| Ref | Part Number | Description |
|---|
| 1 |
325-6 |
SCREW-HH Price: $1.42 |
| 1 |
532144393 |
Deck Asm MWR 42"weldment (AYP part number) Price: $139.99 |
| 2 |
3290-319 |
DISCONTINUED Price: Call Us |
| 2 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 3 |
11-5270 |
WASHER-BUMPER Price: $12.82 |
| 3 |
532138017 |
BRKT ASM SWAY BAR Price: $7.99 |
| 4 |
11-4590 |
PAD-BUMPER Price: $21.30 |
| 4 |
532138440 |
BRKT DECK SW BAR Price: $3.99 |
| 5 |
11-5630-01 |
STOP WA NO 6-7 This part replaces 11-5630. Price: $300.49 |
| 5 |
532085902 |
RETAINER SPRING This part replaces 532004939. Price: $1.99 |
| 6 |
3-6520 |
DISCONTINUED Price: Call Us |
| 6 |
532178024 |
BAR SWAY DECK This part replaces 532130832. Price: $5.99 |
| 7 |
325-3 |
SCREW-HH Price: $1.49 |
| 8 |
325-8 |
SCREW-HH Price: $3.52 |
| 8 |
532850857 |
BLADE BOLT Price: $1.99 |
| 9 |
325-7 |
SCREW-HH Price: $1.53 |
| 9 |
539990118 |
SLW 3/8 STD This part replaces 810030600. Price: $1.99 |
| 10 |
3-4596 |
DISCONTINUED Price: Call Us |
| 10 |
532140296 |
WASHER.BLADE Price: $2.99 |
| 11 |
532131323 |
Price: $12.85 |
| 12 |
18-8590 |
DISCONTINUED Price: Call Us |
| 12 |
532129895 |
BEARING.BALL.#6204.(MANDREL) Price: $6.99 |
| 13 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $17.99 |
| 14 |
18-2410 |
DISCONTINUED Price: Call Us |
| 14 |
532128774 |
HSG MANDREL Price: $22.99 |
| 15 |
3290-216 |
WASHER Price: $3.83 |
| 15 |
532110485 |
BEARING Price: $7.99 |
| 16 |
18-2790 |
DISCONTINUED Price: Call Us |
| 16 |
532174493 |
STRIPPER.MANDREL.ROUND.BLACK This part replaces 532128961. Price: $3.99 |
| 17 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 17 |
872110618 |
BOLT CARRIAGE Price: $2.99 |
| 18 |
18-2420 |
DISCONTINUED Price: Call Us |
| 18 |
872140505 |
BOLT This part replaces 532066238. Price: $2.99 |
| 19 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $2.99 |
| 20 |
18-8600 |
DISCONTINUED Price: Call Us |
| 20 |
532159770 |
BAFFLE.VORTEX This part replaces 532136888. Price: $12.99 |
| 21 |
5-6560 |
DISCONTINUED Price: Call Us |
| 21 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 22 |
20-4390 |
SPACER Price: $12.54 |
| 22 |
532134753 |
Stiffener Bracket 42" deck (AYP part number) Price: $5.99 |
| 23 |
115-4948-01 |
HYDRAULIC CYLINDER ASM (12.19 STROKE) This part replaces 22-7530. Price: $935.73 |
| 23 |
532177563 |
BRKT, DEFL. MOWER This part replaces 532131267. Price: $2.99 |
| 24 |
3-0128 |
SHAFT Price: $75.98 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 25 |
3256-30 |
WASHER-FLAT Price: $5.73 |
| 25 |
532123713 |
SPRING TORSION This part replaces 532106734. Price: $3.99 |
| 26 |
286-3 |
DISCONTINUED Price: Call Us |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 27 |
287-2 |
DISCONTINUED Price: Call Us |
| 27 |
532130968 |
SHIELD.DEFLECTOR.MOWER.42".BLK Price: $22.99 |
| 28 |
3-1365 |
CHAIN Price: $72.97 |
| 28 |
819111016 |
WASHER Price: $5.99 |
| 29 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 30 |
37-2800 |
DISCONTINUED Price: Call Us |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $1.99 |
| 31 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $1.99 |
| 32 |
5-2942 |
SHACKLE Price: $16.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $7.99 |
| 33 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 33 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $4.99 |
| 34 |
3-4636 |
CHAIN Price: $22.51 |
| 34 |
872110622 |
BOLT Price: $0.99 |
| 35 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 35 |
532133835 |
FASTENER.XMAS.TREE Price: $3.99 |
| 36 |
532173438 |
PULLEY.IDLER.FLAT This part replaces 532104360. Price: $14.99 |
| 36 |
8-0280 |
DISCONTINUED Price: Call Us |
| 37 |
3211-4 |
SCREW-HH Price: $1.02 |
