| Ref | Part Number | Description |
|---|
| MK |
380 |
Mulcher Kit with Blades Price: Call Us MK |
| 1 |
532157032 |
DECAL SET Price: $12.99 |
| 1 |
71-0350 |
FOAM-SUPPORT, RADIATOR (RH) Price: $60.07 |
| 1 |
MA-19572631000 |
HOOD Not Available Price: |
| 2 |
532157007 |
DECAL Price: $2.89 |
| 2 |
69-8590-03 |
TOP RADIATOR SUPPORT ASM This part replaces 69-8590. Price: $1,411.31 |
| 2 |
MA-A3810108000 |
NUT Not Available Price: |
| 3 |
532157193 |
DECAL, HOOD RH LTH120 Price: $13.70 |
| 3 |
71-0360 |
FOAM-SUPPORT, RADIATOR (TOP) Price: $31.82 |
| 3 |
MA-19562621BC0 |
SIDE PANEL (LH) Not Available Price: |
| 4 |
532157195 |
DECAL, HOOD LH LTH120 Price: $10.78 |
| 4 |
69-5380 |
HOSE - UPPER RADIATOR Price: $58.56 |
| 4 |
MA-19562622BC0 |
SIDE PANEL (RH) Not Available Price: |
| 5 |
105-0599 |
RADIATOR CAP ASM This part replaces 66-3241. Price: $48.23 |
| 5 |
532166100 |
DECAL-ENGINE HP Price: $5.61 |
| 5 |
MA-F3000106001 |
NUT Not Available Price: |
| 6 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 6 |
MA-19562677ZB0 |
PLATE (LH) PANEL MTG Not Available This part replaces MA-19562677000. Price: |
| 7 |
110-4100 |
HOSE-FUEL This part replaces 23-2140. Price: $28.86 |
| 7 |
MA-19562678ZB0 |
PLATE (RH) PANEL MTG Not Available This part replaces MA-19562678000. Price: |
| 8 |
323-34 |
SCREW-HH Price: $0.54 |
| 8 |
532137259 |
DECAL WARNING (ENGLISH/FRENCH) Price: $8.99 |
| 8 |
MA-F3010108001 |
NUT Not Available Price: |
| 9 |
13-4239 |
FAN SHROUD FOR SERVICE Price: $352.25 |
| 9 |
532150617 |
DECAL FENDER HUSQ Price: $2.39 |
| 9 |
MA-03500140618 |
WASHER Not Available Price: |
| 10 |
532157140 |
DECAL FENDER DANGER Price: $12.99 |
| 10 |
69-5390 |
HOSE - LOWER RADIATOR Price: $58.56 |
| 10 |
MA-10406313000 |
CLIP-REAR PANEL Not Available Price: |
| 11 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 11 |
MA-H1540108016 |
BOLT,W/WASHER Not Available Price: |
| 12 |
94-2860 |
DISCONTINUED Price: Call Us |
| 12 |
MA-19572624000 |
CUSHION-SIDE PANEL Not Available Price: |
| 13 |
71-0210 |
FOAM-SEAL, RADIATOR Price: $12.02 |
| 13 |
MA-19572642000 |
PANEL (LH) REAR CO Not Available Price: |
| 14 |
304-46 |
DRAINCOCK Price: $7.55 |
| 14 |
532136832 |
DECAL V-BELT SCHEMATIC Price: $3.99 |
| 14 |
MA-19572643000 |
PANEL (RH) REAR CO Not Available Price: |
| 15 |
2812-4 |
REDUCER-PIPE Price: $9.67 |
| 15 |
MA-H1940106016 |
BOLT Not Available This part replaces MA-H1640406016. Price: |
| 16 |
340-124 |
ADAPTER Price: $23.18 |
| 16 |
MA-19562661ZB0 |
SUPPORT-PANEL PLAT Not Available This part replaces MA-19562661000. Price: |
| 17 |
237-22 |
O-RING Price: $2.43 |
| 17 |
MA-H1540108020 |
BOLT,W/WASHER Not Available Price: |
| 18 |
94-3335 |
DISCONTINUED Price: Call Us |
| 18 |
MA-19562671BC0 |
COVER-COWLING Not Available Price: |
| 19 |
32128-20 |
NUT-HF Price: $0.99 |
| 19 |
MA-35180844000 |
SCREW-REAR Not Available Price: |
| 20 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 20 |
69-3020 |
LATCH-CAMLOC Price: $43.54 |
| 20 |
MA-10442675000 |
WASHER Not Available Price: |
| 21 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 21 |
MA-H1540108016 |
BOLT,W/WASHER Not Available Price: |
