| Ref | Part Number | Description |
|---|
| 1 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 1 |
532145501 |
Chassis Weldment 11ga (AYP part number) This part replaces 532140341. Price: $130.75 |
| 2 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 2 |
532145009 |
KIT.DRAWBAR.SERVICE This part replaces 532140356. Price: $37.99 |
| 3 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 3 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 4 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 4 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE This part replaces 817490412. Price: $3.99 |
| 5 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 6 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 6 |
532140169 |
Saddle LT Fender Shift (AYP part number) Price: $8.99 |
| 7 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 7 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 8 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 8 |
532002751 |
Clip Line Fuel 13/32 Mtg Hole (AYP part number) Price: $2.42 |
| 9 |
532140621 |
Dash Private Label (AYP part number) Price: Call Us |
| 10 |
532005479 |
Plug Button (AYP part number) Price: $2.99 |
| 11 |
532140311 |
Panel Pnt Dash Lh (AYP part number) Price: $22.99 |
| 13 |
532140816 |
Panel Dash Rh Weldment (AYP part number) Price: Call Us |
| 14 |
817490608 |
Screw Thdrol 3/8-16x1/2 Ty-tt (AYP part number) Price: $3.99 |
| 15 |
532138096 |
Rivet Push (AYP part number) Price: $3.99 |
| 17 |
532144473 |
Hood Paint Steel Private Label (AYP part number) Price: Call Us |
| 24 |
874780616 |
Bolt Fin Hex 3/8-16unc X1 (AYP part number) Price: $3.99 |
| 25 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 26 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 28 |
532179100 |
GRILL ASSEMBLY This part replaces 532142552. Price: $169.99 |
| 29 |
532140273 |
Lens Grille Private Label (AYP part number) Price: $17.99 |
| 30 |
532141324 |
Fender Pnt (AYP part number) Price: Call Us |
| 31 |
532136619 |
Bracket Pnt Fender (AYP part number) Price: $3.99 |
| 32 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 33 |
532124888 |
Footrest Pnt Lh (AYP part number) Price: $3.33 |
| 34 |
532124889 |
Footrest Pnt Rh (AYP part number) Price: $3.33 |
| 35 |
872110606 |
Bolt Rdhd Sht Sqnk 3/8-16 X3/4 (AYP part number) Price: $2.99 |
| 36 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 37 |
532133671 |
Pad Footrest (AYP part number) Price: $7.99 |
| 38 |
532139886 |
Bracket, Asm. Pivot, L.H., Mower Rear (AYP part number) Price: $5.99 |
| 39 |
532139887 |
Bracket, Asm. Pivot, R.H., Mower Rear (AYP part number) Price: $5.99 |
| 51 |
819131216 |
Washer 13/32 x 3/4 x 16 Ga. (AYP part number) Price: $2.99 |
| 53 |
872110608 |
BOLT D This part replaces 872140608. Price: $3.99 |
| 56 |
532140281 |
Support Battery (AYP part number) Price: $1.23 |
| 57 |
874780412 |
Screw Hex 1/4-20 x 3/4 (AYP part number) Price: $2.99 |
| 58 |
532150127 |
AIR DUCT P/L/LT This part replaces 532140806. Price: $14.99 |
| 62 |
532124028 |
Bushing Price: $3.99 |
| 66 |
539990118 |
SLW 3/8 STD This part replaces 811050600. Price: $1.99 |
| 67 |
819091416 |
Washer 9/32 x 7/8 x 16 Ga. (AYP part number) Price: $3.99 |
| 68 |
532140219 |
Hinge Pickoff Hood (AYP part number) Price: $2.99 |
| 69 |
874760412 |
Bolt Hex Hd 1/4-20 (AYP part number) Price: $3.99 |
| 70 |
873680400 |
Nut, Crownlock 1/4-20 (AYP part number) Price: $2.99 |
| 72 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 This part replaces 817030814. Price: $3.99 |
| 73 |
532142779 |
Brace (AYP part number) Price: $2.99 |
| 74 |
819091416 |
Washer 9/32 x 7/8 x 16 Ga. (AYP part number) Price: $3.99 |
| 75 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 873800400. Price: $1.99 |
| 80 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