| 37 |
819131316 |
WASHER Price: $2.99 |
| 38 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 38 |
532132823 |
IDLER SPRING SPACER Price: $4.99 |
| 39 |
5-1720 |
WASHER Price: $2.24 |
| 40 |
23-2610-01 |
LINK ASM This part replaces 23-2610. Price: $211.99 |
| 40 |
873680600 |
LOCKNUT Price: $1.99 |
| 41 |
322-3 |
SCREW-HH Price: $0.79 |
| 42 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 43 |
37-2760-01 |
PIN-LIFT, BAIL This part replaces 37-2760. Price: $89.10 |
| 44 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 44 |
532140088 |
GUARD MANDREL LH BLACK This part replaces 532134236. Price: $14.99 |
| 45 |
7-4152 |
DISCONTINUED Price: Call Us |
| 46 |
3217-7 |
NUT-HEX Price: $0.28 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 47 |
2412-70 |
CLAMP Price: Call Us |
| 49 |
21-5610 |
DISCONTINUED Price: Call Us |
| 50 |
37-2860 |
DISCONTINUED Price: Call Us |
| 51 |
28-2480 |
WASHER-PLAIN Price: $3.99 |
| 52 |
3296-50 |
NUT-LOCK, NI Price: $2.68 |
| 53 |
325-42 |
SCREW-HH Price: $13.99 |
| 54 |
32104-37 |
SCREW-HWH, THREAD CUT Price: $3.26 |
| 54 |
532178515 |
WASHER This part replaces 532133943. Price: $2.99 |
| 55 |
37-2380 |
DISCONTINUED Price: Call Us |
| 55 |
532151785 |
CAM ROLLER KIT This part replaces 532140084. Price: $27.99 |
| 56 |
37-2390 |
DISCONTINUED Price: Call Us |
| 56 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $2.99 |
| 57 |
37-2910-01 |
REST-CYLINDER This part replaces 37-2910. Price: $99.17 |
| 58 |
32146-13 |
NUT-HEX Price: $3.49 |
| 59 |
323-6 |
SCREW-HH Price: $0.66 |
| 59 |
532141043 |
GUARD, BELT Price: $3.99 |
| 60 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 61 |
19-3700 |
DISCONTINUED Price: Call Us |
| 61 |
532131950 |
SPRING EXTENSION Price: $4.99 |
| 62 |
323-8 |
SCREW-HH Price: $1.20 |
| 63 |
5-2262 |
FENDER BRACE Price: $227.15 |
| 64 |
3217-6 |
NUT-HEX Price: $1.19 |
| 65 |
322-2 |
SCREW-HH Price: $0.69 |
| 66 |
21-5480 |
DISCONTINUED Price: Call Us |
| 67 |
5-2263 |
FENDER MOUNT Price: $201.20 |
| 68 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 68 |
532144200 |
V-BELT TRIPATH Price: $32.99 |
| 69 |
3-0144 |
SHAFT Price: $53.89 |
| 70 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 71 |
3218-5 |
NUT-JAM Price: $0.27 |
| 72 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 83 |
532120958 |
WASHER Price: $4.99 |
| 84 |
532156084 |
KEEPER.BELT.IDLER Price: $3.99 |
| 85 |
872110618 |
BOLT CARRIAGE This part replaces 872140618. Price: $2.99 |
| 90 |
874780616 |
BOLT This part replaces 874760614. Price: $3.99 |
| 91 |
532175746 |
BRACKET ASM, ROLLER (L) This part replaces 532132274. Price: $3.99 |
| 92 |
873680600 |
LOCKNUT This part replaces 532062336. Price: $1.99 |
| 93 |
819171416 |
WASHER Price: $2.99 |
| 94 |
539132264 |
MANUAL, OPERATOR Price: $3.20 |
| 95 |
532175747 |
BRACKET ASM, ROLLER This part replaces 532132273. Price: $7.99 |
| 111 |
532155197 |
BRACKET WHEEL GAUGE LH 42" DK Price: $11.99 |
| 112 |
532155198 |
BRACKET WHEEL GAUGE RH 42" DK Price: $11.99 |
| 113 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 114 |
873310500 |
NUT Price: $3.99 |
| 115 |
872110505 |
BOLT This part replaces 872110504. Price: $3.99 |
| 116 |
532004898 |
BOLT Price: $1.99 |
| 117 |
532105455 |
GUAGE WHEEL GT Price: $11.99 |
| 118 |
873680600 |
LOCKNUT This part replaces 532005394. Price: $1.99 |
| 119 |
734117201 |
WASHER This part replaces 819121414. Price: $1.99 |
| 120 |
819171512 |
WASHER Price: $3.99 |
| 121 |
532143723 |
BRACKET.EXTRUDED.GAGE.WHEEL Price: $7.99 |
| 125 |
TBD |
Price: Call Us |
| 128 |
532153390 |
WASHER FELT Price: $2.99 |
| 132 |
819132203 |
WASHER GT Price: $3.99 |
| 532130794 |
MANDREL |
ASM, LH 5PT STAR Price: $32.99 532130794 |
