| 5 |
532001370 |
THRUST WASHER Price: $2.99 |
| 6 |
120-0611-03 |
STRAP Price: $70.31 |
| 6 |
586196301 |
PINION INPUT CRT TILLER This part replaces 532137335. Price: $19.99 |
| 7 |
120-0613-03 |
STRAP Price: $81.86 |
| 7 |
532145101 |
SHAFT.INPUT."D"".TILLER Price: $59.99 |
| 8 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 8 |
532004895 |
BEARING This part replaces 532124792. Price: $9.99 |
| 9 |
322-20 |
SCREW-HH Price: $1.79 |
| 9 |
532154467 |
WASHER, SEAL Price: $3.99 |
| 10 |
110-5331 |
SPRING-COMPRESSION Price: $22.18 |
| 10 |
532100482 |
STEEL.BALL.KIT(12 BALLS) This part replaces 532124697. Price: $3.99 |
| 11 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 11 |
532100371 |
SPRING-SHIFT CRT Price: $3.99 |
| 12 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 12 |
532106160 |
O-RING TI Price: $3.99 |
| 13 |
321-7 |
SCREW-HH Price: $4.19 |
| 13 |
532142145 |
SHIFTING ARM Price: $14.99 |
| 14 |
104-7201 |
NUT-HF Price: $0.69 |
| 14 |
532008353 |
SHIFT FORK TI Price: $19.99 |
| 15 |
120-0646 |
HOUSING-LOWER, ULTRASONIC SENSOR Price: $89.58 |
| 15 |
812000039 |
KLIP RING Price: $3.99 |
| 16 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 16 |
532154466 |
SHAFT.SHIFTER.TILLER Price: $4.99 |
| 17 |
117-8114 |
SENSOR-SONIC Price: $850.04 |
| 18 |
120-0645 |
COVER-SENSOR, ULTRASONIC Price: $80.27 |
| 18 |
532004358 |
WASHER Price: $3.99 |
| 19 |
812000040 |
KLIP RING Price: $3.99 |
| 19 |
92-0010 |
U-BOLT Price: $10.65 |
| 20 |
100-8490 |
SWITCH-ROCKER, ON-NONE-ON Price: $33.76 |
| 21 |
532102115 |
GEAR-REV IDLR CRT Price: $9.99 |
| 22 |
532006803 |
NEEDLE BEARING TI Price: $6.99 |
| 23 |
120-0647 |
NUT Price: $21.97 |
| 23 |
532102111 |
SHAFT CRT Price: $17.99 |
| 24 |
120-0648 |
PLUG-PROGRAMMING Price: $62.08 |
| 24 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 25 |
873610700 |
NUT.ASF.HEX.7/16 Price: $3.99 |
| 25 |
95-7652 |
LIGHT-INDICATOR Price: $45.99 |
| 26 |
120-0772 |
CAP-TUBE Price: $5.21 |
| 27 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 27 |
532431219 |
BEARING.GROUND.DRIVE This part replaces 532143009. Price: $6.99 |
| 28 |
120-0757-03 |
BRACKET-TUBE Price: $29.00 |
| 28 |
532106390 |
SPACER Price: $3.99 |
| 29 |
120-0799-03 |
STRAP Price: $92.15 |
| 29 |
532102134 |
CHAIN CRT Price: $17.99 |
| 30 |
532150737 |
GROUND SHAFT ASS'Y Price: $49.99 |
| 31 |
117-8115 |
CABLE-ULTRASONIC SENSOR, 4 METER Price: $152.18 |
| 31 |
532143008 |
BEARING, SHAFT RH CRT Price: $4.99 |
| 32 |
122-0756 |
HARNESS-WIRE, SONIC BOOM This part replaces 119-1759. Price: $920.12 |
| 32 |
532106388 |
SPACER TI Price: $3.99 |
| 33 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 33 |
532102121 |
SPRCKT 8 GEAR CRT Price: $34.99 |
| 34 |
120-0761 |
BUSHING Price: $3.39 |
| 34 |
532102112 |
SHAFT.SECONDARY.REDUCTION.CRT Price: $17.99 |
| 35 |
119-9432 |
DECAL-CONTROLLER Price: $24.95 |
| 35 |
532102101 |
SCRW WHIZ LOK CRT Price: $2.99 |
| 37 |
120-8575-03 |
UPPER CRADLE ASM Price: $147.46 |
| 37 |
585695502 |
BEARING NEEDLE .875X.687 OE.50 This part replaces 532124791. Price: $2.99 |
| 38 |
120-8576 |
COVER-SLIDE Price: $97.57 |
| 38 |
532154355 |
SPROCKET.ASM.W/BEARING.TILLER This part replaces 532154356. Price: $74.99 |
| 39 |
532105345 |
GEAR TI Price: $22.99 |
| 40 |
532105346 |
GEAR TI Price: $17.99 |
| 41 |
532008358 |
SHAFT.REDUCTION.TILLER Price: $12.99 |
| 42 |
532004220 |
BRNG RACE T Price: $3.99 |
| 43 |
532106146 |
SPACER TI Price: $3.99 |
| 44 |
532155236 |
SEAL ASM, OIL Price: $3.99 |
| 49 |
532431485 |
SHAFT.ASM.TINE Price: $64.99 |
| 50 |
532106147 |
CHAIN.TILLER Price: $39.99 |
| 51 |
817240408 |
SCREW Price: $3.99 |
| 52 |
873220500 |
NUT Price: $3.99 |
| 53 |
532165140 |
BEARING KIT Price: $59.99 |
| 58 |
532179520 |
BOLT SHOULDER 1/4-20 UNC X.875 Price: $2.99 |
| 60 |
532183226 |
FITTING.GREASE.TAPERED Price: $3.99 |
| 61 |
532431015 |
SPACER.1.015X1.50X.650 Price: $2.99 |
| 64 |
532431015 |
SPACER.1.015X1.50X.650 Price: $2.99 |
