| Ref | Part Number | Description |
|---|
| 1 |
33005-00 |
NUT-HF Price: $0.68 |
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
532178557 |
AXLE.FRONT.CAST.MACHINE.W/ZERK Price: $179.99 |
| 2 |
87-5100 |
WASHER-SNUBBING Price: $3.46 |
| 3 |
130-2486 |
MOUNT This part replaces 53-9681. Price: $36.47 |
| 3 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 4 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 4 |
532161849 |
SPINDLE ASSY LH Price: $27.99 |
| 5 |
33115-100 |
SCREW-HH This part replaces 48-7840. Price: $1.57 |
| 5 |
532161848 |
SPINDLE ASM RH Price: $24.99 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
92-7425-03 |
SUPPORT-MOUNT, ENGINE This part replaces 92-7425. Price: $47.42 |
| 7 |
33105-070 |
SCREW-HHF Price: $4.75 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
33105-030 |
SCREW-HHF Price: $1.56 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
48-7570 |
SCREW-HH Price: $8.48 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
48-7810 |
SCREW Price: $7.98 |
| 10 |
874781044 |
Bolt, Fin Hex 5/8-11 x 2-3/4 Price: $3.99 |
| 11 |
33114-020 |
SCREW-HH This part replaces 66-3160. Price: $0.28 |
| 11 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 12 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 12 |
94-1418 |
HOSE-RADIATOR, UPPER Price: $48.18 |
| 13 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
92-7429-03 |
MOUNT-MOTOR, RH This part replaces 92-7429. Price: $99.31 |
| 15 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 15 |
94-1421 |
COUPLING-CENTER SPRING Price: $399.47 |
| 16 |
100-3794 |
DISCONTINUED This part replaces 93-4233. Price: Call Us |
| 16 |
532145103 |
SHAFT ASM, STEERING Price: $99.99 |
| 17 |
75-1370 |
CABLE-BATTERY, POSITIVE Price: $74.84 |
| 18 |
532175572 |
DRAGLINK, BALL JOINT (3SPG1401 Price: $64.99 |
| 18 |
94-3090 |
HARNESS - WIRE, MAIN Price: $1,957.31 |
| 19 |
3256-49 |
WASHER-PLAIN Price: $0.33 |
| 19 |
532156011 |
SUPPORT ASM., STEERING VGT Price: $22.99 |
| 20 |
532163887 |
BOOT.STEERING.BLACK.STEALTH This part replaces 532177592. Price: $5.99 |
| 20 |
86-2990 |
MOUNT-CABLE, THROTTLE Price: $22.81 |
| 21 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 21 |
93-7594 |
SPACER Price: $34.12 |
| 22 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 22 |
93-4215 |
DISCONTINUED Price: Call Us |
| 23 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 24 |
48-7880 |
NUT-HEX Price: $0.25 |
| 25 |
110-6184 |
HOSE-FUEL This part replaces 92-7521. Price: $49.59 |
| 25 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 26 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 26 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 27 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 27 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 28 |
68-9400 |
NUT-FLANGE This part replaces 48-7930. Price: $2.29 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
532104239 |
BEARING-FLANGE GT Price: $9.99 |
| 29 |
94-2624 |
DISCONTINUED Price: Call Us |
| 30 |
2412-125 |
CLAMP-HOSE Price: $5.22 |
| 31 |
532138136 |
BUSHING.NYLINER. Price: $8.99 |
| 31 |
92-7466 |
CLUTCH-FAN Price: $235.73 |
| 32 |
74-3650 |
FAN Price: $269.64 |
| 32 |
819111610 |
WASHER Price: $4.99 |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 34 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 35 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 35 |
531165701 |
SERVICE KIT GEAR.ASM.SECT This part replaces 532138059. Price: $49.99 |
| 36 |
532186799 |
ROD.TIE.NON-ADJUSTABLE This part replaces 532137156. Price: $59.99 |
| 36 |
92-7463 |
DISCONTINUED Price: Call Us |
| 37 |
77-3700 |
GASKET-MUFFLER, EXHAUST Price: $27.34 |
| 37 |
873360600 |
NUT Price: $4.99 |
| 38 |
532121160 |
JOINT.RH This part replaces 532109850. Price: $19.99 |
| 38 |
92-7382 |
DISCONTINUED Price: Call Us |
| 39 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 39 |
873700600 |
NUT Price: $2.99 |
| 40 |
532109851 |
JOINT.LH Price: $27.99 |
| 40 |
74-6490 |
HOSE-LINE, WATER Price: $4.86 |
| 41 |
532155246 |
BRACKET INTERLOCK Price: $4.99 |
| 41 |
92-7381 |
TUBE-RETURN, WATER Price: $75.00 |
| 42 |
33115-025 |
SCREW-HH This part replaces 48-7780. Price: $0.61 |
| 42 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 43 |
92-7426-03 |
MOUNT-MOTOR, LH ASM This part replaces 92-7426. Price: $92.73 |
| 44 |
33004-00 |
NUT-HF Price: $0.34 |
| 44 |
532160135 |
EXT.STEERING.PREM.BLACK This part replaces 532177593. Price: $4.99 |
| 45 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 45 |
819132411 |
Washer 13/32 x 1-1/20 x 11 Ga. Price: $2.99 |
| 46 |
33113-012 |
SCREW-HH This part replaces 48-7610. Price: $0.71 |
| 46 |
819131610 |
WASHER PM Price: $4.99 |
| 47 |
529846001 |
SERVICE.KIT BRKT.ASM.IDLER.STA This part replaces 532177863. Price: $7.99 |
| 47 |
82-5120-03 |
PLATE-ADAPTER This part replaces 82-5120. Price: $822.40 |
| 48 |
2412-150 |
CLIP-J Price: $1.63 |
| 48 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 49 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 49 |
94-1422 |
SPACER-COUPLING Price: $17.98 |
| 50 |
3290-282 |
RIVET-BLIND Price: $0.28 |
| 51 |
93-9176 |
DIPSTICK Price: $75.61 |