| 22 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 22 |
MA-05534-10000 |
PLUG Not Available Price: |
| 23 |
46-3380 |
BOLT-SHOULDER Price: $9.57 |
| 23 |
MA-10442646000 |
PLATE-REAR Not Available Price: |
| 24 |
69-7100-03 |
SUPPORT-RADIATOR, LOWER This part replaces 69-7100. Price: $427.96 |
| 24 |
MA-19562681000 |
STRIP-WEAT Not Available Price: |
| 25 |
3290-216 |
WASHER Price: $3.83 |
| 25 |
MA-19562651ZB0 |
PLATE-SIDE PANEL M Not Available This part replaces MA-19562651000. Price: |
| 26 |
32153-5 |
NUT-HEX Price: $1.59 |
| 26 |
MA-35187458000 |
STRIP-RUBBER PNL Not Available Price: |
| 27 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 27 |
MA-35374839000 |
SHIM-SIDE PANEL Not Available This part replaces MA-36205314000. Price: |
| 28 |
340-65 |
O-RING Price: $3.58 |
| 28 |
MA-19560424000 |
CUSHION-REAR PANEL Not Available Price: |
| 29 |
69-5620 |
HOSE ASM Price: $295.27 |
| 29 |
MA-19562656001 |
CUSHION Not Available Price: |
| 30 |
69-8450 |
HYD HOSE ASM Price: $293.46 |
| 30 |
MA-19562657000 |
CUSHION-INSTRMT PN Not Available Price: |
| 31 |
69-5900 |
TUBE ASM Price: $132.49 |
| 31 |
MA-19562658000 |
CUSHION-INSTRMT PN Not Available Price: |
| 32 |
69-1670 |
OIL COOLER ASM Price: $2,500.58 |
| 32 |
MA-19572621000 |
CUSHION-SIDE PANEL Not Available Price: |
| 33 |
32103-3 |
NUT-WING Price: $1.22 |
| 33 |
MA-19562686000 |
CUSHION-RUBBER Not Available Price: |
| 34 |
71-0370 |
FOAM-SUPPORT, RADIATOR (LOWER) Price: $47.96 |
| 34 |
MA-03500140818 |
WASHER Not Available Price: |
| 35 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 36 |
71-0340 |
FOAM-SUPPORT, RADIATOR (LH) Price: $60.07 |
| 37 |
98-7349-03 |
BRACKET-CYLINDER This part replaces 88-9450. Price: $16.20 |
| 38 |
2412-41 |
CLAMP-R Price: $4.82 |
| 39 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 40 |
322-6 |
SCREW-HH Price: $0.45 |
| 41 |
323-7 |
SCREW-HH Price: $0.65 |
| 42 |
71-0380 |
FOAM-COWL, RIGHT REAR Price: $62.16 |
| 43 |
325-6 |
SCREW-HH Price: $1.42 |
| 44 |
71-0390 |
FOAM-SUPPORT, RADIATOR (REAR) Price: $52.94 |
| 45 |
76-8750 |
PLATE-WARNING Price: $9.67 |
| 46 |
3290-271 |
RIVET-POP Price: $0.25 |
| 47 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 48 |
2412-147 |
CLAMP-R Price: $2.51 |
| 50 |
68-6150 |
BREATHER Price: $27.22 |
| 51 |
354-95 |
FITTING-STRAIGHT Price: $6.75 |
| 53 |
110-6188 |
HOSE-FUEL This part replaces 71-2680. Price: $51.72 |
| 54 |
32144-69 |
SCREW-HWHTF Price: $1.58 |
| 56 |
88-6770 |
STUD-BALL Price: $4.55 |
| 57 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 58 |
94-3336 |
DISCONTINUED Price: Call Us |
| 59 |
94-3337 |
DISCONTINUED Price: Call Us |
| 532142341 |
DECAL |
DRAWBAR CONTROL Price: $2.42 532142341 |
| 532166604 |
Manual |
Owner's (English) Price: Call Us 532166604 |
| 532166605 |
Manual |
Owner's (French) Price: Call Us 532166605 |
| 532184310 |
PAD |
FOOTREST LH This part replaces 532154515. Price: $8.99 532184310 |
| 532184311 |
PAD |
FOOTREST RH BLACK This part replaces 532154516. Price: $8.99 532184311 |
| 581724901 |
DECAL.TRACTOR.6MIL.H/ADJUST |
This part replaces 532138311. Price: $9.99 581724901 |
