| Ref | Part Number | Description |
|---|
| 1 |
11-0160 |
ROLLER SHAFT SCREW ASM Price: $28.16 |
| 1 |
163465 |
Battery Price: Call Us |
| 2 |
3220-3 |
NUT-HJ Price: $0.28 |
| 2 |
74760412 |
Bolt Hex Hd 1/4-20 unc x 3/4 Price: Call Us |
| 3 |
137-9706 |
DECAL-WARNING This part replaces 93-8064. Price: $4.48 |
| 4 |
147-3120 |
BALL JOINT RECEIVER ASM This part replaces 99-1460. Price: $16.35 |
| 5 |
94-5590 |
RH Lift Arm ASM Price: Call Us |
| 6 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 7 |
322-1 |
SCREW-HH Price: $0.22 |
| 8 |
115-3259 |
KIT-SERVICE, PIN This part replaces 10-6110. Price: $39.21 |
| 8 |
176689 |
Box Battery Price: Call Us |
| 9 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 10 |
HY4486 |
NUT UNF 1/2"NYLOC EXT THIN5/16 This part replaces 283-8. Price: $1.36 |
| 11 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 12 |
105-3822 |
HYD CYLINDER ASM This part replaces 99-8159. Price: $533.45 |
| 13 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 14 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 15 |
5-1226 |
WASHER Price: $3.90 |
| 16 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 16 |
176138 |
Switch Interlock Price: Call Us |
| 17 |
10-7820 |
PIVOT HINGE ASM Price: $504.57 |
| 18 |
136-8483 |
FRAME-PULL, RH This part replaces 104-2055. Price: $382.66 |
| 19 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 20 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 21 |
138-6311 |
ARM-PULL-ASSEMBLY-LH This part replaces 92-0586. Price: $29.91 |
| 21 |
175688 |
Harness Asm Light w/4152j Price: Call Us |
| 22 |
133-2337 |
ROLLER ASM This part replaces 99-4277. Price: $176.14 |
| 22 |
4152J |
Bulb Light #1156 Price: Call Us |
| 23 |
3290-317 |
WASHER-SPRING Price: $1.40 |
| 24 |
131-4295 |
PIN-PIVOT This part replaces 10-6090. Price: $51.39 |
| 24 |
421299 |
Cable Battery 6 Ga. 11"red Price: Call Us |
| 25 |
138-6303 |
ARM-PULL-ASSEMBLY-RH This part replaces 92-0585. Price: $29.91 |
| 25 |
421297 |
Cable Battery Price: Call Us |
| 26 |
175158 |
Fuse 20 AMP Price: Call Us |
| 26 |
21-8470 |
SHAFT-ROLLER Price: $62.10 |
| 27 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 27 |
73510400 |
Nut Keps Hex 1/4-20 unc Price: Call Us |
| 28 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 28 |
421298 |
Cable Ground 6 Ga. 12" Black Price: Call Us |
| 29 |
192749 |
Switch Seat Price: Call Us |
| 29 |
92-9767 |
HOSE Price: $69.61 |
| 30 |
105-3828 |
SPACER Price: $5.10 |
| 30 |
193350 |
Switch Ign Price: Call Us |
| 33 |
411933 |
Key/Chain Price: Call Us |
| 34 |
110712X |
Switch Light/Reset Price: Call Us |
| 40 |
197428 |
Harness Ign Price: Call Us |
| 41 |
71110408 |
Bolt Blk Fin Hex 1/4-20 Price: Call Us |
| 42 |
131563 |
Cover Terminal Red Price: Call Us |
| 43 |
192507 |
Solenoid Price: Call Us |
| 48 |
140844 |
Adapter Ammeter Price: Call Us |
| 52 |
141940 |
Protection Wire Loop Price: Call Us |
| 79 |
175242 |
Socket Asm Bulb Price: Call Us |
| 90 |
180449 |
Cover Terminal Battery Price: Call Us |
| 92 |
196615 |
Harness Pigtail Price: Call Us |
| 93 |
192540 |
Screw Plastite 10-14 x 2.0 Price: Call Us |
